Page 1
Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/ Products Intel Order Number: D23738-001...
Page 2
Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of the Intel product could create a situation where personal injury or death may occur.
Safety Information Important Safety Instructions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the ® Intel Server Deployment Toolkit CD and/or at http://support.intel.com/support/ motherboards/server/sb/cs-010770.htm.
Take care to grip with, but not squeeze, the pliers or other tool you use to remove a jumper, or you may bend or break the pins on the board. Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
Disk on Module (DOM) Install Guide The Intel® Storage System SSR212MA ships with a single 512-MB Disk on Module (DOM) installed directly to the server board’s IDE connector. The DOM is a storage device based on flash memory technology, which emulates an ordinary magnetic hard disk drive.
Press in on the palm latch (see letter “B”) and slide the enclosure cover back (see letter “C”) until it stops (about 2 inches). TP01851 Figure 1. Unlatching Enclosure Cover Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
(see letter “B”). Lift the enclosure cover (see letter “C”) to completely remove it from the chassis. TP01827 Figure 2. Removing Enclosure Cover Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
Disk on Module (DOM) Install Guide Remove Processor Air Duct 7. Lift the processor air duct from its location over the processor socket(s). TP01856 Figure 3. Removing Processor Air Duct Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
PCI riser assembly and components on the PCI RAID controller card(s) are not rubbing against the sheet metal of the chassis. TP00879 Figure 4. Removing PCI Riser Assembly from Chassis Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
Disk on Module (DOM) Install Guide Install Replacement DOM 9. Disconnect the power cable from the old DOM (see letter “A” in the following figure) TP01863 Figure 5. Disconnecting Power Cable from DOM. Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
TP01864 Figure 6. Removing Old DOM 11. Install the replacement DOM to the server board’s IDE connector. You should feel it snap into place. TP01865 Figure 7. Installing Replacement DOM Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
Disk on Module (DOM) Install Guide 12. Connect the power cable to the replacement DOM. TP01866 Figure 8. Connecting Power Cable to DOM Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
The latches should lock into position once the PCI riser assembly is seated properly. TP00876 Figure 9. Installing PCI Riser Assembly into Chassis Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
Disk on Module (DOM) Install Guide Install Processor Air Duct 14. Reinstall the processor air duct over the processor on the server board. TP01855 Figure 10. Installing Processor Air Duct Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
16. Re-connect all peripheral devices and the AC power cable. Power up the storage system. 17. Refer to the Intel® Storage System Software User Manual for information on activating the DOM and updating the software. Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
Page 20
Disk on Module (DOM) Install Guide Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA...
