Asus Terminator 2 User Manual page 46

Adjusting the volume settings
1. After rebooting the system, click
on the volume control icon on the
Windows ®
Volume Control window.
2. Click the Volume Control
Advanced button. The Advanced
Controls for Volume Control
window appears.
To achieve 6-channel audio
capability when playing DVDs,
check the boxes opposite AC3
SPDIF and PCM SPDIF.
Click Close.
Adjusting the microphone settings
1. Click on the Microphone Advanced
button to display the Advanced
Controls for Microphone window.
2. Check the box opposite Mic2
Select to enable the front panel
microphone.
3. Click Close for the new settings to
take effect.
The rear panel Mic port (pink) is automatically disabled when you
enable the front panel Mic port. Only one Mic port works at a time.
46
taskbar to display the
Chapter 3: Starting up
