Vista VSBCMC6LED Instruction Manual

VSBCMC6LED(Colour/Monochrome) VSBMC6LED(Monochrome)
Thank you for choosing this high quality camera, before attempting to connect or operate this product, please
read and follow these instructions
General
These CCD video cameras employ a 1/3" CCD solid-state imaging device, which provide high reliability.
These bullet cameras can be easily installed in both internal and external locations along with its very low
current consumption of 140mA the camera is not only simple to install but achieves an excellent reliability
record.
Features
1. High quality picture.
2. Indoors or out-door use.
3. Long life and high reliability.
SPECIFICATION
Image sensor
Number of Pixel
Resolution
Min. Illumination
S/N Ratio
Electronic Shutter
White Balance
Video Output
Standard Board Lens
Lens Angle
Power Source
Current Consumption
Operating Temp
Storage Temp
IR LED
IR LED wavelewngth
IR LED half angle
Dimension (mm)
Box Dims
Weight
Weight boxed
Mounting Bracket

INSTRUCTION MANUAL

VSBMC6LED
1/3"Monochrome CCD
500(H) x 582(V) <CCIR>
420TV lines
More than 50dB
N/A
120mA (LED Off) & 180mA (LED On)
1/3" Colour/Monochrome Ex-View CCD
500(H) x 582(V) <PAL>
0Lux (IR LED ON)
1/50 to 1/100,000 sec.
1.0Vp-p composite, 75Ω
6mm / F2.0
32° (V) 42° (H)
DC12V+ 10%
-10°C ~ +40°C
-20°C ~ +60°C
6 Unit IR LED up to 5m
850nm
± 15 degree
40Ø x 110(H) mm
70(W) x 70(L) x 142(H)
329g incl. bracket
381g
40(W) x 75(H)
VSBCMC6LED
380 TV lines
More than 45dB
Auto white balance
