Stock Inspection &
Requirements
Some workpieces are not safe to turn or may
require modification before they are safe to
turn. Before turning a workpiece, inspect all
workpieces for the following:
• Workpiece Type:
This machine is intended for cutting natural
and man-made wood products, and some
plastics. Never attempt to cut any metal,
stone, or rubber workpiece; cutting these
materials can lead to machine damage or
severe injury.
• Foreign Objects:
Nails, staples, dirt, rocks and other foreign
objects are often embedded in wood. While
cutting, these objects can become dislodged
and hit the operator, cause tool grab, or break
the turning tool, which might then fly apart.
Always visually inspect your workpiece for
these items. If they can't be removed, DO
NOT turn the workpiece.
• Large/Loose Knots:
Loose knots can become dislodged during
the turning operation. Large knots can cause
a workpiece to completely break in half dur-
ing turning and cause machine damage and
personal injury. Choose workpieces that do
not have large/loose knots.
• Wet or "Green" Stock:
Cutting wood with a moisture content over
20% causes unnecessary wear on tooling
blades, increases the risk of tool grab, and
yields poor results.
Excessive Warping:
•
Workpieces with excessive bowing or twist-
ing are unstable and unbalanced. Never turn
these workpieces at high speed, or instability
will be magnified and the workpiece can be
ejected from the lathe causing impact injures.
Only turn concentric workpieces!
G0462 Wood Lathe (Mfd. Since 11/14)

Adjusting Head

The Model G0462 headstock can be positioned
anywhere along the bed and pivoted up to 180˚.
To position the headstock along the length of
the bed:
1. DISCONNECT LATHE FROM POWER!
2. Loosen the head lock lever shown in
Figure 16.
Head Lock
Lever
Figure 16. Head lock lever.
3.
Slide the headstock to the desired position,
then retighten the lock lever.
Note: The large hex nut under the headstock
may require occasional adjustment to ensure
proper clamping pressure to the bed. Turn
the hex nut in small increments to fine tune
the clamping pressure, as needed.
If the lathe head unexpectedly moves during
operation, the tool and your hand could be
drawn into the spinning workpiece resulting
in death or crushing injuries. ALWAYS make
sure the head lock lever is tight and the
head pivot pin is seated before operation.
