- Page 1 User Manual AtlonA 2X1 VGA W/ STEREO AUDIO (AUTOMATIC) SWITCHER AT-APC21A www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515...
-
Page 2: Table Of Contents
4. Specification ..........5. Panel Descriptions ..........5.1 Front Panel ..........5.2 Rear Panel ..........6. Connection and Installation ..........7. Safety Information ..........8. Warranty ..........9. Atlona Product Registration ..........www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515... -
Page 3: Introduction
INTRODUCTION Atlona Technologies’ AT-APC21A is an automatic VGA Switcher with 2 inputs to 1 output with Stereo Audio. This unit fea- tures multiple switching capabilities including automatic selection of the active channel to eliminate the need of manual control. To switch over to another channel, simply turn on the other device or use external control button. A manual control button is also available to switch between desired channels. -
Page 4: Panel Descriptions
4. Channel 2 VGA Input 5. Channel 2 Audio Input 2. Rear Panel 1. External Control Button 2. VGA Output: Connect to VGA monitor/projector 3. Audio Output: Connect to speaker 4. Power Adapter (Spare) www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515... -
Page 5: Connection And Installation
CONNECTION AND INSTALLATION 1. Connect the desired VGA monitor and speaker to the output of the AT-APC21A and two VGA + Audio sources to the corresponding inputs of the AT-APC21A via VGA and audio cables. 2. The LED display on the switch panel will turn on when the switch detects a VGA signal (Blue: Channel 1, Green: Chan- nel 2) The External control button is available for manual switching. -
Page 6: Safety Information
Use only accessories recommended by ATLONA to avoid fire, shock or other Do not modify the wall plug. hazards. Doing so will void the warranty and safety features. -
Page 7: Warranty
Product, or repair or replacement of the Product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. -
Page 8: Atlona Product Registration
At Atlona, we respect and protect your privacy and assure you that your registration information is completely secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited war- ranty rights. To register go to www.atlona.com/registration www.atlona.com | toll free: 1-877-536-3976...
