2.6 Installing a DIMM

The motherboard comes with two Double Data Rate (DDR) Dual Inline
Memory Module (DIMM) sockets. These sockets support up to 2GB
system memory using unbuffered non-ECC PC3200/2700/2100 DIMMs.

2.6.1 Memory configurations

You may install 64MB, 128MB, 256MB, 512MB, and 1GB DDR DIMMs into
the DIMM sockets.
Obtain DDR DIMMs only from ASUS qualified vendors. Refer to the
table below. Visit the ASUS website (www.asus.com) for the latest
Qualified Vendors List.
Qualified DDR400 vendors list
This table lists the memory modules that have been tested and qualified
for use with this motherboard.
Size Vendor
256MB MICRON
256MB PSC
256MB TwinMOS
256MB SAMSUNG
256MB SAMSUNG
256MB Kingston
256MB Transcend
256MB CORSAIR
256MB Infineon
•
•
•
24
Part Number
MT8VDDT3264AG-40BC4
AL5D8B53T-5B1K
M2G9108AIATT9F081AADT
M368L3223DTM-CC4
M368L3223DTM-CCC
KVR400X64C25/256
TS32MLD64V4F3
CMX256A-3500C2PT
HYS64D32300GU-5-B
Install only identical (the same type and size) DDR DIMM in
DIMM_A and DIMM_B.
Always install DIMMs with the same CAS latency. For optimum
compatibility, it is recommended that you obtain memory modules
from the same vendor.
This motherboard only supports x4, x8, x16 chips/per module DDR
DIMMs.
Chip Brand Chip Number
MICRON 46V32M8
PSC A2S56D30BTP
TwinMOS TMD7608F8E50D
SAMSUNG K4H560838D-TCC4
SAMSUNG K4H560838D-TCCC
Winbond W9425088H-5
MOSEL V58C2256804SAT5
–– ––
Infineon HYB25D256800BT-5
Chapter 2: Basic installation
