12.9 Field settings on the user interface – overview
1st code 2nd Setting name
code
0 User interface setup
00 User permission level
01 Room temperature compensation value
02 Not applicable. Do not change the default value.
03 Status: space heating schedule timer mode (Method 1=1 / Method
2=0)
04 Status: space cooling schedule timer mode (Method 1=1 / Method
2=0)
1 Settings are not applicable
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Not applicable. Do not change the default value.
03 Not applicable. Do not change the default value.
2 Automatic setback function
00 Status: setback operation
01 Setback operation start time
02 Setback operation stop time
3 Weather dependent setpoint
00 Low ambient temperature (Lo_A)
01 High ambient temperature (Hi_A)
02 Setpoint at low ambient temperature (Lo_Ti)
03 Setpoint at high ambient temperature (Hi_Ti)
4 Settings are not applicable
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Not applicable. Do not change the default value.
5 Automatic setback and disinfection setpoint
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Leaving water setback temperature
03 Room setback temperature
04 Not applicable. Do not change the default value.
6 Option setup
01 Optional room thermostat installed
7 Option setup
00 Forced pump operation
8 Option setup
00 User interface temperature control
01 Not applicable. Do not change the default value.
03 Not applicable. Do not change the default value.
04 Status: freeze-up prevention
9 Automatic temperature compensation
00 Leaving water temperature compensation value (heating)
01 Leaving water thermistor auto corrective function
02 Not applicable. Do not change the default value.
03 Leaving water temperature compensation value (cooling)
04 Not applicable. Do not change the default value.
A Option setup
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Allowable undershoot value for return water
03 Allowable overshoot value for leaving water
b Settings are not applicable
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Not applicable. Do not change the default value.
03 Not applicable. Do not change the default value.
04 Not applicable. Do not change the default value.
C Leaving water temperature limits
00 Setpoint: heating leaving water maximum temperature
01 Setpoint: heating leaving water minimum temperature
02 Setpoint: cooling leaving water maximum temperature
03 Setpoint: cooling leaving water minimum temperature
04 Not applicable. Do not change the default value.
Installer and user reference guide
52
Date Value Date Value Default Range Step Unit
value
2 2~3 1
0 –5~5 0.5
1 — —
1 (ON) 0/1 —
1 (ON) 0/1 —
1 — —
1:00 — —
0 — —
15:00 — —
1 (ON) 0/1 —
23:00 0:00~23:00 1:00
5:00 0:00~23:00 1:00
–10 –20~5 1
15 10~20 1
40 25~80 1
25 –20~5 1
1 — —
Fri — —
23:00 — —
70 — —
10 — —
5 0~10 1
18 17~23 1
1 — —
0 0~2 —
1 (ON) 0/1 —
0 (OFF) 0/1 —
1 — —
1 — —
0 0~2 1
0 –2~2 0.2
1 (ON) 0/1 1
0 — —
0 –2~2 0.2
0 — —
0 — —
0 — —
5 0~15 1
3 1~5 0.5
35 — —
45 — —
1 — —
70 — —
70 — —
50 37~50 1
25 25~37 1
20 18~22 1
5 Q (a) ~18 1
0 — —
