6.2 RS-232 Configuration/Debug Port
This port is physically a RJ-45 connection. A RJ-45 to DB-9 pigtail cable is shipped with
the module. This port permits a PC based terminal emulation program to view
configuration and status data in the module and to control the module. The cable for
communications on this port is shown below:
ProSoft Technology, Inc.
MVI69-DFCM User Manual
June 24, 2004
MVI69-DFCM Configuration/Debug Port Cable MVI69-DFCM Configuration/Debug Port Cable
DB-9 Male DB-9 Male
RxD RxD
2 2
TxD TxD 3 3
COM COM 5 5
Cable Connections
RS-232 Host RS-232 Host
TxD TxD
RxD RxD
COM COM
