Intel SS4000-E Technical Product Specification
Entry storage system
Hide thumbs
Also See for SS4000-E:
- User manual (246 pages) ,
- Quick start user manual (1 page) ,
- Troubleshooting manual (11 pages)
Related Manuals for Intel SS4000-E
Summary of Contents for Intel SS4000-E
- Page 1 ® Intel Entry Storage System SS4000-E Technical Product Specification (Hardware) Intel Order D42567-002 Revision 1.2 Storage Systems Group Marketing...
-
Page 2: Revision History
Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice. -
Page 3: Table Of Contents
Intel® Entry Storage System SS4000-E Table of Contents Table of Contents 1. Feature Summary ......................... 1 System Components ....................5 System Board Feature Set ..................7 Serial ATA (SATA) Host Bus Adapter..............8 SATA Hot Swap Backplane ..................8 Enclosure Management................... 9 1.5.1... - Page 4 Table of Contents Intel® Entry Storage System SS4000-E 5.3.2 Power Connector ....................33 5.3.3 Front Panel Connector................... 34 6. Regulatory Information ...................... 35 6.1 Product Regulation Requirements..................35 6.1.1 Product Safety Compliance ................... 35 6.1.2 Product EMC Compliance – Class B Compliance ..........35 6.1.3...
- Page 5 Entry Storage System SS4000-E ................. 1 ® Figure 2. Intel Entry Storage System SS4000-E Block Diagram ..........5 Figure 3. System Components - Right Side.................. 6 Figure 4. System Components – Left Side .................. 7 Figure 5. I2C Serial Bus Interface Block Diagram ..............10 Figure 6.
- Page 6 Table 11. Power Connector Pin-out.................... 33 Table 12. Front Panel Power Connector..................34 ® Table 13. Intel Entry Storage System SS4000-E System Office Environment Summary..40 ® Table 14. Intel Entry Storage System SS4000-E Operating and Non-Operating Environmental Limits ........................... 41 ®...
-
Page 7: Feature Summary
Processor family. ® For more information on the Intel Entry Storage System SS4000-E Storage Management Software, please refer to the Intel® Storage Management User Guide available from Intel Business Link (IBL), support.intel.com or your Intel sales representative. TP000086 ® Figure 1. Intel Entry Storage System SS4000-E Revision 1.2... - Page 8 Expandable to 1.0 TB – using four 250 GB drives Expandable to 2.0 TB – using four 500 GB drives NOTE: For specific drive family and capacities supported, please refer to the SS4000-E Tested Hardware and OS List (THOL) Drive Bays 4 Serial ATA (SATA) Hot Pluggable 3.5 inch SATA...
- Page 9 SATA backplane. The power supply enclosure contains one 40mm fan. Power 200 W continuous power supply. Intel Entry Storage System Configuration SS4000-E ships with one 200W power supply Max AC input current (PS Enclosure) 4 Amperes at 115 Vrms, 2 Amperes at 230 Vrms 17.0 A...
- Page 10 Feature Summary Intel® Entry Storage System SS4000-E Nordic Countries EMKO-TSE (74-SEC) 207/94 Russia GOST 50377-92 United States UL– 60950 – CSA 60950 (UL and cUL) Electromagnetic Capability (Class B) (EMC) Australia/New Zealand AS/NZS 3548 (based on CISPR 22) Canada ICES-003...
-
Page 11: System Components
Intel® Entry Storage System SS4000-E Feature Summary System Components A block diagram of the storage system functional components is shown below. ® Figure 2. Intel Entry Storage System SS4000-E Block Diagram The components included with this storage system are diagrammed below. Revision 1.2... -
Page 12: Figure 3. System Components - Right Side
Feature Summary Intel® Entry Storage System SS4000-E TP000228 Power Supply Connector Power Supply SATA Backplane Connector Fan Connector System Board Figure 3. System Components - Right Side Revision 1.2... -
Page 13: System Board Feature Set
NOTE: For specific memory recommendations please refer to the Tested Hardware and OS List (THOL). NOTE: The Intel Entry Storage System SS4000-E ships with 256MB memory. Only qualified service personnel should service system memory. Peripheral 1 32-bit PCI bus operating at 33MHz providing connection for: Interfaces •... -
Page 14: Serial Ata (Sata) Host Bus Adapter
Intel® Entry Storage System SS4000-E Serial ATA (SATA) Host Bus Adapter ® The Intel Entry Storage System SS4000-E ships with one 4 port PCI-X to SATA Host Bus Adapters. The SATA HBA provides the following feature set: Feature Description Number of ports 4, using a single Intel 31244 SATA controller. -
Page 15: Enclosure Management
Intel® Entry Storage System SS4000-E Feature Summary Enclosure Management The enclosure management controller monitors various aspects of the storage enclosure. The enclosure management controller is comprised of the following elements and supports associated features: • CPLD (Lattice ispMACH 4064V) •... -
Page 16: Hard Disk Drive Leds
Figure 5. I2C Serial Bus Interface Block Diagram 1.5.3 Hard Disk Drive LEDs ® The Intel Entry Storage System SS4000-E SATA HSBP contains one LED for each of the four drive slots. Table 1. HDD LED Function Activity Light States... -
Page 17: Chassis Dimensions And Weight
Intel® Entry Storage System SS4000-E Feature Summary Chassis Dimensions and Weight Table 2. Chassis Dimensions and Weight Height 8.42 inches 214mm Width 6.30 inches 160mm Depth 9.6 inches 243mm Weight Chassis - as shipped (0 drives) 3.5 kilograms 7 pounds Chassis - fully configured (4 drives) 5.45 kilograms... -
Page 18: Back Panel I/O Ports And Features
Feature Summary Intel® Entry Storage System SS4000-E Back Panel I/O Ports and Features At the rear of the chassis are two 10/100/1000 Network Interface Card (NIC) connectors and two USB 2.0 ports. The Input/Output (I/O) connectors are integrated to the back panel. The figure below shows the rear of the storage system. -
Page 19: Front Panel And Hard Disk Drive Bays
Intel® Entry Storage System SS4000-E Feature Summary Front Panel and Hard Disk Drive Bays AF000227 Figure 7. Hard Disk Drive Bays AF000310 Figure 8. Chassis Front Revision 1.2... -
Page 20: Front/Rear Panel Controls And Indicators
Feature Summary Intel® Entry Storage System SS4000-E 1.8.1 Front/Rear Panel Controls and Indicators The front/rear panel controls and indicators are defined below: Table 3. Front and Rear Control Button Functions Toggles the system power on/off. Power button (front) Holding button down will shut the system down. -
Page 21: Figure 9. Front Panel
Intel® Entry Storage System SS4000-E Feature Summary NIC1 Activity NIC1 Ethernet Link NIC2 Ethernet Link NIC2 Activity Global Disk Status System Status Power Status Power Button Figure 9. Front Panel Revision 1.2... -
Page 22: Figure 10. Rear Panel
Feature Summary Intel® Entry Storage System SS4000-E AF000084 System Fan USB Ports Power Connector NIC2 Ethernet Port NIC1 Ethernet Port Reset Button Power Supply Fan Cable Lock Figure 10. Rear Panel Revision 1.2... -
Page 23: Figure 11 Hard Disk Drive Carrier Led Light Pipe
Intel® Entry Storage System SS4000-E Feature Summary Table 5. Intel Disk Drive Carrier LED Functions Continuous green indicates the drive is available. Blinking green indicates drive activity Disk Drive Activity LED Continuous amber indicates a fault condition possibly requiring the drive to Light Pipe be replaced. -
Page 24: Power Sub-System
200 Intel Entry Storage System SS4000-E Watt power supply. Power Supply ® The Intel Entry Storage System SS4000-E accommodates one 200 Watt (W) power supply. PARAMETER Nominal Voltage (in) 90 VAC 115-230 VAC 253 VAC Voltage (in frequency) -
Page 25: Power Supply Outputs
® The Intel Entry Storage System SS4000-E power system supports one 200 W Power Supply. The power supply provides six DC output rails; +3.3V, +5V, +12V, -5V, -12V and +5Vsb. Table 5. Power Supply Output Summary (200W 10 second peak ratings) +3.3V... -
Page 26: Table 6. Front Panel Power Supply Led Indicator
Power Sub-System Intel® Entry Storage System SS4000-E 2.1.1.1 Front Panel Power Supply LED Indicator The power supply is connected to a single external LED to indicate the status of the power supply. When AC is applied to the Power Supply Unit (PSU) and the system is powered on, the LED will be solid on green to indicate that all the power outputs are available. -
Page 27: Output Power/Currents
Intel® Entry Storage System SS4000-E Power Sub-System Output Power/Currents The following table defines power and current ratings for this 200 Watt continuous (300 Watts peak) power supply. The output power shall not exceed the rated output power. The power supply must meet both static and dynamic voltage regulation requirements for the minimum loading conditions. - Page 28 Power Sub-System Intel® Entry Storage System SS4000-E Voltage Over Current Limit 115Vrms 230Vrms 100A (@ 25°C ambient cold start) Revision 1.2...
-
Page 29: Over Voltage Protection (Ovp)
Intel® Entry Storage System SS4000-E Power Sub-System 2.4.2 Over Voltage Protection (OVP) The power supply over voltage protection shall be locally sensed. In an over voltage fault occurs, the supply will latch all DC outputs into a shutdown state except 5Vsb output. This latch shall be cleared by an AC power interruption. -
Page 30: System Cooling Fan
® The Intel Entry Storage System SS4000-E includes a cooling fan that has a single rotor 92 mm fan, mounted on the rear of the chassis. The Power Supply enclosure contains one 40 mm fan for cooling the power supply module. -
Page 31: Figure 13. Chassis Fan And Backplane Location
Intel® Entry Storage System SS4000-E System Cooling Fan AF000303 System Chassis Fan System Board Backplane and connectors Hard Disk Drive Figure 13. Chassis Fan and Backplane Location Revision 1.2... -
Page 32: Chassis Bays
® The Intel Entry Storage System SS4000-E chassis provides four hard drive bays at the front of the chassis. All hard drive bays may be populated with a carrier-mounted 3.5 inch SATA hard disk drive. The latch must be open prior to inserting the drive carrier containing a disk drive. -
Page 33: Figure 14. Disk Drive Carrier Insertion And Removal
Intel® Entry Storage System SS4000-E Chassis Bays TP02349 Figure 14. Disk Drive Carrier Insertion and Removal Revision 1.2... -
Page 34: Hard Disk Drive Bays
SATA, 3.5 inch x 1 inch, hard disk drives. The SATA drives may be “electrically” hot-swapped ® while the system power is applied, i.e., after POST (Power On Self Test). See the Intel Entry Storage System SS4000-E User Guide for more information. -
Page 35: Hard Disk Drive Carrier
Intel® Entry Storage System SS4000-E Chassis Bays AF000227 Figure 16. Hard Disk Drive Bays 4.1.1 Hard Disk Drive Carrier Each hard drive used in the system must be mounted to a drive carrier, making insertion and extraction of the drive from the chassis very simple. Each drive tray has its own dual purpose latching mechanism that is used to both insert/extract drives from the chassis and lock the carrier in place. -
Page 36: Figure 17. Hard Drive Carrier Assembly
Chassis Bays Intel® Entry Storage System SS4000-E Figure 17. Hard Drive Carrier Assembly Revision 1.2... -
Page 37: System Interconnection
SATA controller on the motherboard. I/O Panel Connectors ® The Intel Entry Storage System SS4000-E provides an aperture for the rear I/O ports. The following are the I/O ports available: • Two RJ-45 LAN connectors •... -
Page 38: Sata Hsbp Connectors
System Interconnection Intel® Entry Storage System SS4000-E SATA HSBP Connectors 5.3.1 SATA Connector The following table defines the pin-outs of the SATA Drive Connector. The first connector carries signals from drive 1, the second connector is connected to drive 2, the third connector connects to drive 3 and the fourth connector connects to drive 4. -
Page 39: Power Connector
Intel® Entry Storage System SS4000-E System Interconnection 5.3.2 Power Connector The following table defines the pin-out of the 2x10 Power Connector. Table 11. Power Connector Pin-out Signal Name Signal Name +3.3V +3.3V +3.3V -12V PS-ON Power Good Stand-By 5V +12V PSA1 Revision 1.2... -
Page 40: Front Panel Connector
System Interconnection Intel® Entry Storage System SS4000-E 5.3.3 Front Panel Connector The following table defines the pin-outs of the 2x8 Front Panel connector. Table 12. Front Panel Power Connector Signal Name Signal Name Power LED+ Power LED- VCC3R RAIDA Status LED... -
Page 41: Regulatory Information
Intel® Entry Storage System SS4000-E Regulatory Information Regulatory Information 6.1 Product Regulation Requirements Intended Application – This product was evaluated as Information Technology Equipment (ITE), which may be installed in homes, offices, schools, computer rooms, and similar commercial type locations. The suitability of this product for other product categories and environments (such as: medical, industrial, telecommunications, NEBS, residential, alarm systems, test equipment, etc.), other than an ITE application, may... -
Page 42: Certifications / Registrations / Declarations
Regulatory Information Intel® Entry Storage System SS4000-E 6.1.3 Certifications / Registrations / Declarations UL Certification (US/Canada) CE Declaration of Conformity (CENELEC Europe) FCC/ICES-003 (USA/Canada) VCCI Certification (Japan) C-Tick Declaration of Conformity (Australia) MED Declaration of Conformity (New Zealand) BSMI Certification (Taiwan) -
Page 43: Product Regulatory Compliance Markings
Intel® Entry Storage System SS4000-E Regulatory Information Product Regulatory Compliance Markings The Intel Server Chassis product bears the following regulatory marks. Regulatory Compliance Country Marking cULus Listing Marks USA/Canada GS Mark Germany CE Mark Europe FCC Marking (Class A) EMC Marking (Class A) -
Page 44: Product Ecology Requirements
All cords and cables shall contain < 100 ppm of cadmium. European Restriction of Hazardous Substances (RoHS) Intel has a system in place to restrict the use of banned substances in accordance with the European Directive 2002/95/EC. Compliance is based on declaration that materials banned in the RoHS Directive are either (1) below all applicable substance threshold limits or (2) an approved/pending RoHS exemption applies. - Page 45 Intel® Entry Storage System SS4000-E Regulatory Information Note: RoHS implementing details are not fully defined and may change. Threshold limits and banned substances are noted below. Quantity limit of 0.1% by mass (1000 PPM) for: Lead Mercury Hexavalent Chromium Polybrominated Biphenyls Diphenyl Ethers (PBDE) Quantity limit of 0.01% by mass (100 PPM) for:...
-
Page 46: Environmental Limits
Intel® Entry Storage System SS4000-E Environmental Limits System Office Environment ® Table 13. Intel Entry Storage System SS4000-E System Office Environment Summary Parameter Limits Operating Temperature 10 degrees celcius to +35 degrees celcius with the maximum rate of change not to exceed 10 degrees celcius per hour. -
Page 47: Environmental Limits
Intel® Entry Storage System SS4000-E Environmental Limits Environmental Limits The following table summarizes environmental limits, both operating and non-operating. ® Table 14. Intel Entry Storage System SS4000-E Operating and Non-Operating Environmental Limits Temperature Specification Non-operating -40 degrees celcius to 70 degrees celcius... -
Page 48: Serviceability And Availability
Serviceability and Availability Intel® Entry Storage System SS4000-E Serviceability and Availability The system is designed to be serviced by qualified technical personnel only. The desired Mean Time To Repair (MTTR) of the system is TBD minutes, including diagnosis of the system problem. To meet this goal, the system enclosure and hardware have been designed to minimize the MTTR. -
Page 49: Calculated Mtbf
Calculated MTBF Calculated MTBF ® The Mean Time Between Failures (MTBF) for the Intel Entry Storage System SS4000-E is calculated at 27,248 hours operating at 40 degrees C. The following table shows the MTBF numbers for individual components within the chassis, and does not include hard disk drives. -
Page 51: Appendix A: Spares And Accessories
Intel® Entry Storage System SS4000-E Appendix A: Spares and Accessories Appendix A: Spares and Accessories Upgrade and Accessory Parts ® Table 16. Intel Entry Storage System SS4000-E Upgrade and Accessory Parts Product Code MM # Qty. Description 88026 FXX10DVCARBLK Drive Carrier Spare – 10 Pack... -
Page 52: Glossary
Glossary Intel® Entry Storage System SS4000-E Glossary Word / Acronym Definition Ampere Alternating Current Australian Communication Authority ACPI Advanced Configuration and Power Interface ANSI American National Standards Institute AT Attachment Decibel Average Baseboard Management Controller British Thermal Units Celsius ®... - Page 53 Intel® Entry Storage System SS4000-E Glossary Integrated Circuit I/O Controller Hub Internet Database Connector Integrated Drive Electronics Intel® Management Module Input/Output iSCSI Internet Protocol Small Computer System Interface Information Technology Equipment Kilo (1.024 x 10 Kilobyte Kilovolt Kilohertz Local Area Network...
- Page 54 Glossary Intel® Entry Storage System SS4000-E SOIC Small Outline Integrated Circuit SRAM Static Random Access Memory Server System Infrastructure TQFP Thin Quad Flat Pack Terabyte UART Universal Asynchronous Receiver Transmitter μF Micro Farad (1 x 10 Farads) μS Micro Second (1 x 10...
