UM10525 120 V 20 W CFL demo board using the UBA2212 Rev. 1 — 19 April 2012 User manual Document information Info Content Keywords UBA2212, demo board, CFL, boost, 120 V (AC), 20 W Abstract This document is a user manual for the UBA2212 120 V, 20 W demo...
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 Revision history Date Description 20120419 first issue Contact information For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com UM10525 All information provided in this document is subject to legal disclaimers.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 1. Introduction The UBA2212 series is a family of high voltage monolithic integrated circuits for driving Compact Fluorescent Lamps (CFL) in half-bridge configurations. It is derived from the UBA2211 IC and modified to drive a 120 V (AC) application.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 2. Safety Warning WARNING Lethal voltage and fire ignition hazard The non-insulated high voltages that are present when operating this product, constitute a risk of electric shock, personal injury, death and/or ignition of fire.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 3. Specifications Table 1. Demo board specification Parameter State Value Comment AC line input voltage 96 V (AC) to 144 V (AC) board optimized for 120 V (AC), 60 Hz.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 4. Schematic and functional description L FILT C DVDT C FS SGND SGND SENSE PGND SGND AC input C BUF UBA2212 DVDT R fuse R osc C VDD...
Page 7
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 lamp osc(nom) ..VCO input time (s) preheat ignition and boost burn transition 001aan302 Fig 4. Timing sequence of the system In preheat, current I charges capacitor C...
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 5. Measurement results Using a typical 20 W lamp, the measurements show that the boost effect is visible to the human eye when the light is powered up. The same situation is not visible when the same lamp is used without boost feature.
Page 9
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 (1) I signal. lamp (2) SW signal timing for preheat. (3) CB signal timing for boost and transition. (4) Half-bridge voltage. Fig 6. Time sequence for a boost lamp with a zoom function applied to the preheat state (1) I signal.
Page 10
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 Table 2. Electrical parameters 12 W boost lamp (UBA2212BT N1B) Boost ratio = 1.49; boost time = 38.5 s (25 cycles); transition time = 2 s. State...
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 5.1 Boost lamp with high lamp voltage During boost state, lamps consume more power. As a result, the half-bridge valley voltage value is pulled low. In addition, CM or hard switching occurs especially when a high lamp voltage with used with a low mains input.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 5.2 RMS control in boost and steady states When ignition frequency is reached, the lamp ignites. V increases to a given voltage to set the lamp current at the level defined by the internal boost reference and resistor R...
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 (1) VDD signal. (2) I signal. lamp (3) Half-bridge voltage. (4) CB signal timing for boost and transition. Fig 10. OTP function activated in boost state 5.4 Saturation Current protection A critical parameter in the design of the lamp inductor is its saturation current.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 (1) Half-bridge voltage. (2) I signal. lamp (3) RC signal. Fig 11. IC operation with saturated inductor at ignition 5.5 Capacitive mode protection The UBA2212 detects hard switching operations to prevent stress on MOSFETs using the internal Zero-Voltage Switching (ZVS) control circuit.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 6. Schematic and Bill Of Materials (BOM) The components used are illustrated in Figure 3 Figure Table 3 describes the components required for 120 V reference board application.
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 Table 3. Bill of materials …continued Number Reference Typical value Quantity PC40-EE16; 1.5 mH; 1 A; N = 180:6:6; diameter 0.23 mm UBA2212CT; SO14 Burner burner; T3 Spiral 20 W 7.
Page 18
UM10525 NXP Semiconductors 120 V 20 W CFL demo board using the UBA2212 Fig 15. 12 W Baishi CFL Table 5. Electrical parameters 12 W boost lamp (UBA2212BT N1B) Boost ratio = 1.56.; C = 22 F, 250 V; L2 = 1.75 mH, 2 ;...
