Page 1: Installation Guide
® Intel Storage System SSR316MJ2 Cable Kit (FMJCABLES2) Installation Guide Order Number: D27073-002... - Page 2 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
-
Page 3: Important Safety Instructions
010770.htm. Instrucciones de seguridad importantes Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en http://support.intel.com/support/motherboards/server/sb/CS-010770.htm. ® Intel Storage System SSR316MJ2 Cable Kit... - Page 4 Avoid injury: Lifting the storage system chassis and attaching it to the rack is a two-person job. If needed, use an appropriate lifting device. A fully loaded Intel® Storage System SSR316MJ2 weighs approximately 31.8 kg (70 lbs.). CAUTIONS Temperature: The operating temperature of the storage system, when installed in an equipment rack, must not go below 5°...
-
Page 5: Table Of Contents
Required Tools........................38 Power Down System and Remove Chassis Cover ............... 38 Disconnect Front Panel Cables..................... 39 Remove Fan Assembly Screws .................... 40 Disconnect Fan Cables ......................41 Remove Fan Assembly ......................42 ® Intel Storage System SSR316MJ2 Cable Kit... - Page 6 Connect I C Cables ....................... 44 Install Fan Assembly ......................45 Attach Fan Assembly ......................46 Connect System Fan Cables ....................47 Connect Front Panel Board Cables ..................48 Finishing Up .......................... 49 ® Intel Storage System SSR316MJ2 Cable Kit...
- Page 7 Figure 37. Attaching System Fan Assembly ................. 46 Figure 38. Connecting System Fan Cables ................47 Figure 39. Connecting Front Panel Board Cables ..............48 Figure 40. Installing the Chassis Cover ................49 ® Intel Storage System SSR316MJ2 Cable Kit...
- Page 8 ® Intel Storage System SSR316MJ2 Cable Kit viii...
-
Page 9: About The Cable Kit
About the Cable Kit Enclosed is your new Intel® FMJCABLES2 Cable Kit. This document describes how to install the ® cables included in this kit into the Intel Storage System SSR316MJ2. Kit Contents The FMJCABLES2 Cable Kit consists of the following:... -
Page 10: Sata Cables Installation Procedures
1. Review the safety information and warnings at the beginning of this guide. 2. Power down your Intel® Storage System Console. See letter “A” in Figure 1. 3. Remove both AC power cords from the AC power inputs at the rear of your storage system. -
Page 11: Unseat Hard Disk Drive Carriers
You must later reinstall each drive carrier ® into the same location from which it was removed. See the Intel Storage System SSR316MJ2 Quick Start User’s Guide for details. -
Page 12: Disconnect Front Panel Cables
3. Disconnect the primary IDE cable, labeled J5, from the front panel board. See letter “C” in Figure 3. 4. Disconnect the front panel power connector from the front panel board. See letter “D” in Figure 3. TP01799 Figure 3. Disconnecting Front Panel Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 13: Remove Fan Assembly Screws
Use a Number 1 size Phillips* screwdriver to remove the screw on each side of the system. See letter “A” in Figure 4. These screws hold the system fan assembly in place. See Figure 4. These screws will be re-installed later. TP01800 Figure 4. Removing System Fan Assembly Screws ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 14: Disconnect Fan Cables
2. Disconnect the Fan 4 cable from the server board. See letter “B” in Figure 5. 3. Disconnect the Fan 5 cable from the server board. See letter “C” in Figure 5. TP01801 Figure 5. Disconnecting System Fan Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 15: Remove Fan Assembly And Disconnect Sata Cables
2. Remove the 16 SATA cable connectors from the two SATA Host Bus Adapter cards located inside the chassis at the rear of the system. See letter “B” in Figure 6. TP01802 Figure 6. Removing System Fan Assembly and Disconnecting SATA Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 16: Disconnect I C Cables
See letter “A” in the circled area of Figure 7. 3. Disconnect the I C cable that is labeled JP6 from the backplane board. See letter “B” in the circled area of Figure 7. TP01804 Figure 7. Disconnecting I C Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 17: Disconnect Power Distribution Module Cables
SATA Cables Installation Procedures Disconnect Power Distribution Module Cables Disconnect the two 12-pin power distribution module connectors from the backplane board. See letter “A” in Figure 8. TP01805 Figure 8. Disconnecting Power Distribution Module Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 18: Cut Sata Cable Ties
2. Cut the plastic cable ties that bundle the SATA cables. See letter “A” in Figure 9. Use caution so you do not cut the SATA cables. TP01803 Figure 9. Cutting SATA Cable Ties ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 19: Remove Backplane Board
3. Lift the backplane board from the storage system. See letter “C” in Figure 10. CAUTION Use caution while lifting the backplane board so you do not cut yourself on sharp edges. TP01806 Figure 10. Removing Backplane Board ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 20: Remove Backplane Board From Housing
Use caution while lifting the backplane board so you do not cut yourself on sharp edges. 3. Remove all SATA cables from the backplane board. See letter “C” in Figure 11. Figure 11. Removing the Backplane Board from the Metal Housing ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 21: Connect Sata Cables And Attach Backplane Board To Housing
3. Using a Number 1 size Phillips Screwdriver, screw in the two Phillips screws on each side of the backplane board that hold the backplane board in its metal shroud. See Figure 12. Figure 12. Installing New Backplane Board into Metal Shroud ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 22: Connect I C Cables
Figure 13. 2. Connect the I C cable that is labeled JP6 to the backplane board. See letter “B” in the circled area of Figure 13. TP01822 Figure 13. Connecting I C Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 23: Connect Power Distribution Module Cables
SATA Cables Installation Procedures Connect Power Distribution Module Cables Connect the two 12-pin Power Distribution Module cables to the backplane board. See letter “A” in Figure 14. TP01808 Figure 14. Connecting Power Distribution Module Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 24: Install Backplane Board
4. Use a Number 1 size Phillips screwdriver to install two screws into each side of the system and the backplane board. See letter “C” in Figure 15. TP01807 Figure 15. Installing New Backplane Board ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 25: Connect Sata Cables
See letter “B” in Figure 4. Bundle the SATA cables in other locations as necessary. Figure 16. Connecting SATA Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 26: Install Fan Assembly
2. Align the holes on the bottom edge of the system fan assembly with the blue plastic shock brackets on the bottom of the chassis. 3. Set the system fan assembly into place. See letter “A” in Figure 17. TP01811 Figure 17. Installing System Fan Assembly ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 27: Attach Fan Assembly
Use a Number 1 size Phillips screwdriver to attach the fan assembly to the chassis, using one screw at each side of the system. See letter “A” in Figure 18. TP01812 Figure 18. Attaching System Fan Assembly ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 28: Connect System Fan Cables
2. Connect the Fan 4 cable to the server board. See letter “B” in Figure 19. 3. Connect the Fan 5 cable to the server board. See letter “C” in Figure 19. TP01813 Figure 19. Connecting System Fan Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 29: Connect Front Panel Board Cables
See letter “C” in Figure 20. 4. Connect the front panel power connector to the front panel board. See letter “D” in Figure 20. TP01814 Figure 20. Connecting Front Panel Board Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 30: Seat Hard Disk Drive Carriers
1. Slide all sixteen hard disk drive carriers into the bays until they stop. See letter “A” in Figure 21. 2. Push the handles up until they latch into place. See letter “B” in Figure 21. TP01815 Figure 21. Seating Hard Disk Drives ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 31: Finishing Up
3. Tighten the two thumb screws at the rear of the chassis. See letter “B” in Figure 22. 4. Connect the AC power cables. See letter “C” in Figure 22. 5. Power on your Intel® Storage System Console. See letter “D” in Figure 22. TP01816 Figure 22. -
Page 32: Front Panel Cables Installation Procedures
1. Review the safety information and warnings at the beginning of this guide. 2. Power down your Intel® Storage System Console. See letter “A” in Figure 1. 3. Remove both AC power cords from the AC power inputs at the rear of your storage system. -
Page 33: Disconnect Front Panel Cables From Front Panel Board
3. Disconnect the secondary IDE cable, labeled J3, from the front panel board. See letter “B” in Figure 3. 4. Disconnect the primary IDE cable, labeled J5, from the front panel board. See letter “C” in Figure 3. TP01820 Figure 24. Disconnecting Front Panel Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 34: Disconnect Front Panel Cables From Server Board
2. Disconnect the secondary IDE cable, labeled J1J4, from the server board. See letter “B” in Figure 3. 3. Disconnect the front panel cable, labeled J1J2, from the server board. See letter “C” in Figure 3. TP01817 Figure 25. Disconnecting Front Panel Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 35: Connect New Front Panel Cables To Server Board
The secondary IDE cable has a white metal sheath and the connector on the front panel is also white. 4. Connect the front panel cable, labeled J1J2, to the server board. See letter “C” in Figure 20. TP01818 Figure 26. Connecting Front Panel Cables to Server Board ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 36: Connect Front Panel Board Cables To Front Panel Board
3. Connect the primary IDE cable, labeled J5, to the front panel board. The primary IDE cable has a blue metal sheath and the connector on the front panel is also blue. See letter “C” in Figure 20. TP01819 Figure 27. Connecting Front Panel Board Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 37: Finishing Up
3. Tighten the two thumb screws at the rear of the chassis. See letter “B” in Figure 22. 4. Connect the AC power cables. See letter “C” in Figure 22. 5. Power on your Intel® Storage System Console. See letter “D” in Figure 22. TP01816 Figure 28. -
Page 38: I C Cables Installation Procedures
1. Review the safety information and warnings at the beginning of this guide. 2. Power down your Intel® Storage System Console. See letter “A” in Figure 1. 3. Remove both AC power cords from the AC power inputs at the rear of your storage system. -
Page 39: Disconnect Front Panel Cables
3. Disconnect the primary IDE cable, labeled J5, from the front panel board. See letter “C” in Figure 3. 4. Disconnect the front panel power connector from the front panel board. See letter “D” in Figure 3. TP01799 Figure 30. Disconnecting Front Panel Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 40: Remove Fan Assembly Screws
Use a Number 1 size Phillips* screwdriver to remove the screw on each side of the system. See letter “A” in Figure 4. These screws hold the system fan assembly in place. See Figure 4. These screws will be re-installed later. TP01800 Figure 31. Removing System Fan Assembly Screws ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 41: Disconnect Fan Cables
2. Disconnect the Fan 4 cable from the server board. See letter “B” in Figure 5. 3. Disconnect the Fan 5 cable from the server board. See letter “C” in Figure 5. TP01801 Figure 32. Disconnecting System Fan Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 42: Remove Fan Assembly
Simultaneously pull up on both sides of the system fan assembly to remove the fan assembly from the storage system. See letter “A” in Figure 6. Set the system fan assembly on a static-free surface. TP01821 Figure 33. Removing System Fan Assembly ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 43: Disconnect I C Cables
Figure 7. 5. Disconnect the I2C cable that is labeled SL2_J13from the SATA Host Bus Adapter card set. See letter “B” in Figure 8. TP01804 Figure 34. Disconnecting I C Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 44: Connect I C Cables
Figure 13. 4. Connect the I2C cable that is labeled SL2_J13to the SATA Host Bus Adapter card set. See letter “B” in Figure 14. TP01822 Figure 35. Connecting I C Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 45: Install Fan Assembly
2. Align the holes on the bottom edge of the system fan assembly with the blue plastic brackets on the bottom of the chassis. 3. Set the system fan assembly into place. See letter “A” in Figure 17. TP01811 Figure 36. Installing System Fan Assembly ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 46: Attach Fan Assembly
Use a Number 1 size Phillips screwdriver to attach the fan assembly to the chassis, using one screw at each side of the system. See letter “A” in Figure 18. TP01812 Figure 37. Attaching System Fan Assembly ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 47: Connect System Fan Cables
2. Connect the Fan 4 cable to the server board. See letter “B” in Figure 19. 3. Connect the Fan 5 cable to the server board. See letter “C” in Figure 19. TP01813 Figure 38. Connecting System Fan Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 48: Connect Front Panel Board Cables
See letter “C” in Figure 20. 4. Connect the front panel power connector to the front panel board. See letter “D” in Figure 20. TP01814 Figure 39. Connecting Front Panel Board Cables ® Intel Storage System SSR316MJ2 Cable Kit... -
Page 49: Finishing Up
3. Tighten the two thumb screws at the rear of the chassis. See letter “B” in Figure 22. 4. Connect the AC power cables. See letter “C” in Figure 22. 5. Power on your Intel® Storage System Console. See letter “D” in Figure 22. TP01816 Figure 40.
