System Hardware and Installation

RESETTING DEFAULT CONFIGURATION SETTINGS

The Tunnel Master
these settings before configuring your own settings. The following procedure
shows how to erase the current settings.
NOTE:
To erase all configuration settings, follow these steps:
1 Remove the battery from the Main CPU PCB.
2 On the main CPU board, set DIP switch 6 to the ON position.
3 On the main CPU board, press and hold the reset switch (SW1) for about
30 seconds, and then release the reset button.
Wait for the display to come back up. All settings are erased.
4 Put the battery back into its socket.
5 On the main CPU board, return or set the DIP switch 6 to the OFF position.
The Tunnel Master

See "DIP Switch Settings" on page 40.

Rules for Installation

Before you begin, please read this entire manual.

Install permanent connections in accordance with local building/fire
codes, all Federal, State, and Local codes.

All wiring must meet the National Electrical Code ANSI/NFPA 70.

Canadian users must also comply with the Canadian Electrical Code CEC,
CAN/CSA C22.1 Pt. 1.

High-voltage (AC) and low-voltage (DC) must not be combined in a
common conduit, junction box, or wire trough.

Power for the Tunnel Master
dedicated UPS, as supplied by ICS.

The Tunnel Master
grounded.

Test connections in the manual override position prior to system start-up.

Check through packing materials for manuals, cables, connectors, etc.
before disposing of cartons.
14
Tunnel Master

Jr. is delivered with pre-loaded settings. You can erase
ICS recommends a complete, first-time erase using DIP switch 6, as
described below.

Jr.is ready to begin your configuration process.

Jr. and any peripherals must come from the

Jr. and peripheral equipment must be properly

Jr. User Manual—Version 3.0
January 2016
