Set Module Time Response
Read Block – Set Module Time
Offset Description
2 to (n+1) Spare
n=60, 120, or 240 depending on what is entered in the Block Transfer Size parameter
(see the configuration file).
Get Module Time for Processor Time
Write Block – Get Module Time
Offset Description
1 to n
n=60, 120, or 240 depending on what is entered in the Block Transfer Size parameter
(see the configuration file).
Read Block – Write Module TIme
Offset Description
8 to n
n=60, 120, or 240 depending on what is entered in the Block Transfer Size parameter
(see the configuration file).

2.4.4 Warm Boot

This block is sent from the CompactLogix processor to the module (output image) when
the module is required to perform a warm-boot (software reset) operation. The structure
of the control block is shown below:
Offset
n=60, 120, or 240 depending on what is entered in the Block Transfer Size parameter
(see the configuration file).
ProSoft Technology, Inc.
MVI69-DFCM User Manual
June 24, 2004
0 9972
1 Write Block ID
0 9973
Spare
0 9973
1 Write Block ID
2 Year (0-9999)
3 Month (1-12)
4 Day (1-31)
5 Hour (0-23)
6 Minutes (0-59)
7 Seconds (0-59)
Spare
Description
0 9998
1 to n Spare
Functional Overview
Length
1
1
Length
1
Length
1
1
1
1
1
1
1
1
Length
1
247
