[Spectrum] Measure Menu

Key Sequence: Measurements > Spectrum
For a shortcut to the active measurement or this main menu if no measurement is active,
press the touch screen where the words IA (Spectrum) are located, in the upper right corner of
the display.
Measure
Power and
Bandwidth
Masks and
C/I
AM/FM
Demod
Generator
IQ Waveform
Capture
Coverage
Mapping
All Measurements Off
Figure 3-35. IA Spectrum Measure Menu
3-42
Power and Bandwidth: Opens the
Masks and C/I: Opens the
AM/FM Demod: Opens the
Generator: Opens the
submenu key is present only in spectrum analyzers with a Tracking
Generator option.
IQ Waveform Capture: Opens the
(Option 24)" on page
Option 24 is installed.
Coverage Mapping: Opens the
on page 3-61. This submenu key is present only when Option 431 is
installed.
All Measurements Off: Turns off all measurements.
