Power Supply for Camera

Power Connection: Connect the 3S-6S (DC11.2V-DC25V) positive wire to camera Pin 2(+), and negative
wire to camera Pin 1(GND-).
Don't operate the camera immediately after power-on. After 15s self-checking, the camera will acquire the
usual parameters for mapping, and it can meet he requirements of most missions. You also could set up the
parameters by the menu button on the top of the camera.
Set Camera Language
1. Check that [Enter] is selected on the screen, then press
2. Set [Language], then press
3. Check that [Enter] is selected, then press
FOXTECH Map-01 Mapping Camera
.
.
Select items: / / / / /
Set:
on the control wheel.
