Product Specifications
actively selecting commands from the command list to execute or issuing commands
directly from the ladder logic. The CompactLogix processor also has the ability to control
the scanning of slaves on the port.

1.1.3 Physical

This module is designed by ProSoft Technology and incorporates licensed technology
from Allen-Bradley (CompactLogix backplane technology).
•
CompactLogix Form Factor - Single Slot
•
Connections :
o
o

1.1.4 CompactLogix Interface

•
Operation via simple ladder logic
•
Complete monitoring of module through RSLogix 5000 software
•
CompactLogix backplane interface via I/O access
•
All data related to the module is contained in a single controller tag with defined
objects to ease in the monitoring and interfacing with the module
1.2

Hardware Specifications

The MVI69-DFCM module is designed by ProSoft Technology and incorporates licensed
technology from Allen-Bradley (CompactLogix backplane technology).
Current Loads
Operating Temperature
Storage Temperature
Relative Humidity
DF1 Port Connector
Configuration Connector
2
RJ45 connectors for DF1 support of RS-232, RS-422 or RS-485
interfaces
1 – RJ45 RS-232 Configuration Tool Connector
800 mA @ 5V (from backplane)
0 to 60° C
32 to 140° F
-40 to 85°C
-40 to 185° F
5 – 95% (w/o condensation)
Two RJ45 connectors (RJ45 to DB9 cable
shipped with unit (supporting RS-232, RS-
422 and RS-485 interfaces (RJ45 to DB9
cables shipped with unit.
RJ45 RS-232 Connector (RJ45 to DB9
cable shipped with unit.
