Digital Networks DECserver ConX4 Installation And User Manual page 13

Table 1-1: Controls, Indicators, and Connectors
Item
1 Power Indicator
2 System OK Indicator
3 Network OK Indicator
4 10/100 Connector
5 Ethernet MAC Address
6 Port Activity Indicators
7 Port Connectors (RJ45)
8 Reset Switch
9 Power Connector
Description
Turns on when power is supplied to the DECserver
4
ConX through a power adapter or through Power-over-
Ethernet (PoE).
Turns on when the DECserver ConX
completes the ROM-based self-tests.
Turns on when you connect the DECserver ConX
properly terminated network. Blinks while the ConX
loads or dumps software.
Connects the DECserver ConX
The MAC address of the DECserver ConX
Consists of four LEDs, each corresponding to a device
port on the DECserver ConX
turns on when the associated port is in use. These LEDs
blink when port activity is detected and continue blinking
until port data transfer stops. The LEDs are also used to
indicate status during the power-on selftest.
Connects the peripheral devices to the DECserver
4
ConX .
Resets the DECserver ConX
characteristics.
Connects the power source to the standalone DECserver
4
ConX .
4
successfully
4
to a
4
to the network.
4
.
4
. Each port activity LED
4
to the factory-default
Overview 1-5
