Channel Scanner (Option 27)
4-8

Scanner Menu

Key Sequence: Scanner
Scanner
Scan
Channels
Scan
Frequencies
Scan
Custom List
Scan
Script Master
Figure 4-2. Channel Scanner Scanner Menu

Channel Scan Menu

Key Sequence: Scanner > Scan Channels > Scan Channels
Channel Scan
Signal Standard
Channel
50
Number of Channels
20
Channel Step Size
1
Back
Figure 4-3. Channel Scanner Channel Scan Menu
Spectrum Analyzer MG
Scan Channels: Opens the
Scan Frequencies: Opens the
Scan Custom List Frequencies: Opens the
on page 4-11.
Scan Script Master: If no script list is currently in use, the Select Script
Master Scan Setup File dialog opens to select a script file for measurement
use. Select a file and press Enter. The Scan Script Master menu is listed.
If a script file has been selected or in use, then the
on page 4-9 is listed. The submenu keys allow you to import a new file or
change any parameter set in the Script Master file created in Master Software
Tools.
Signal Standard: Opens the Signal Standards list dialog to select a signal
standard.
Channel: Opens the Channel Editor list to set a valid band in the selected
signal standard.
Number of Channels: Sets the number of channels to be displayed. From 1
to 20 channels can be displayed.
Channel Step Size: Sets the number of channels to skip between displayed
channels.
Back: Returns to the
PN: 10580-00349 Rev. M
"Channel Scan Menu" on page
"Freq Scan Menu" on page
"Scanner Menu" on page
4-8 Scanner Menu
4-7.
4-8.
"Custom Scan Menu"
"Scan Script Master Menu"
4-7.
4-7
