RuggedCom RuggedServer RS416 Specification Sheet page 8

Fiber Optical Specifications (Ethernet Ports)
Parameter
10BaseFL
Mode Multimode
Connectors ST
Typical Dist. (km)
Optical Wavelength (nm) 820
Cable Size Core/Cladding (um) 50 or 62.5/125
Tx Power (dBm) -34.4
Rx Sensitivity (dBm) -8.2
Typical Budget
Longer segment lengths dependent on fiber specifications. Consult factory for further details.
www.RuggedCom.com
Modular 16-Port Serial Device Server with Integrated Managed Ethernet Switch
Fiber Specifications and Dimensions
Fiber Port Type
Multimode
MTRJ / ST / SC
2 2 20
1310
50 or 62.5/125
-15.7 -15.5
-33.5 -32
22 17 16.5
100BaseFX
Singlemode
LC / SC
50 90
1310
8 or 9/125
-2.5 2.5
-37 -39
34.5 41.5
RuggedServer™ RS416
Serial Fiber Specifications
Parameter Fiber Port Type
Connector
Maximum Distance
Tx Power -13.5 dBm Aug
Rx Sensitivity -28.5 dBm Aug
Optical Budget
RuggedServer™ RS416
ST
5km
15dB
8
