ROBINHOOD Slimline 600 Installation Instruction

RANGEHOOD
I N S T A L L A T I O N
Note: Generic model is shown.
Actual product may differ.
PLEASE READ THE ENTIRE INSTRUCTION BEFORE INSTALLING THE RANGEHOOD
W A L L M O U N T I N G
MODEL 900
817
104
290
18
732
523
For rear
to
ducting cut hole
MODEL 600
932
to suit duct size.
Dimensions
shown
are for Uniduct
STOVE
HEIGHT
U N D E R C U P B O A R D
For top ducting cut hole
to suit duct size.
Dimensions shown are
for Uniduct
Underside View of Cupboard
I N S T R U C T I O N
If using Uniduct
cut outside wall
hole
90 x 290mm
600-800mm
For Gas 650-800mm
STOVE
900mm
HEIGHT
900
M O U N T I N G
Drill
523 (600)
5mm
817 (900)
holes
95
290
Wall
S I D E W A L L
M O U N T I N G
DRILL HOLES AND MOUNT TWO
CUP WASHERS AS SHOWN
REFER WALL MOUNTING DETAIL
2.4M
CEILING
HEIGHT
DOOR EXTENSION
CONCEALS TOP OF
SL Models Only
RANGEHOOD
(SL Models Only)
SL Models Only
INNER CUPBOARD MOUNTED
DRILL FOUR HOLES AT
POSITIONS INDICATED,
REFER UNDER CUPBOARD
MOUNTING
W A L L M O U N T I N G
FOR INSTALLATION OF PLUGS
FOR WALL MOUNTING
1. Mark location of holes as per
installation instructions.
2. Drill 8mm hole.
Note: Do not use a screw driver
to punch a hole in the base
material.
3. Insert Plastic Toggle and tap
with a hammer to ensure it is
flush with the base material.
4. Place supplied screw through
cup washer. Insert into toggle
and tighten.
M O U N T I N G
SCREW
THROUGH
SIDES USING
HOLE POSITIONS
INDICATED
REMOVE FILTERS
O P T I O N S
MOUNTING TO REAR WALL
2
1
IF UNIT COMES WITH
1
KNOCK-OUT - REMOVE
SWIVEL POWER OUTLET TO TOP
MOUNTING UNDER
CUPBOARDS
295mm
72mm
SWIVEL POWER OUTLET TO TOP.
CUT HOLE IN CABINET TO SUIT
D E T A I L S
1
HOOK RANGEHOOD ONTO CUP
WASHERS, FIX TOP BRACKET
2
(BRACKET IS PRE-FITTED ON
RANGEHOOD)
SCREW INTO PLASTIC INSERTS
FROM INSIDE CUPBOARD
NOT FOR USE
IN SOLID WALLS
FOR SOLID WALLS
USE APPROPRIATE
WALL PLUGS
103767 Issue A
ECN:2557
