Positioning The Instrument; Calibration Curves - Check-line RH6 Manual

1.0

POSITIONING THE INSTRUMENT

Insert the sword-sensor into the stack for only approx. 10 cm, and push it a few
more centimetres into the stack every 10 seconds. Let your RH6 adequately adjust
to the material (at least 5 minutes) before you start to measure, particularly when
the material pile was stored at a different temperature than the device. When
removing the sword-shaped sensor please ensure that there is no up or down
movement, because this could deform the sensor. For heavy stacks and rolls please
use the optionally available sword sensor holder and the tool for removing the sword
sensor holder.
1.1 Measurement
To switch on the instrument, press the
seconds.
After showing the logo, the measuring window opens and
the current temperature and moisture value is displayed.
In the type selection menu the calibration curves can be
changed by pressing or . The calibration curves saved
in the device can be found in the following list.
2.0

CALIBRATION CURVES

calibration curve description
rel. humidity rel. humidity of air
dew point dew point
abs. humidity abs. humidity of air
equilibrium moisture
EMC wood
content of wood
absolute moisture
aH Kraftliner %
Kraftliner paper
absolute moisture
aH Testliner %
Testliner paper
© Electromatic Equipment Co., Inc.
key for 3
unit measuring range
%rh 0 to 100%
55 to +60° C
° C resp. ° F resp.
-67 to 140° F
g/m³ 0 to 130 g/m³
2 to 30%
%EMC
(wood moisture)
% 5 to 15%
% 3 to 12,2%
-2-
