2.3 Removing the cover

To remove the cover:
1. On the rear panel, locate the
three screws that secure the
cover to the chassis.
2. Use a Phillips (cross) screw
driver to remove the cover
screws. Keep the screws for
later use.
3. Pull the cover slightly toward
the rear panel until the side tabs
are disengaged from the
chassis.
4. Lift the cover, then set aside.
ASUS Terminator 2 barebone system
