External Peripheral Interface Connection

An RJ-45 Ethernet cable connector can be connected to the external peripheral interface
connectors.
To install this device, connect the corresponding cable connector from the actual device
to the corresponding ALUDRA external peripheral interface connector making sure the
pins are properly aligned.
LAN Connection (Single Connector)
There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection
to an external network. To connect a LAN cable with an RJ-45 connector, please follow
the instructions below.
1 Locate the RJ-45 connectors. The locations of the USB connectors are shown in
Connectors, page 31.
2 Align the connectors. Align the RJ-45 connector on the LAN cable with one of the
RJ-45 connectors on the ALUDRA. See Figure 60.
3 Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable
RJ-45 connector into the on-board RJ-45 connector.
76
Figure 60: LAN Connection
