Intel
X18-M/X25-M SATA Solid State Drive
SSDSA1MH080G1, SSDSA2MH080G1, SSDSA1MH160G1, SSDSA2MH160G1
Available in 1.8" and 2.5" Form Factors
Capacity: 80 GB and 160 GB
Uses Intel NAND flash memory Multi-Level Cell
(MLC) components
Bandwidth Performance Specifications
— Sustained Sequential Read: Up to 250 MB/s
— Sustained Sequential Write: Up to 70 MB/s
Read and Write IOPS specifications (IOmeter
Queue Depth 32)
— Random 4 KB Reads: Up to 35 K IOPS
— Random 4 KB Writes: Up to 3.3 K IOPS
Latency Specifications:
— Read: 85 µs
— Write: 115 µs
PCMark* Vantage Benchmark HDD Score:
20,000
Compatibility
®
— Intel
Matrix Storage Manager
— SATA Revision 2.6 compliant, compatible
with SATA 1.5 Gb/s and 3 Gb/s interface
rates
— ATA/ATAPI-7 Compliant
— SSD Enhanced SMART ATA feature set
— Native Command Queuing (NCQ) command
set
Certifications
— UL*
— CE*
— C-Tick*
— BSMI*
— MIC*
— Microsoft* WHQL
— RoHS*
Power Management
— 3.3 V (1.8") or 5 V (2.5") SATA Supply Rail
— SATA Interface Power Management
— OS-Aware Hot Plug/Removal
Power Specifications
— Active: 0.150 W TYP
— Idle: 0.060 W TYP
Temperature
o
— Operating: 0
C to 70
— Non-Operating: -55
Reliability
— Read Error Rate (BER): 1 sector per 10
bits read
— Mean Time Between Failures (MTBF)
1,200,000 hours
— Minimum of five years of useful life
Shock
— Operating and Non-operating: 1,000 G/0.5
msec
Vibration
— Operating: 2.17 G
RMS
— Non-operating: 3.13 G
Weight
— 1.8" 5 mm Form Factor: 35 +/-2 grams
— 1.8" 8 mm Form Factor: 47 +/-2 grams
— 2.5" 7 mm Form Factor: 80 +/-2 grams
— 2.5" 9.5 mm Form Factor: 86 +/-2 grams
Order Number: 319765-008US
Product Manual
o
C
o
o
C to 95
C
15
(7-800 Hz)
(10-500 Hz)
RMS
May 2009
Advertisement
Table of Contents
Related Manuals for Intel SSDSA1MH080G1
Summary of Contents for Intel SSDSA1MH080G1
- Page 1 X18-M/X25-M SATA Solid State Drive SSDSA1MH080G1, SSDSA2MH080G1, SSDSA1MH160G1, SSDSA2MH160G1 Available in 1.8” and 2.5” Form Factors Capacity: 80 GB and 160 GB Uses Intel NAND flash memory Multi-Level Cell (MLC) components Bandwidth Performance Specifications — Sustained Sequential Read: Up to 250 MB/s —...
-
Page 2: Ordering Information
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order. Copies of documents which have an order number and are referenced in this document, or other Intel literature may be obtained by calling 1-800-548-4725 or by visiting Intel's website at http://www.intel.com. -
Page 3: Table Of Contents
3.5.4 Minimum Useful Life ... 11 Mechanical Information ... 11 1.8” 5 mm Intel X18-M SATA SSD ... 11 1.8” 8 mm Intel X18-M SATA SSD ... 13 2.5” 7 mm Intel X25-M SATA SSD ... 14 2.5” 9.5 mm Intel X25-M SATA SSD ... 15 Pin and Signal Descriptions ... -
Page 4: Revision History
® Intel X18-M/X25-M SATA SSD Revision History...27 ® Intel X18-M/X25-M SATA Solid State Drive Product Manual May 2009 Order Number: 319765-008US... -
Page 5: Introduction
SATA hard drives. Intel X18-M/X25-M SATA SSDs are available in 1.8” and 2.5” form factors that are electrically, mechanically, and software compatible with existing 1.8” and 2.5” Serial ATA slots and cables. -
Page 6: Block Diagram
On A Chip Architecture The Intel X18-M/X25-M SATA SSDs utilize a cost effective System on a Chip (SOC) design to manage a full SATA 3 Gb/s bandwidth with the host while managing multiple flash memory devices on multiple channels internally. -
Page 7: Product Specifications
PCMark Vantage HDD Score Note: Performance tests and ratings are measured using HP* Compaq* 6910p notebook with Intel Core™2 Duo CPU T7300 @ 2.0 GHz processor and 2 GB DRAM running Microsoft* Windows Vista* Enterprise Edition and reflects the approximate performance as measured by that configuration. -
Page 8: Electrical Characteristics
Typical Power Consumption Mode Active Idle Note: Active power is measured during execution of MobileMark* 2007 with DIPM (Device Initiated Power Management) enabled. ® Intel X18-M/X25-M SATA Solid State Drive Product Manual ® ® Intel Intel X18-M/X25-M SATA SSD X18-M/X25-M SATA SSD Average Latency 85 µs (TYP) -
Page 9: Environmental Conditions
® Intel X18-M/X25-M SATA SSD Environmental Conditions 3.4.1 Temperature Table 9. Temperature Related Specifications Mode Operating Ambient Temperature Non-Operating Operating Temperature Gradient Non-Operating Operating Humidity Non-Operating Note: Measured without condensation. 3.4.2 Altitude The drive is not sensitive to changes in altitude because it has no moving parts. Drive tested within -1K and +40K feet. -
Page 10: Electromagnetic Immunity
In the extremely unlikely event of a nonrecoverable read error, the drive will report it as a read failure to the host; the sector in error is considered corrupt and is not returned to the host. ® Intel X18-M/X25-M SATA Solid State Drive Product Manual Performance... -
Page 11: Mean Time Between Failure
The drive will have a minimum of 5 years of useful life under typical client workloads with up to 20 GB of host writes per day. Mechanical Information 1.8” 5 mm Intel X18-M SATA SSD The following figure shows the physical package information for the 5 mm deep 1.8” Intel X18-M SATA SSD. - Page 12 Dimensions for Intel X18-M SATA SSD 1.8” 5 mm Form Factor Notes: Connector Outline: The 1.8” Intel X18-M SATA SSD connector is compliant to the SATA Rev 2.6 specifications. Connector Location: The 1.8” Intel X18-M SATA SSD connector is compliant to the micro SATA SFF-8144 specification.
-
Page 13: Mm Intel X18-M Sata Ssd
1.8” 8 mm Intel X18-M SATA SSD The following figure shows the physical package information for the 8 mm deep 1.8” Intel X18-M SATA SSD. Figure 3. Dimensions for Intel X18-M SATA SSD 1.8” 8 mm Form Factor Note: All dimensions are in millimeters. May 2009 Order Number: 319765-008US ®... -
Page 14: 2.5" 7 Mm Intel X25-M Sata Ssd
2.5” 7 mm Intel X25-M SATA SSD The following figure shows the physical package information for the 7 mm deep 2.5” Intel X25-M SATA SSD. Figure 4. Dimensions for Intel X25-M SATA SSD 2.5” 7 mm Form Factor Note: All dimensions are in millimeters. ®... -
Page 15: 2.5" 9.5 Mm Intel X25-M Sata Ssd
2.5” 9.5 mm Intel X25-M SATA SSD The following figure shows the physical package information for the 9.5 mm deep 2.5” Intel X25-M SATA SSD. Figure 5. Dimensions for Intel X25-M SATA SSD 2.5” 9.5 mm Form Factor Note: All dimensions are in millimeters. May 2009 Order Number: 319765-008US ®... -
Page 16: Pin And Signal Descriptions
Pin and Signal Descriptions This section identifies the pin locations and signal descriptions of the Intel X18-M/ X25-M SATA SSDs. Pin Locations 5.1.1 1.8” Pin Locations Figure 6. Layout of Signal and Power Segment Pins Signal Segment S1 ® Intel... -
Page 17: Pin Locations
® Intel X18-M/X25-M SATA SSD 5.1.2 2.5” Pin Locations Figure 7. Layout of Signal and Power Segment Pins Signal Segment S1 Signal Description Table Table 13. Serial ATA Connector Pin Signal Definitions for 1.8” and 2.5” Form Factors Function Ground... - Page 18 The host may ground P11 if it is not used for Device Activity Signal (DAS). Pins P13, P14 and P15 are connected together, although they are not connected internally to the device. The host may put 12 V on these pins. ® Intel X18-M/X25-M SATA Solid State Drive Product Manual Definition 5 V Power.
-
Page 19: Hot Plug Support
COMINIT when first mated with a powered connector to guarantee reliable detection by a host system without hardware device detection. Command Sets ATA Commands The Intel X18-M/X25-M SATA SSDs support all the mandatory ATA commands defined in the ATA/ATAPI-7 specification. 6.1.1 ATA General Feature Command Set... -
Page 20: Identify Device Data
Reserved for assignment by the CompactFlash Association Retired Serial number (20 ASCII characters) Retired Obsolete Firmware revision (8 ASCII characters) Model number (Intel Solid State Drive) 7:0—Maximum number of sectors transferred per interrupt on MULTIPLE commands Reserved Capabilities Capabilities Obsolete... - Page 21 ® Intel X18-M/X25-M SATA SSD Table 16. Returned Sector Data (Continued) F = Fixed Word V = Variable Default Value X = Both 69-70 71-74 001Eh 0106h 0048h 0040h 00FCh 001Ah 746Bh 7C01h 6123h 7469h BC01h 6123h 407Fh 0001h 0001h...
-
Page 22: Power Management Command Set
X = F or V. The content of the word may be fixed or variable. 6.1.2 Power Management Command Set The Intel X18-M/X25-M SATA SSD supports the Power Management command set, which consists of • CHECK POWER MODE • IDLE •... -
Page 23: Security Mode Feature Set
• SECURITY FREEZE LOCK • SECURITY DISABLE PASSWORD 6.1.4 SMART Command Set The Intel X18-M/X25-M SATA SSDs support the SMART command set, which consists of • SMART ENABLE OPERATIONS • SMART DISABLE OPERATIONS • SMART ENABLE/DISABLE AUTOSAVE • SMART RETURN STATUS The Intel X18-M/X25-M SATA SSDs also support the following optional commands: •... -
Page 24: 48-Bit Address Command Set
6.1.6 48-Bit Address Command Set The Intel X18-M/X25-M SATA SSDs support the 48-bit Address command set, which consists of • FLUSH CACHE EXT • READ DMA EXT • READ NATIVE MAX ADDRESS EXT • READ SECTOR(S) EXT • READ VERIFY SECTOR(S) EXT •... -
Page 25: Native Command Queuing
® Intel X18-M/X25-M SATA SSD 6.2.2 Native Command Queuing The Intel X18-M/X25-M SATA SSDs support the Native Command Queuing (NCQ) command set, which includes • READ FPDMA QUEUED • WRITE FPDMA QUEUED Note: With a maximum queue depth equal to 31. -
Page 26: Terms And Acronyms
IOPS Input output operations per second iMSM The Intel Matrix Storage Manager device driver and associated system software. Logical Block Address Link Power Management: the ability of the SATA link layer to enter one of two lower power consuming states, partial and slumber... - Page 27 ® Intel X18-M/X25-M SATA SSD Table 18. Glossary of Terms and Acronyms (Continued) Term Root Mean Squared Revolutions Per Minute Release To Manufacture SATA Serial ATA Small Form Factor Self-Monitoring, Analysis and Reporting Technology: an open standard for developing hard SMART drives and software systems that automatically monitors a hard drive’s health and reports...
- Page 28 Maximum Queue Depth number changed to 31 on 6.2.2. Updated Sustained Read Bandwidth number on Added extra information on altitude in 3.4.2. Updated RoHS reference in Initial Release. Earlier information released as Intel® High Performance Solid State Drive May 2008 Advance Product Manual - 318512-002US. ®...
