Digital Networks DECserver ConX4 Installation And User Manual page 27

Step Action
2 If your DECserver is already booted and running DECserver Network Access
Software skip to section B:
A) Apply power. When self-test completes the following will be displayed on the
console:
Local>
Local -901- Initializing DECserver ConX4
8E-A2-3B FW V2.6 HW 1.0
. . .
Proceed to Step 3.
B.) From the DECserver Network Access Server "Local>" prompt type the
following:
Local> show server
Network Access SW V3.1 BL01 for ConX4 ROM 2.6 Uptime:
0 00:02:42
...
3 In both of the previous examples the firmware version was shown to be V2.6.
Procedure for Upgrading your DECserver ConX
Step Action
1 Make a Bootp/TFTP, TFTP, or MOP load host available on the same LAN segment as
the DECserver.
2 Obtain firmware update image and place in the load area. Make sure to use the
appropriate filename (ie MNBOOT.SYS for MOP Server or MNBOOT for TFTP).
If you are using a BOOTP/TFTP server, such as Access Server Loader, be sure to
configure it properly with the DECServer MAC address, IP-Address, IP-Mask, Device
Name and the firmware update file name.
00-10-64-
4
Firmware:
Installation 2-13
