Dynojet POWER COMMANDER V Installation Instructions Manual page 6

FIG.J
Stk
FIG.K
FIG.L
21-023 www.powercommander.com
13 Plug the BLUE colored wires from the PCV in-line of the stock wiring harness
14 Unplug the stock wiring harness from the #1 ignition coil (Fig. K).
PCV
15 Plug the PCV in-line of the stock wiring harness and ignition coil (Fig. L).
and ignition coil (Fig. J).
These wires are accessed from the right side of the motorcycle.
The GREEN colored wires go in-line of the stock GREEN/PURPLE
The RED colored wires go in-line of the stock BROWN/PINK
2016 Triumph T120 PCV - 6
