16 Operation
INFORMATION
Space cooling based on temperature setpoint is enabled
by default, so only temperature shifts are possible (no ON/
OFF instruction).
Quiet mode
See "To program quiet mode" on
Switch the mode on or off at a scheduled time. Four actions can be
programmed per day. These actions are repeated daily.
To program space cooling
5 sec
INFORMATION
Press to return to previous steps in the programming
procedure without saving modified settings.
1 Press to enter the programming/consulting mode.
2 Select the operation mode you would like to program using
and .
Result: The actual mode is blinking.
3 Press to confirm the selected mode.
Result: The time is blinking.
4 Consult the action(s) using
5 Hold down for 5 seconds to program the detailed actions.
Result: The first programmed action appears.
6 Select the action number you would like to program or to modify
using .
7 Set the correct action time using
8 Set the leaving water temperature using
9 Set the room temperature using
Installer and user reference guide
62
page 63.
5 sec
and .
and .
and
and .
10 Select using
controller off.
11 Repeat this procedure to program the other actions.
Result: When all actions have been programmed, make sure
that the display shows the highest action number you would like
to save.
12 Press for 5 seconds to store the programmed actions.
Result: If is pressed when action number 3 is displayed,
actions 1, 2 and 3 are stored, but action 4 is deleted. You
automatically return to step 6. Press
to previous steps in this procedure and finally return to normal
operation.
13 You automatically return to step 6; start again to program the
following day.
To program space heating
5 sec
.
to switch cooling and the remote
several times to return
5 sec
SERHQ020~032BAW1 + SEHVX20~64BAW
Split packaged air-cooled water chiller
4P508020-1B – 2018.04
