I/O extension module (22-pin IOC_MB)

This connector is for the CGAEX extension module.

P4R8T IOC_MB Connector

10. Optional modem connector (10-1 pin MDC)

This interface connects to the JP2 connector in the optional modem

module.

P4R8T MDC Connector

P4R8T

GAME

COM1

CGAEX

IOC_DC

MDC

PHONE

GND

AC_SYNC

+3VSB

AC_SDIN1

AC_RST#

GND

AC_SDOUT

MDC_BITCLK
