FUNCTION CODE #5
Unprotected Write (Basic Command Set)
Column Command Parameter
1 Enable/Type Word
2 Virtual Database Address
3 Poll Interval
4 Count
5 Swap Type Code
6 Node Address
7 Function Code = 5
8 Word Address
9 to 11 Not Used
This function writes one or more words of data to the PLC memory.
FUNCTION CODE #100
Word Range Write (PLC-5 Command)(Binary Address)
Column Command Parameter
1 Enable/Type Word
2 Virtual Database Address
3 Poll Interval
4 Count
5 Swap Type Code
6 Node Address
7 Function Code = 100
8 File Number
9 Element Number
10 Sub-Element Number
11 Not Used
This function is used to write one or more words of data to a PLC data table.
ProSoft Technology, Inc.
MVI69-DFCM User Manual
June 24, 2004
Appendix G – Command Function Codes
Description
0=Disabled, 1=Continuous and
2=Conditional.
This parameter defines the database
address of the first data point to be
associated with the command.
Minimum number of seconds to wait
before polling with this command.
Number of data word values to be
considered by the function.
Swap type code for command:
0=None, 1=Swap words, 2=Swap
words & bytes and 3=swap bytes in
each word.
Address of unit to reach on the data
highway.
Unprotected Write Function
Word address where to start the write
operation.
These fields are not used by the
command. Values entered in these
columns will be ignored.
Description
0=Disabled, 1=Continuous and
2=Conditional.
This parameter defines the database
address of the first data point to be
associated with the command.
Minimum number of seconds to wait
before polling with this command.
Number of data word values to be
considered by the function.
Swap type code for command:
0=None, 1=Swap words, 2=Swap
words & bytes and 3=swap bytes in
each word.
Address of unit to reach on the data
highway.
Word Range Write Command.
PLC-5 file number to be associated
with the command. If a value of -1 is
entered for the parameter, the field
will not be used in the command, and
the default file will be used.
The parameter defines the element in
the file where write operation will start.
If a value of -1 is entered for the
parameter, the field will not be used in
the command, and the default
element will be used.
This parameter defines the sub-
element to be used with the
command. Refer to the AB
documentation for a list of valid sub-
element codes. If the value is set to -
1, the default sub-element number
will be used.
This field is not used by the
command. Values entered in this
column will be ignored.
Parameter
P1
P2 to P4
Parameter
P1
P2
P3
P4
