AUMA SAREx 07.2 – SAREx 16.2 Operation Instructions Manual page 48

Spare parts
Information: Please state device type and our order number (see name plate) when ordering spare parts. Only
original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts
AUMA from any liability. Delivered spare parts may slightly vary from the representation in these instructions.
Ref. Designation
no.
002.0 Bearing flange
003.0 Hollow shaft
005.0 Drive shaft
005.1 Motor coupling
005.3 Manual drive coupling
009.0 Planetary gearing for manual drive
017.0 Torque lever
018.0 Gear segment
019.0 Crown wheel
022.0 Drive pinion II for torque switching
023.0 Output drive wheel for limit switching
024.0 Drive wheel for limit switching
025.0 Locking plate
058.0 Wire for protective earth
070.0 Motor (VD motor incl. ref. no. 079.0)
079.0 Planetary gearing for motor drive
(SA/SAR 07.2 SA/SAR 16.2 for VD
motor)
155.0 Reduction gearing
500.0 Cover
501.0 Ex plug/socket connector with screw-
type terminals (KP, KPH)
501.1 Screw Control terminal
501.2 Washer Control terminal
501.3 Screw Power terminal
501.4 Washer Power terminal
502.1 Pin carrier (without pins)
505.0 Pin for controls
506.0 Pin for motor
507.0 Cover for electrical connection
511.0 Threaded plug
514.0 Output drive type A (without stem nut)
514.1 Axial needle roller bearing
516.0 Output drive type D
48
SAEx 07.2
Type Ref. Designation
no.
Sub-assembly 535.1 Snap ring
Sub-assembly 539.0 Screw plug
Sub-assembly 542.0 Handwheel with ball handle
549.0 Output drive type B1/B3/B4/E
549.1 Output drive sleeve B1/B3/B4/C
Sub-assembly 553.0 Mechanical position indicator
Sub-assembly 554.0 Socket carrier for motor plug/socket
connector with cable harness
556.0 Potentiometer for position transmitter
556.1 Potentiometer without slip clutch
Sub-assembly 557.0 Heater
Sub-assembly 558.0 Blinker transmitter including pins at
wires (without impulse disc and insula-
tion plate)
Sub-assembly 559.0-1 Control unit with torque switching
heads and switches
Sub-assembly 559.0-2 Control unit with magnetic limit and
torque transmitter (MWG) for Non-in-
trusive version in combination with
AUMATIC integral controls
Sub-assembly 560.0-1 Switch stack for direction OPEN
Sub-assembly 560.0-2 Switch stack for direction CLOSE
Sub-assembly 560.1 Switch for limit/torque
Sub-assembly 560.2 Switch case
Sub-assembly 566.0 Position transmitter EWG/RWG
Sub-assembly 566.1 Potentiometer for RWG without slip
clutch
566.2 Position transmitter board for RWG
566.3 Wires for RWG
567.1 Slip clutch for potentiometer
568.1 Stem protection tube (without cap)
Sub-assembly 568.2 Cap for stem protection tube
Sub-assembly 568.3 V-seal
Sub-assembly 575.1 Stem nut type A
Sub-assembly 583.0 Motor coupling on motor shaft
Sub-assembly 583.1 Pin for motor coupling
Sub-assembly 584.0 Retaining spring for motor coupling
Sub-assembly 7003 Radial seal for output drive type A with
ISO
Sub-assembly S1 Seal kit, small
S2 Seal kit, large
SAEx 16.2 / SAREx 07.2 SAREx 16.2
Type
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Sub-assembly
Set
Set
