- Page 1 Intel® Storage System SSR212MA Spares / Parts List & Configuration Guide A reference guide to assist customers in ordering the necessary components to configure the Intel® Storage System SSR212MA Rev 1.7 Subject to Change August 2006...
-
Page 2: Table Of Contents
Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice. -
Page 3: Production Configurations
1 x Intel Xeon™ Processor 2.8 GHz • 2x Intel RAID Controller SRCS28X, w/ Battery Backup Units (BBU) • 12 x Intel hard disk drive carriers (for use with Serial ATA drives) • 12x hard disk drive labels • 12x Serial ATA hard disk drive cable •... -
Page 4: Production System Codes
IMPORTANT: Intel Storage System SSR212MA memory upgrade guideline Intel® Storage System SSR212MA embedded operating system supports a maximum of 4 GB of system memory. See table below for recommended system memory based on drive quantities and drive capacity. Required minimum (for functionality): 200 MB + 200 MB per 1 TB of raw disk capacity + 128 MB per RAID 5 array. -
Page 5: Production Hardware Spares (Field Replaceable Units)
Existing Production Spares & Accessories Product Code MM # Description SE7520JR2ATAD2 876355 00735858167376 Intel Server Board SE7520JR2 Boxed Board - DDR2 SATA (min order quanity = 5) SRCS28X 866296 00735858171625 Intel RAID Controller SRCS28X (two ship with each SSR212MA system). -
Page 6: Features And Benefits
Simplify Deployment and Administration The Intel Storage System SSR212MA comes standard with a full lineup of compelling software features that simplify storage management and lower administrative costs. From a central console, you can configure and manage your SAN system using an intuitive graphical interface. - Page 7 Fibre Channel drives. Support for RAID 0, 1, 5, 10 or 50. Flexibility for optimizing performance and fault tolerance. ® ™ Intel Xeon Processor Processing performance to meet the demanding needs of storage virtualization. Solid state Disk on Module (DOM) boot device, Provides redundancy capability for SAN management software.
-
Page 8: Hardware Specifications
Intel® Xeon™ processor 2.80 GHz with 1 MB L2 cache. Memory Capacity Expandable to 16 GB maximum. NOTE: Please see memory expansion recommendations in section 1.2 of the Intel Storage System SSR212MA Technical Product Specification. Memory Type Synchronous Dynamic Random Access Memory (SDRAM), DDR2-400, Registered, ECC. - Page 9 Power supply enclosure contains a 60 mm fan for cooling and runs whenever AC power applied. Power Configuration 500 W continuous, 1+1 redundant power supplies. Intel Storage System SSR212MA ships with one 500W power supply. Max AC input current 7.2 Amperes at 110 Vrms, 3.5 A at 220 Vrms (each power supply).
- Page 10 GB 17625 - (Harmonics) CNCA Certification (China) Intel, the Intel logo, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. THE MARKETING MATERIALS AND CONTENT IN THIS DOCUMENT ARE PROVIDED AS EXAMPLES ONLY FOR ILLUSTRATIVE PURPOSES. YOU ARE RESPONSIBLE FOR DEVELOPING AND VERIFYING YOUR OWN MARKETING MATERIALS AND RELATED CLAIMS.
