Introduction
This section provides information on the cables used to connect the SmartNode and the interface cards to the
existing network infrastructure and to third party products.
Console
The SmartNode can be connected to a serial terminal over its serial console port, as depicted in figure 8.
CAUTION
Serial Terminal
See section
Note
Introduction
The interconnecting cables shall be acceptable for external use
and shall be rated for the proper application with respect to volt-
age, current, anticipated temperature, flammability, and
mechanical serviceability.
Note
A Patton Model 16F-561 RJ45 to DB-9 adapter is included with
each SmartNode 4970 Series device
Figure 8. Connecting a serial terminal
"Console port"
on page 47 for console port pin-outs.
0 /3
0 /2
0 /1
T 1
0 /0
/E
1
E T
H
0 /1
C o
n s
o le
R S
-2
3 2
C • Cabling
41
