ALUDRA user manual
Serial Port3 IRQ [11]
Use the Serial Port3 IRQ option to select the interrupt address for serial port 3.
10
11
Select RS232 or RS485/RS422 [RS/232]
Use the Select RS232 or RS485/RS422 option to select the Serial Port 3 signalling
mode.
RS232
RS422/RS485
Serial Port4 Address [2E8]
Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
Disabled
3E8
2E8
2F0
2E0
Serial Port4 IRQ [10]
Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
10
11
90
Serial port 3 IRQ address is 10
D Serial port 3 IRQ address is 11
EFAULT
D Serial Port 2 signaling mode is RS-232
EFAULT
Serial Port 2 signaling mode is RS-422 or RS-485
No base address is assigned to serial port 3
Serial port 4 I/O port address is 3E8
D Serial port 4 I/O port address is 2E8
EFAULT
Serial port 4 I/O port address is 2F0
Serial port 4 I/O port address is 2E0
D Serial port 4 IRQ address is 10
EFAULT
Serial port 4 IRQ address is 11
