To facilitate mounting the DECserver ConX
inet, the spacing of the screw holes on the Wallmount bracket are identi-
NOTE
cal the spacing on the cabinet rails.
Figure 2-3: Standalone Configuration – 10/100BASE-T Connection
Table 2-1: Description of Standalone Configuration (10/100BASE-T)
Callout Number
1
2
3
2-4 Installation
Description
RJ45 Cable to Ethernet
Serial Port Cable
Power Cable and International Power Supply
4
on a standard 19-inch cab-
