RuggedCom RuggedSwitch RS940G Specification Sheet page 7

Fiber Specifications and Mechanical Drawing
Parameter
Mode
Connector
Typical Dist.
Optical Wavelength (nm)
Cable SizeCore/Cladding (um)
TX Power (Min/Max) (dBm)
RX Sensitivity (dBm)
RX Saturation (dBm)
Typical Budget (dB)
www.RuggedCom.com
Fiber Optical Specifications
Multimode Singlemode
LC, LC-SFP SC, LC, LC-SFP
500m 10km
850 1310
50/125 or 62.5/125 8/125 or 9/125
-9.5/-4 -9/-3
-20 -22
0 -3
14 17
RuggedSwitch
8-Port Managed Gigabit Ethernet Switch, 128-bit Encryption
Fiber Port Type
Singlemode
SC, LC, LC-SFP
25km
1310
8/125 or 9/125
-7 / 3
-26
-3
19
RS940G
®
Singlemode
LC-SFP
70km
1550
8/125 or 9/125
0 / 5
-23
0
25
RuggedSwitch RS940G
®
7
