IRVING STORAGE BENCH
For assistance with assembly contact.
Southern Enterprises Inc.
Assembly Instructions
customer service 1-800-633-5096
service@seidal.com
www.seidal.com
PO:13008
Top supports up to 250 lb.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BC961400TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Southern Enterprises BC961400TX

  • Page 1 BC961400TX IRVING STORAGE BENCH For assistance with assembly contact. Southern Enterprises Inc. Assembly Instructions customer service 1-800-633-5096 service@seidal.com www.seidal.com PO:13008 Top supports up to 250 lb.
  • Page 2 BC961400TX IRVING STORAGE BENCH Parts List Please review all parts and hardware before disposing of any packaging. Call customer service if missing hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. 3PCS 2PCS 2PCS short shelf...
  • Page 3 28PCS 12PCS glue wood dowel short bolt 1/4” x 3/8” 6PCS 2PCS 8PCS medium bolt 1/4” x 3/4” long bolt 1/4” x 7/8” lock washer 4PCS end cap allen wrench Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
  • Page 4 BC961400TX IRVING STORAGE BENCH Assembly Instructions Attach short shelf (1) to long shelf (2) as shown. Note: Make sure all the finished edges on the shelves are facing the same direction. Figure 1 Attach side panel (3) to the assembled shelf using glue (A) and wood dowel (B).
  • Page 5 Using glue (A) and wood dowel (B); attach the assembled parts to bottom panel (4) as shown. Note: Make sure the finished edge on the bottom panel is facing the same direction as the finished edges on the rest of the unit. Figure 3 Slide back panel (6) along the grooves of side panels (3).
  • Page 6 Attach top panel (5) to the assembled unit using glue (A) and wood dowel (B) as shown. Figure 5 Attach short stretchers (7) to bottom stretchers (9) using short bolts (C). Tighten with allen wrench (H) Note: Do not fully tighten the bolts until figure 8 is complete.
  • Page 7 Attach top stretchers (8) and assembled bottom panel to side panels (10) using lock washers (F) and short bolts (C) as shown. Tighten with allen wrench (H). Figure 7 Attach the assembled metal base to cushion (11) using medium bolts (D). Then, attach end caps (G) to metal base as shown.
  • Page 8 Secure the hutch with metal base using long bolts (E) as shown. Tighten using allen wrench (H). Your Irving storage bench is now complete. Figure 9 Customer Service 1-800-633-5096 service@seidal.com Southern Enterprises, Inc. 600 Freeport Parkway, Suite 200 Coppell, Texas 75019...
  • Page 9: Parts Replacement Form

    90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
