CHAPTER 2:

SYSTEM HARDWARE AND INSTALLATION

This chapter includes preliminary steps to take for a new Tunnel Master
installation. This chapter provides a brief description of the hardware
components and their function and the tunnel settings wiring diagrams.
The Tunnel Master
environments and hard use of a busy car wash.

Audience

This chapter is intended for installation technicians and electricians. A
thorough understanding of electrical wiring, installation, codes and safety
protocols is required. Additionally, some familiarity with car wash tunnel
equipment and installation is recommended. No prior experience with the
Tunnel Master

Purpose

This installation guide is provided to assist you in installing the Tunnel
Master
electrician prior to the installation of conduit and wiring to ensure the Tunnel
Master
Faulty installations are the major cause of system malfunctions. The Tunnel
Master
ensure its reliability and proper operation.
!
NOTE:
January 2016
Tunnel Master

Jr. hardware is designed to withstand the harsh

Jr. is required.

Jr. controller relay box. This guide should be supplied to the

Jr. system is installed properly.

Jr. system must be installed exactly as described in this manual to
WARNING: Failure to properly install the Tunnel Master
system will void the warranty and could result in serious
injury or death.
