  • Page 1: User Manual

    ® 2N Lift8 Communicator for lifts User Manual Firmware: Version: 2.3.1 www.2n.cz...
  • Page 2 2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find information and to answer your questions about 2N products and services. On www. faq.2n.cz you can find information regarding products adjustment and instructions for optimum use and procedures „What to do if...".
  • Page 3 The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All development, production and distribution processes of the company are managed by this standard and guarantee a high quality, technical level and professional aspect of all our products.
  • Page 4 2.10.2 Fireman 2.10.3 Fireman – Mechanical Mounting 2.11 I/O Module 2.12 Camera Module 2.13 RS232 Module 2.14 Audio Unit – Shaft Antivandal 3. System Configuration 3.1 Lift8 Programming 3.2 Table of Parameters 3.3 SMS Configuration 2N TELEKOMUNIKACE a.s., www.2n.cz 4/377...
  • Page 5 4.10 Rescue Activation and End 4.11 Battery Replacement 5. Service Tool 5.1 Installation and Login 5.2 Introduction to Application 5.3 Use 6. Lift8 Server 6.1 Installation and Licensing 6.2 Use 7. Control Panel 7.1 Installation and Login 7.2 Introduction to Application 7.3 Use...
  • Page 6 13. Supplementary Information 13.1 Troubleshooting 13.2 List of Abbreviations 13.3 Regulations 13.4 General Instructions and Cautions 2N TELEKOMUNIKACE a.s., www.2n.cz 6/377...

  • Page 7: Product Introduction

    Here is what you can find in this section: 1.1 Product Description 1.2 Components and Associated Products 1.3 Changes 1.4 Terms and Symbols Used 2N TELEKOMUNIKACE a.s., www.2n.cz 7/377...

  • Page 8: Product Description

    LEDs. It is also equipped with a USB interface for comfortable configuration, voice message recording and software upgrade. can be connected via: GSM, UMTS, PSTN or VoIP. ® Lift8 meets the TÜV certifications . System Diagram 2N TELEKOMUNIKACE a.s., www.2n.cz 8/377...
  • Page 9 System Diagram ® Example of Lift8 Central Unit, Splitter and Audio Unit Connection Main bus Audio unit bus 2N TELEKOMUNIKACE a.s., www.2n.cz 9/377...
  • Page 10 The audio units cannot be connected to a telephone line without the When shared by multiple shafts, the audio units cannot be connected without the and splitters. 918600 2N ® Lift8 Central Unit ® Lift8 Central Unit For connection of up to 8 lifts to a GSM/UMTS/PSTN line. Including a power EURO cable and rechargeable battery.
  • Page 11 918620E 2N ® Lift8 Splitter ® Lift8 Splitter – lift audio unit interconnection. 918610E 2N ® Lift8 Audio Unit – COP (Normal version) ® Lift8 Audio Unit – COP Audio unit electronics for lift cabin building in. Including speaker and microphone (HandsFree).
  • Page 12 918610EX 2N ® Lift8 Audio Unit – COP – Cable Version Contains LED, microphone and speaker connected to cables. ® Lift8 Audio Unit – COP – Cable Version 918611E 2N ® Lift8 Audio Unit – Machine Room/Control Centre ® Lift8 Audio Unit –...
  • Page 13 918612E 2N ® Lift8 Audio Unit – Shaft ® Lift8 Audio Unit – Shaft Audio unit for cabin roof and shaft or cabin bottom. Robust yellow cover. HandsFree mode, ALARM button and Triphony, LED indicators. Not intended for use in the cabin.
  • Page 14 Audio Unit – Fireman Used for fire fighting operations. Activates top priority calls. 918610FZK 2N ® Lift8 Audio Unit – Fireman DPS (1 button) 918619E 2N ® Lift8 Audio Unit – Fireman DPS (knob + 1 push-to- talk button) ®...
  • Page 15 918617E 2N ® Audio Unit – Shaft Antivandal ® Lift8 Audio Unit – Shaft Antivandal A robust, highly resistant audio unit designed for installation on lift cabin roofs and shaft bottoms, under cabin floors and/or any other places that require communication, e.g.
  • Page 16 Lift8 Camera Module For camera connection (IP, RS232, RS485) to the lift cabin. Every cabin in each shaft ® can contain a camera module (up to 8 camera modules in 2N Lift8). 918654E 2N ® Lift8 RS232 Module ® Lift8 RS232 Module ®...
  • Page 17 918650E 2N ® Lift8 GSM Module ® Lift8 GSM Module For Central Unit connection via a mobile network. Optional data connection for remote system configuration. 918651E 2N ® Lift8 UMTS Module ® Lift8 UMTS Module For Central Unit connection via a mobile network. Optional data connection for remote system configuration.
  • Page 18 918652E 2N ® Lift8 PSTN Module ® Lift8 PSTN Module For Central Unit connection via an analogue line. 918653E 2N ® Lift8 VoIP Module ® Lift8 VoIP Module For Central Unit connection via a VoIP line. 2N TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 19 Cooperating 2N ® Applications 918700E 2N ® Lift8 Service Tool ® Lift8 Service Tool ® Lift8 Service Tool application is intended for remote supervision and ® configuration of the Lift8 communicators. 918700E 2N ® Lift8 Control Panel ® Lift8 Control Panel ®...
  • Page 20 918700E 2N ® Lift8 Communicator ® Lift8 Communicator ® Lift8 Communicator application is intended for receiving alarm calls by the dispatcher. 918700E 2N ® Lift8 Server ® Lift8 Server ® Lift8 Server application processes check calls and mediates communication between the s and PC applications.
  • Page 21 Associated 2N ® Products 918655E – 2N ® Lift8 External Pictograms Driver ® Lift8 External Pictograms Driver ® Transforms the Lift8 cabin LED outputs into universal pilot lamps. 2N TELEKOMUNIKACE a.s., www.2n.cz 21/377...
  • Page 22 Surveillance mode in the Control Panel Improvements in applications 1.7.0 Firmware 1.7.0 Camera module New protocols: CPC Antenna/KONE 2N ext. and P100 2N ext. (shaft number and audio unit type identification) DE language support Auto-delete of archive records 2N TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 23 Image downloading application (get-cam-image) 2.2.0 Firmware 2.2.0 Event reporting New actions and script commands Monitoring of statistic data and a new character set on the server New installers In-band DMTF Direct call (call to IP address) 2N TELEKOMUNIKACE a.s., www.2n.cz 23/377...
  • Page 24 Server – receiving of operational calls Operational calls (jammed button, audio test error, battery error) Get-cam-image – image loading option outside an active call 2.3.1 Firmware 2.3.1 Change of module mounting spacers New events (service tool) 2N TELEKOMUNIKACE a.s., www.2n.cz 24/377...

  • Page 25: Symbols Used

    Useful information for quick and efficient functionality. Note Routines or advice for efficient use of the device. Future Functions, New Features The grey-marked text in this document designates the functions and features that are under preparation or development at present. 2N TELEKOMUNIKACE a.s., www.2n.cz 25/377...
  • Page 26 2.10.1 Fireman PCB 2.10.2 Fireman 2.10.3 Fireman – Mechanical Mounting 2.11 I/O Module 2.12 Camera Module 2.13 RS232 Module 2.14 Audio Unit – Shaft Antivandal Each subsection includes: Description of Components Before You Start Fitting Electrical Wiring 2N TELEKOMUNIKACE a.s., www.2n.cz 26/377...
  • Page 27 2.1 PSTN/GSM/UMTS/VoIP Central Unit Description Central Unit 2N TELEKOMUNIKACE a.s., www.2n.cz 27/377...
  • Page 28 Indication Elements 2N TELEKOMUNIKACE a.s., www.2n.cz 28/377...
  • Page 29 Central Unit Connectors There are a USB connector and reset button to the right of the (see the figure below). USB Connector and Reset Button 2N TELEKOMUNIKACE a.s., www.2n.cz 29/377...
  • Page 30 USB Port Connection Recommendation Do not keep your PC connected for a long time unless necessary to reduce the computer damage due voltage surge from the telephone line during storms, for example. 2N TELEKOMUNIKACE a.s., www.2n.cz 30/377...
  • Page 31 On an easily accessible place there is a risk of telephone line misuse or SIM card misappropriation. is mounted on a wall with the included wall plugs and screws. 2N TELEKOMUNIKACE a.s., www.2n.cz 31/377...
  • Page 32 Connect the to the mains supply. Caution If you connect one lift shaft only, it is not necessary to connect the splitters. Use the splitters only if you want to connect 2 or more lift shafts. 2N TELEKOMUNIKACE a.s., www.2n.cz 32/377...

  • Page 33: Power Supply

    ® Never use 2N Lift8 without its protective cover to avoid electric ® accident, malfunction due to wrong interconnection and/or 2N Lift8 electronics damage or destruction as a result of electric short-circuit or ® adverse environmental conditions. It is because...
  • Page 34 LED (Power/battery) should start to flash (charging). The charges the rechargeable batteries until fully charged. After some time the flashing green LED (charging) should change to a permanently illuminated green LED (battery charged). 2N TELEKOMUNIKACE a.s., www.2n.cz 34/377...
  • Page 35 The required 1h backup is not guaranteed if more than 20 audio units are installed. Remember to replace the batteries every two years. Splitter – CU Bus Connection 2N TELEKOMUNIKACE a.s., www.2n.cz 35/377...
  • Page 36 - ). Mind the polarity. Main bus 1 … Main bus power + 2 … Main bus power - 3 … Main bus audio + 4 … Main bus audio - 5 … Main bus data + 2N TELEKOMUNIKACE a.s., www.2n.cz 36/377...
  • Page 37 The maximum total cable length is 30 m with the cross-section of 0.75 mm2. For higher lengths, enlarge the supply pair cross-section: PWR (60 m – 1.5 mm2 , or 100 m – 2.5 mm2). 2N TELEKOMUNIKACE a.s., www.2n.cz 37/377...
  • Page 38 (power wire, video signal etc.). Do not lead the bus close to power cables, especially in long-distance sections. Branch the bus to shorten the total length of sections. 2N TELEKOMUNIKACE a.s., www.2n.cz 38/377...
  • Page 39 CU, splitter or I/O module. Caution Find the 2-pin termination resistance connector between the main bus connector and audio unit connectors (see the figure below). By default, the termination resistance is connected (jumper mounted). 2N TELEKOMUNIKACE a.s., www.2n.cz 39/377...
  • Page 40 Examples of Connection: 2N TELEKOMUNIKACE a.s., www.2n.cz 40/377...
  • Page 41 ISDN line. Telephone line requirements The line must not be a dual or party one. The telephone socket and its wiring are usually the network provider's property and may not be tampered with. 2N TELEKOMUNIKACE a.s., www.2n.cz 41/377...
  • Page 42 Other recommendations ® Make an agreement with the PBX owner regarding operating costs (2N Lift8 outgoing calls are billed at the owner‘s expense with the exception of free calls via “green lines”).
  • Page 43 If there is permanent manning in your building (security staff, ® receptionist), train the personnel how to rescue people and program 2N Lift8 to call this service. This is used in particular where no PSTN line is available. Recommendation In places with a poor signal quality find an appropriate place or use a special (directional) antenna.
  • Page 44 VoIP VoIP is the cheapest solution where a reliable Internet connection is available. 2N TELEKOMUNIKACE a.s., www.2n.cz 44/377...
  • Page 45 The splitters are connected in series, i.e. one after another (never in parallel), to avoid system instability. The termination resistance (jumper) is mounted on the last splitter or IO module (furthest from the ® Lift8 Splitter 2N TELEKOMUNIKACE a.s., www.2n.cz 45/377...
  • Page 46 1 … Main bus power + 2 … Main bus power - 3 … Main bus audio + 4 … Main bus audio - 5 … Main bus data + 6 … Main bus data - 2N TELEKOMUNIKACE a.s., www.2n.cz 46/377...
  • Page 47 Configure lift 2–8 as 2–8 (set the switch to position 5 for lift 5, e.g.). Warning Do not configure the splitter address as 0, 1 and 9 or the system will report a fault Address 1 is used by the central unit Audio Unit Connection 2N TELEKOMUNIKACE a.s., www.2n.cz 47/377...
  • Page 48 The control electronics must ensure that, after the contact opening, the lifts in operation go down to the nearest station and the doors open. Caution This function may be mandatory depending on the regulations applicable for the given country and time of installation. 2N TELEKOMUNIKACE a.s., www.2n.cz 48/377...
  • Page 49 Wall Mounting Use appropriate wall plugs and screws for mounting (not included in the delivery). Hang the device using the pre-drilled holes on the device bottom. Wall Mounting DIN Rail Mounting 2N TELEKOMUNIKACE a.s., www.2n.cz 49/377...
  • Page 50 A wrong mounting procedure may lead to damage to the electronics due to water infiltration. The splitter circuits are constantly under voltage and water leakage causes electrochemical reaction. No warranty can be claimed for products damaged in this manner! 2N TELEKOMUNIKACE a.s., www.2n.cz 50/377...
  • Page 51 The yellow and green LEDs flash to indicate audio unit upgrading. The red LED on the back side is permanently on. No LED is illuminated upon upgrade and the audio unit is ready for use. 2N TELEKOMUNIKACE a.s., www.2n.cz 51/377...
  • Page 52 1 cover with printing 5 tightening straps Mounting Electronics Mounting This audio unit is intended for mounting behind the lift control panel. Typically, the panel is ready for installation as shown in the drawing below: 2N TELEKOMUNIKACE a.s., www.2n.cz 52/377...
  • Page 53 (one hole must have the minimum diameter of 5 mm, a group of smaller holes must have the same total area). Be sure to degrease and clean the surface carefully before! 2N TELEKOMUNIKACE a.s., www.2n.cz 53/377...
  • Page 54 May I place the speaker on the cabin ceiling? This placement is not recommended. May I use a longer cable to the speaker? For the speaker yes, but we do not recommend it for the microphone. 2N TELEKOMUNIKACE a.s., www.2n.cz 54/377...
  • Page 55 Induction loop connector CANCEL, contact activation Speaker connector Alarm 2 (set 2) Servicing connector Configuration jumpers Two LED signal lamps (other side) Audio unit position 1. (yellow) Request received ALARM and CANCEL negation 2. (green) Connection confirmed 2N TELEKOMUNIKACE a.s., www.2n.cz 55/377...
  • Page 56 (1 – cabin 2 roof , 2 – cabin 2, 3 – under cabin 2). Configure the required changes as printed on the electronics cover. If you have removed the cover, put it back in the original position and tighten the screw. 2N TELEKOMUNIKACE a.s., www.2n.cz 56/377...
  • Page 57 The position-setting jumpers are employed exceptionally, e.g. where a certain audio unit type is used in a position other than normally intended. To recover the initial address setting, follow the drawing on the cover. Bus Connection 2N TELEKOMUNIKACE a.s., www.2n.cz 57/377...
  • Page 58 NO/NC contact may be connected to them. If one of the ALARM contacts is connected to another circuit, an appropriate isolation strength according to the applicable standards has to be ensured between the contacts. 2N TELEKOMUNIKACE a.s., www.2n.cz 58/377...
  • Page 59 In that case, the rescue request is cancelled. If the door does not open, the request is accepted. Find out before installation whether the door opening signal is available in the lift cabin. 2N TELEKOMUNIKACE a.s., www.2n.cz 59/377...
  • Page 60 For activation by voltage connection, leave the jumper as it is (6th pin on jumper 12) – CANCEL without jumper fitted (factory setting). For activation by voltage disconnection, fit the jumper (6th pin on jumper 12) – CANCEL inverted – jumper fitted. 2N TELEKOMUNIKACE a.s., www.2n.cz 60/377...
  • Page 61 Figure: Alternative LED Connection for Audio Unit – COP Note The cables required for this configuration are not part of the standard delivery but are available upon agreement. In this configuration, the auxiliary indicators on the PCB are not illuminated. 2N TELEKOMUNIKACE a.s., www.2n.cz 61/377...
  • Page 62 Lift8 External Pictogram Driver is in compliance with the essential requirements and other relevant provisions of the 1999/5/EC Directive. ® The Declaration of Conformity is attached to the basic module of 2N Lift8 and also available at www.2n.cz 2N TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 63 The service technician enters a valid password via the Lift8 voice menu to terminate the process. When the rescue password is entered via the voice menu, the yellow LED goes off on the audio unit and the 'Rescue process was terminated' is played. 2N TELEKOMUNIKACE a.s., www.2n.cz 63/377...
  • Page 64 Warning Remember to set the rescue password (parameter 992) to activate the rescue function. The rescue process can only be activated on a cabin audio unit configured as the cabin (default audio unit setting). 2N TELEKOMUNIKACE a.s., www.2n.cz 64/377...
  • Page 65 You can connect a handset to the audio unit for better acoustic properties in noisy environments. You can connect an external siren to the audio unit for incoming call signalling. You can configure the machine room audio unit to be shared by multiple lifts. 2N TELEKOMUNIKACE a.s., www.2n.cz 65/377...
  • Page 66 ALARM memory – set 1 (011– 016). Push the ALARM button to call the control room or machine room audio unit configured as an intercom. The ALARM and TRIPHONY buttons shine even at relax. 2N TELEKOMUNIKACE a.s., www.2n.cz 66/377...
  • Page 67 There is a group of jumpers under the transparent front cover. Do not use any of them if the machine room is only intended for the given lift. The audio unit identifies itself as the machine room for the given lift. 2N TELEKOMUNIKACE a.s., www.2n.cz 67/377...
  • Page 68 The audio unit is intended for Lift8 audio unit bus connection exclusively. Do not connect it to other wires to avoid its damage or destruction. Maintain polarity while connecting the audio unit to avoid audio unit error. 2N TELEKOMUNIKACE a.s., www.2n.cz 68/377...
  • Page 69 Open the protective door on the audio unit and adjust the volume using the trimmer. Caution Use the trimmer to set the best acoustic properties eliminating feedback. Volume configuration only works in the HandsFree mode. 2N TELEKOMUNIKACE a.s., www.2n.cz 69/377...
  • Page 70 2N TELEKOMUNIKACE a.s., www.2n.cz 70/377...
  • Page 71 The audio unit calls the numbers configured in the ALARM memory – set 2 (021– 026). The ALARM button illumination (not required by default) helps you find and activate the audio unit easily in the dark. 2N TELEKOMUNIKACE a.s., www.2n.cz 71/377...
  • Page 72 The audio unit is not intended for outdoor installations. Electrical Installation Connectors The audio unit has one connector for bus connection. The second RJ-11 connector is used for handset connection. Both the connectors are under the side doors. 2N TELEKOMUNIKACE a.s., www.2n.cz 72/377...
  • Page 73 To set the cabin 2 audio unit, insert the jumper to the shaft bottom position (left jumper) and then select the audio unit position with the other jumper (cabin 2 roof, cabin 2, under cabin 2). Close the door and tighten the screw. 2N TELEKOMUNIKACE a.s., www.2n.cz 73/377...
  • Page 74 Do not connect it to other wires to avoid its damage or destruction. Maintain polarity while connecting the audio unit to avoid audio unit error. Caution The audio unit is powered via a 2-wire bus. Disconnection of these wires results in the audio unit switch-off. 2N TELEKOMUNIKACE a.s., www.2n.cz 74/377...
  • Page 75 Open the protective door on the audio unit and adjust the volume using the trimmer. Caution Use the trimmer to set the best acoustic properties eliminating feedback. Volume configuration only works in the HandsFree mode. 2N TELEKOMUNIKACE a.s., www.2n.cz 75/377...
  • Page 76 Before You Start Requirements Make sure that the lift wall is even. Make sure that the installation meets the standard requirements (ALARM button height and distance from the other lift buttons, e.g.). Product Completeness Check 2N TELEKOMUNIKACE a.s., www.2n.cz 76/377...
  • Page 77 Just drill holes into the cabin wall as shown in the figure below (also see the 1:1 figure on the product box). The larger hole is intended for cabling. Round the hole edges to avoid cable damage! Figure: Mounting Hole Dimensions for Audio Unit – Cabin Compact 2N TELEKOMUNIKACE a.s., www.2n.cz 77/377...
  • Page 78 Alarm call deactivation by terminals (on/off) polarity **) door opening Contact = contact control NO/NC contact **) (on/off) ALARM 2 Contact = contact control NO contact Alarm call activation from terminal (closing) Alarm set 2 2N TELEKOMUNIKACE a.s., www.2n.cz 78/377...
  • Page 79 The audio unit is intended for Lift8 audio unit bus connection exclusively. Do not connect it to other wires to avoid its damage or destruction. Connectors Figure: Connectors on Audio Unit – Cabin Compact (New Type) 2N TELEKOMUNIKACE a.s., www.2n.cz 79/377...
  • Page 80 Rotary Switch There is a glass-covered rotary switch on the audio unit front side. Use the switch to set ALARM/CANCEL (normal/inverted input) and audio unit type (cabin, cabin roof, cabin bottom, shaft bottom). 2N TELEKOMUNIKACE a.s., www.2n.cz 80/377...
  • Page 81 Tighten slightly. Position 7 – shaft bottom Positions 8, 9, 0 / not used (red bus LED flashing) ALARM and CANCEL Setting (Rotary Switch) Contact closing/voltage connection control of ALARM and CANCEL 2N TELEKOMUNIKACE a.s., www.2n.cz 81/377...
  • Page 82 The door opening signal must be active even during power outage. Note Make sure that delayed calling is configured to make the CANCEL input 2N TELEKOMUNIKACE a.s., www.2n.cz 82/377...
  • Page 83 Screw the 30 mm long M4 headless grub screws included in the audio unit package in place of the corner cover screws removed. Tighten the screws with an internal hexagon key wrench. Put the audio unit on the holes, apply the serrated lock washers from the outside 2N TELEKOMUNIKACE a.s., www.2n.cz 83/377...
  • Page 84 Replace the window and insert the hex key wrench in the bottom edge hole turning it right about 10 times until the window slides under the panel edge. Tighten the window applying a moderate force. 2N TELEKOMUNIKACE a.s., www.2n.cz 84/377...
  • Page 85 Connection of induction loop for hearing-impaired The induction loop for people with impaired hearing is part of the Compact cabin audio unit. No more accessories are required for the given case. 2N TELEKOMUNIKACE a.s., www.2n.cz 85/377...
  • Page 86 If you have mounted the connector pins correctly, use 1 bolt spacer (3) and 2 threaded spacers (4) to fit the module. Use a 5mm hex socket wrench to fit the spacers. 2N TELEKOMUNIKACE a.s., www.2n.cz 86/377...
  • Page 87 Tighten the 3 screws to fit the cover. Connect the to the mains supply. Warning While mounting the module, make sure that all the pins are fitted correctly into the connector to avoid module damage. 2N TELEKOMUNIKACE a.s., www.2n.cz 87/377...
  • Page 88 Remove the sealing ring from the cover. Be careful while mounting the module: push the antenna connector through the cover. Mount the module onto the externally threaded spacers (2) and connect it to the motherboard connector (1). 2N TELEKOMUNIKACE a.s., www.2n.cz 88/377...
  • Page 89 If you have mounted the connector pins correctly, use 1 bolt spacer (3) and 2 threaded spacers (4) to fit the module. Use a 5mm hex socket wrench to fit the spacers. 2N TELEKOMUNIKACE a.s., www.2n.cz 89/377...
  • Page 90 Slide and release the SIM card holder (Fig. 1). Tilt out the SIM card holder (Fig. 2). Insert the SIM card (Fig. 3). Replace the SIM card holder and lock it into position (Fig. 4). 2N TELEKOMUNIKACE a.s., www.2n.cz 90/377...
  • Page 91 Caution In places with a poor signal quality find an appropriate place or use a special (directional) antenna. Should you have DTMF transmission problems, set parameter 710 to 1 2N TELEKOMUNIKACE a.s., www.2n.cz 91/377...
  • Page 92 Should you have DTMF transmission problems, set parameter 710 to 1 (for GSM modules only). 2N TELEKOMUNIKACE a.s., www.2n.cz 92/377...
  • Page 93 If you have mounted the connector pins correctly, use 1 bolt spacer (3) and 2 threaded spacers (4) to fit the module. Use a 5mm hex socket wrench to fit the spacers. 2N TELEKOMUNIKACE a.s., www.2n.cz 93/377...
  • Page 94 Connect the CU to the mains supply. Warning While fitting the module, make sure that all the pins are fitted correctly into the connector to avoid module damage. Caution ® The A-Law codec is only supported in Lift8 2N TELEKOMUNIKACE a.s., www.2n.cz 94/377...
  • Page 95 2N TELEKOMUNIKACE a.s., www.2n.cz 95/377...
  • Page 96 Press the button to set up the call. The call duration is infinite. Repress the button to stop the call. The Fireman call setup is signalled by the Fireman audio unit LED (mounted on the PCB or carried externally from connector 8). 2N TELEKOMUNIKACE a.s., www.2n.cz 96/377...
  • Page 97 Fireman audio unit and the cabin and machine room audio units in one and the same lift shaft. If any of the machine room audio units is configured as the control centre (intercom), you can join in the Fireman call. 2N TELEKOMUNIKACE a.s., www.2n.cz 97/377...
  • Page 98 Button is not included. Before You Start Installation Conditions Make sure that the panel is ready for installation, check the speaker perforation area. Make sure that there is 65×130×20 mm of free space behind the panel. 2N TELEKOMUNIKACE a.s., www.2n.cz 98/377...
  • Page 99 1 printed cover Mounting Electronic Installation This audio unit is designed for mounting behind the lift control panel. Prepare the panel for installation as shown below: Figure: Cabin Audio Unit – Universal Mounting Hole Dimensions 2N TELEKOMUNIKACE a.s., www.2n.cz 99/377...
  • Page 100 While gluing choose such procedures or adhesives that prevent membrane damage by adhesives and volatile substances, or heat. We recommend you to keep the speaker sealed to eliminate vibrations and ensure electric insulation. 2N TELEKOMUNIKACE a.s., www.2n.cz 100/377...
  • Page 101 Can I use a longer cable for the speaker? You can use a longer cable for the speaker, but not for the microphone. Electric Installation Description of Terminals, Connectors and Jumpers Figure: Terminals, Connectors and Jumpers on Cabin Audio Unit – Universal Board 2N TELEKOMUNIKACE a.s., www.2n.cz 101/377...
  • Page 102 The lower pin defines the button count jumper connected – 1 button jumper unconnected – 2 buttons Note If an external LED is connected to connector 8, the LED 1 indicator will not be shining. 2N TELEKOMUNIKACE a.s., www.2n.cz 102/377...
  • Page 103 Loosen the four screws slightly and move the cover downwards. Remove the cover. Use the trimmer in the lower part of the electronics to adjust the volume (see the figure below). Caution Use the trimmer to set the best acoustic properties while eliminating feedback. 2N TELEKOMUNIKACE a.s., www.2n.cz 103/377...
  • Page 104 2 s) on the audio unit keypad (green LED shining) to join in the call. Push (for longer than 2 s) on the audio unit keypad (green LED flashing) to leave the call without terminating it. 2N TELEKOMUNIKACE a.s., www.2n.cz 104/377...
  • Page 105 While the button is pushed, no sound is transmitted from the other audio units. Release the button to allow the persons at the other audio units (cabin, machine room or machine room as intercom) to talk. 2N TELEKOMUNIKACE a.s., www.2n.cz 105/377...
  • Page 106 1x replaceable one-hole sealing for big bushing for thick cables 1x big blind with nut 1x small bushing with nut 1x big bushing packing 2x small bushing packings 4x (5 x 90) mm screws 4x "intelligent" (8 x 50) mm wall plugs 2N TELEKOMUNIKACE a.s., www.2n.cz 106/377...
  • Page 107 Terminals, Connectors and Jumpers on Fireman Audio Unit Board Terminals and Connectors Speaker connector 2 microphone connectors Audio unit bus Detent button (knob) connector Volume setting (trimmer) Configuration jumper Button connector (Push to talk) Servicing connector 2N TELEKOMUNIKACE a.s., www.2n.cz 107/377...
  • Page 108 Volume Setting Use the trimmer on the electronics board to adjust the volume (refer to the Description of Terminals, Connectors and Jumpers above). Caution Use the trimmer to set the best acoustic properties while eliminating feedback. 2N TELEKOMUNIKACE a.s., www.2n.cz 108/377...
  • Page 109 See below for an overview of mounting types and list of necessary components. Wall Mounting For concrete and steel structures, etc. What you need for installation: ® Lift8 Fireman only (no need for covering frame) 2N TELEKOMUNIKACE a.s., www.2n.cz 109/377...
  • Page 110 ® Lift8 Fireman Covering frame: contact your distributor Flush Mounting – Thermally Insulated Wall What you need for installation Longer screws (depending on the thermal insulation thickness) ® Lift8 Fireman Covering frame: contact your distributor 2N TELEKOMUNIKACE a.s., www.2n.cz 110/377...
  • Page 111 Flush mounting kit, Part No. 9151001 ® Lift8 Fireman Covering frame: contact your distributor Flush Mounting – Plasterboard What you need for installation Flush mounting kit for plasterboard, Part No. 9151002 ® Lift8 Fireman Covering frame: contact your distributor 2N TELEKOMUNIKACE a.s., www.2n.cz 111/377...
  • Page 112 Using different, lower-quality screws may lead to screw and surface corrosion! Make sure that no impurities get into the device (especially on the sealing and microphone sound guides) after removing the front panel. 2N TELEKOMUNIKACE a.s., www.2n.cz 112/377...
  • Page 113 Remove the front panel from the audio unit. Select the holes for the cables. Choose and mount the enclosed bushing depending on the count of cables: two-hole, one-hole or both types of bushings. Fill the other holes with the packing included. 2N TELEKOMUNIKACE a.s., www.2n.cz 113/377...
  • Page 114 Select the holes for the cables. Insert the packings in the other holes. Use the cable bushings or some sealing to avoid insect or water penetration. Mount a small bushing into the audio unit bottom hole too. Put a frame on the audio unit. 2N TELEKOMUNIKACE a.s., www.2n.cz 114/377...
  • Page 115 Although unnecessary for the audio unit function, the sealing helps protect the wall against dampening due to water leakage. Do not complete the mounting procedure until you have connected the audio unit electrically – refer to Electric Installation. 2N TELEKOMUNIKACE a.s., www.2n.cz 115/377...
  • Page 116 Flush Mounting – Hollow Bricks It is practically impossible to fit plugs into hollow bricks because the inner brick walls are too thin for drilling. Therefore, use the flush mounting kit and follow the instructions included therein. 2N TELEKOMUNIKACE a.s., www.2n.cz 116/377...
  • Page 117 Flush Mounting – Plasterboard Use the flush mounting kit for plasterboard walls and follow the instructions included therein. 2N TELEKOMUNIKACE a.s., www.2n.cz 117/377...
  • Page 118 The I/O Modules are connected serially (in line). Do not use parallel connection to avoid system instability. Connect the termination resistance connecting jumper to the last device (Splitter or I/O Module furthest from the CU). See the figures below for terminal layout details. I/O Module – Lower Side 2N TELEKOMUNIKACE a.s., www.2n.cz 118/377...
  • Page 119 CU maintaining polarity (power + -, audio + -, data + - ) – see the I/O Module cover. Connect the devices serially (in line). Parallel connection is not allowed. Refer to the CU section for more details. 2N TELEKOMUNIKACE a.s., www.2n.cz 119/377...
  • Page 120 Connect the jumper to the first and last device (CU, splitter or I/O module) on the bus. Refer to the CU section for more details. By default, the termination resistance jumper is off. 2N TELEKOMUNIKACE a.s., www.2n.cz 120/377...

  • Page 121: Led Indicators

    This LED is on when the given input is active, i.e. nominal voltage for Input 1–4 detection of logic 1 is detected on it. Logic Orange This LED is on when the given input is active, i.e. the given relay is closed. Output 1– 2N TELEKOMUNIKACE a.s., www.2n.cz 121/377...
  • Page 122 5 A per contact. Never exceed this limit to avoid system damage. When the relay is closed, the respective LED signals this state. You can configure the relay function in ® Service Tool application. Example of Output Relay Connection 2N TELEKOMUNIKACE a.s., www.2n.cz 122/377...
  • Page 123 Wall Mounting Use appropriate wall plugs and screws for mounting (not included in the delivery). Hang the device using the pre-drilled holes on the device bottom. Wall Mounting 2N TELEKOMUNIKACE a.s., www.2n.cz 123/377...
  • Page 124 A wrong mounting procedure may lead to damage to the electronics due to water infiltration. The splitter circuits are constantly under voltage and water leakage causes electrochemical reaction. No warranty can be claimed for products damaged in this manner! 2N TELEKOMUNIKACE a.s., www.2n.cz 124/377...

  • Page 125: Camera Module

    485 type. The camera module can work with the Central Unit (CU), or autonomously. It contains a microSD card slot for recording images in variable intervals. ® Connect the camera module to the CU or splitter via a 2-wire bus to support the 2N Lift8 communication.
  • Page 126 Connect the camera module via a 2-wire bus (audio unit bus) to the CU or splitter maintaining polarity. Audio unit bus 1... Audio unit bus + 2... Audio unit bus – Warning ® Maintain the connection polarity to make the Lift8 system work correctly. 2N TELEKOMUNIKACE a.s., www.2n.cz 126/377...

  • Page 127: Mode Switch

    Connect the camera module to the LAN if the IP camera is installed in the LAN. If the camera module is connected to the Lift8 system, use the Service Tool for configuration (refer to Subs. 5.3 – Service Tool – Use for more details).
  • Page 128 Select Set static IP address to a camera to activate the DHCP server to assign the defined address to the camera. If the static IP address is already set for the IP camera, it is unnecessary to enable the server. 2N TELEKOMUNIKACE a.s., www.2n.cz 128/377...
  • Page 129 Caution The RS232 and RS485 cameras work without a local power supply too in the Lift8 system only if they have a low current consumption. Saving files to an SD card does not work without a local power supply. 2N TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 130 The LED is on when the camera is connected and configured properly. The LED flashes to indicate active recording. Orange The LED is on when the camera is connected and configured properly. The LED flashes to indicate active recording. 2N TELEKOMUNIKACE a.s., www.2n.cz 130/377...
  • Page 131 Caution The OK LED is flashing and ERR LED is illuminated when the unit is being upgraded. Caution ® Use the Lift8 Service Tool application to set the camera type and other parameters. Camera Module Setting ® ® Set the...
  • Page 132 DHCP server option is enabled for the camera. Refer to network.cfg for more setting details. Having set the network parameters, you can open the Internet browser to go on configuring via the web interface (see the Web Interface below). 2N TELEKOMUNIKACE a.s., www.2n.cz 132/377...
  • Page 133 Username   admin IP camera access user name (login) Password   IP camera access password Caution - IP camera Set resolution and compression in your IP camera configuration. Each IP camera has a different URL. 2N TELEKOMUNIKACE a.s., www.2n.cz 133/377...
  • Page 134 Parameter Default Note name value password The password set via password.cfg is encrypted when an SD card is inserted in the camera module. Upozornění The user name is always Admin (not respecting the upper/lower case). 2N TELEKOMUNIKACE a.s., www.2n.cz 134/377...

  • Page 135: Microsd Card

    Standalone Camera Module Upgrade ® Refer to 2N Lift8 Camera Module at www.2n.cz for the latest firmware (ln_app_camera.bin). Download the file to a microSD root directory. When you insert the microSD card, the file (ln_app_camera.bin) will be loaded onto the dataflash (yellow LEDs flashing) and then the module will get restarted.
  • Page 136 User name: Admin Password: 2n 2N TELEKOMUNIKACE a.s., www.2n.cz 136/377...
  • Page 137 See below for the mounting types and necessary components. Install the device on sites not exposed to water leakage or condensation. Wall Mounting Use appropriate wall plugs and screws for mounting (not included in the delivery). Hang the device using the pre-drilled holes on the device bottom. 2N TELEKOMUNIKACE a.s., www.2n.cz 137/377...
  • Page 138 A wrong mounting procedure may lead to damage to the electronics due to water infiltration. The Camera Module circuits are under constant voltage and water leakage causes electrochemical reaction. No warranty can be claimed for products damaged in this manner! 2N TELEKOMUNIKACE a.s., www.2n.cz 138/377...
  • Page 139 Product Completeness Check Check whether the product package is complete before installation. The RS232 module package contains: 1 electronics board (RS232 module) 2 long threaded spacers, 1 short screwed spacer 1 screw RS232 cable cable bushing 2N TELEKOMUNIKACE a.s., www.2n.cz 139/377...
  • Page 140 Now mount the RS232 module. Be careful while putting the module on the pins. Make sure that you have connected all the pins to the module connector. Having fitted the pins into the connector correctly, you can fix the module using 3 screws (see Fig.). 2N TELEKOMUNIKACE a.s., www.2n.cz 140/377...
  • Page 141 <CR> = Enter 145<CR>sms text<Ctrl+z> 145 – international number or without apostrophes (including +) AT+CMGS=603123456, 129 – national number 145<CR>sms text<Ctrl+z> AT+CMGF= AT+CMGF=1 Select SMS   mode ATE1 ATE1 Enable echo Return edited characters to the terminal 2N TELEKOMUNIKACE a.s., www.2n.cz 141/377...
  • Page 142 Serial Port Configuration You can only set the transmission rate of 9600–115200 bauds for the serial port. The other parameters are preset: Bits per word 8 bits Parity no parity Stop bits 1 stop bit 2N TELEKOMUNIKACE a.s., www.2n.cz 142/377...
  • Page 143 The audio unit is initialised first – the ALARM button is blue-backlit. The ALARM button blue backlight flashes to indicate an upgrading process. The audio unit stops shining after upgrade and is ready for use. 2N TELEKOMUNIKACE a.s., www.2n.cz 143/377...
  • Page 144 Product Completeness Check Check the product package for completeness before installation: ® 1 2N Lift8 Shaft Antivandal 1 Torx 10 / Torx 20 double-ended spanner Bushings (extra package): 1x big two-hole, sealed bushing with nut 1x replaceable big one-hole bushing seal for thick cables...
  • Page 145 Unscrew the 4 screws using the Torx 20 spanner enclosed and remove the audio unit front cover to reveal the electronics board. Desription of Terminals, Connectors and Jumpers Audio Unit – Fireman Terminals, Connectors and Jumpers 2N TELEKOMUNIKACE a.s., www.2n.cz 145/377...
  • Page 146 Set the audio unit location using the configuration jumper (7). Jumper setting Audio unit location shaft bottom no jumper over the cabin jumper up under the cabin jumper down 3. Replace the cover and tighten the 4 screws. Caution Avoid duplicate audio unit settings. 2N TELEKOMUNIKACE a.s., www.2n.cz 146/377...

  • Page 147: Volume Control

    Volume Control Set the required volume using the trimmer (refer to the Description of Terminals, Connectors and Jumpers above) on the electronics board. Caution Use the trimmer to set the best acoustic properties eliminating feedback. 2N TELEKOMUNIKACE a.s., www.2n.cz 147/377...
  • Page 148 An improper mounting may result in the audio unit not being waterproof. Water leakage may damage the electronics. ® Lift8 Shaft Antivandal is assembled with stainless steel screws. If you lose them, never use other screws to avoid corrosion and screw appearance deterioration! 2N TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 149: System Configuration

    3. System Configuration The system is supplied pre-configured. ® This section describes the Lift8 configuration. There are three ways how to ® program Lift8 3.1 Lift8 Programming 3.2 Table of Parameters 3.3 SMS Configuration 2N TELEKOMUNIKACE a.s., www.2n.cz 149/377...
  • Page 150 3.1 Lift8 Programming ® The advantage of the Lift8 (hereinafter referred to as ) system is that it is programmed via the where all the parameters are stored. Hence, you do not have to reconfigure anything to replace an Audio Unit and you can program just one multiple lift systems, for example.
  • Page 151 If you have programmed and stored a value other than the required one, you can re-enter the value of course. 2N TELEKOMUNIKACE a.s., www.2n.cz 151/377...

  • Page 152: Troubleshooting

    In such cases, try some other equipment (a digital PBX, e.g.) or the machine room telephone set. If the machine room or PSTN programming attempts fail too, you have probably entered an invalid password. Programming via Service Tool ® Refer to the Service Tool section (Section 5) for details. 2N TELEKOMUNIKACE a.s., www.2n.cz 152/377...
  • Page 153 Set 1 – ALARM up to 16 empty   ® button memory digits: 0–9 via a PC (use the 2N Service Tool Set 1 – ALARM up to 16 empty   button memory digits: 0–9 Set 1 – ALARM...
  • Page 154 4= CPC KONE, 5 = P100, 6 = autodetection DTMF protocol (CPC Antenna /P100), 7 = CPC Antenna 2N ext, 8 = CPC KONE 2N ext, 9 = P100 2N ext 2N ext is a protocol that transmits the shaft...
  • Page 155 Set 2 – ALARM up to 16     ® button memory via a PC (use the 2N digits: 0–9 Service Tool If set 2 of the ALARM Set 2 – ALARM up to 16    ...
  • Page 156 4= CPC KONE, 5 = P100, 6 = autodetection DTMF protocol (CPC Antenna /P100), 7 = CPC Antenna 2N ext, 8 = CPC KONE 2N ext, 9 = P100 2N ext 2N ext is a protocol that transmits the shaft...
  • Page 157 DTMF (1), checking call 2 = confirmation of memory 1–6 picking up (supported only for GSM/UMTS /VoIP), 3 = CPC Antenna, 4= CPC KONE, 5 = P100, 6 = autodetection DTMF protocol (CPC Antenna 2N TELEKOMUNIKACE a.s., www.2n.cz 157/377...
  • Page 158 Parameter name Range of values Default value Note Info /P100), 7 = CPC Antenna 2N ext, 8 = CPC KONE 2N ext, 9 = P100 2N ext 2N ext is a protocol that transmits the shaft number and audio unit...
  • Page 159 A= output 1 Default output ABCD empty B= output 2 state of IO C= output 3 module 2 D= output 4 Default output ABCD empty 0= output off state of IO 1= output on module 3 2N TELEKOMUNIKACE a.s., www.2n.cz 159/377...
  • Page 160 If there is a DTMF change transfer problem in the GSM network, enable this parameter. Set time hhmm   Read the current time   setting and configure a new one if necessary. * 2N TELEKOMUNIKACE a.s., www.2n.cz 160/377...
  • Page 161 When the tone is detected, a number is dialled from a memory (common dial-in for all memories: 011–016, 021– 026, 071–076, 081–086). 2N TELEKOMUNIKACE a.s., www.2n.cz 161/377...
  • Page 162 (if there is an pick-up incoming call from PSTN). Max. call time 0–1000 s 120 s The call can be extended   by a call-extending command (DTMF 4). 0 = disabled (never-ending call). 2N TELEKOMUNIKACE a.s., www.2n.cz 162/377...
  • Page 163 This applies to PSTN   line test time modules only. If the line is OK, the test is carried out every hour. Lift8 seizes the line and tries to detect the dialtone. If no dialtone is detected, the line test is carried out...
  • Page 164 Par. Parameter name Range of values Default value Note Info 5 minutes). If the dialtone is detected again, Lift8 will pass into the "Line OK" state. Min. dialtone 200–2000 ms 400 ms The tone must be longer   period than a half-period of the busy tone! Min.
  • Page 165 Private mode 0–24 hours Private mode allows   muting of the ® microphone on the 2N Lift1 . Possible setting of this parameter is: 0 – two way audio enabled always. 1–X, no password in the rescue mode, time...
  • Page 166 13 are set in parameters 975–979 or 971. Intercom up to 16 digits: empty Provide lift identification   identification 0–9 for foreigners, for number example. If not filled in, the serial number is used. 2N TELEKOMUNIKACE a.s., www.2n.cz 166/377...
  • Page 167 Cautions: sequence by User messages to pressing 3 after recorded into the CU call ® confirmation with the aid of the 2N Service Tool Call end up to 10     sequence announcements in sequence Checking call 0–6...
  • Page 168 Values for Mon, Tue,   checking call Wed, Thu, Fri, Sat, Sun: 0 = do not call 1 = call Example: 1000100 = the checking call will be made on Mondays and Fridays. 12345   2N TELEKOMUNIKACE a.s., www.2n.cz 168/377...
  • Page 169 1001 Enable data 0–1 Permit the use of the GSM   /UMTS module connection to the provider's data network. 1002     Configure the mobile   provider's access APN server. ** 2N TELEKOMUNIKACE a.s., www.2n.cz 169/377...
  • Page 170 1104 DNS server     Set the DNS server IP   address. ** 1105 SIP server     Set the IP address for   connection to the counterparty (PBX, operator). ** 2N TELEKOMUNIKACE a.s., www.2n.cz 170/377...
  • Page 171 Set the time zone (UTC) From version ® in which Lift8 1.7.2 installed. ** 1.8.0 Change value 1151 Synchronisation 60–86400 3600 From ® Define how often 2N period version Lift8 shall synchronise 1.7.2 with the SNTP server. ** 2N TELEKOMUNIKACE a.s., www.2n.cz 171/377...
  • Page 172 Enable the data client From (refer to 7.1 Control Panel version for details). ** 1.6.0 1.7.2 Range change 1231 Server IP   empty From ® Set the Lift8 Server address version IP address. ** 1.6.0 2N TELEKOMUNIKACE a.s., www.2n.cz 172/377...
  • Page 173 1.6.0 Control Panel. ** ® * This parameter can only be configured via the voice menu (incoming call to 2N Lift8 or via the machine room audio unit). ® ** This parameter can only be configured via the...
  • Page 174 How to Record Announcement From PC ® ® Apply the Service Tool to record user announcements and numerals to Lift8. ® Refer to Subs. 5.3, Service Tool – Use, for details. 2N TELEKOMUNIKACE a.s., www.2n.cz 174/377...

  • Page 175: Sms Configuration

    (918653E 2N Lift8 VoIP Module) modules! Caution ® Every SMS must meet the conditions listed below to be sent to 2N Lift8 successfully. If not, the SMS will be ignored, no changes will be made. 2N TELEKOMUNIKACE a.s., www.2n.cz 175/377...

  • Page 176: Function Description

    You can set all the Lift8 CU parameters via configuration SMS messages, including those requiring a string (word, IP address, etc.). Every configuration SMS message must include the following parts: L8 header for unique identification of the 2N 2N TELEKOMUNIKACE a.s., www.2n.cz 176/377...
  • Page 177 SMS-based configuration obeys the same rules and limitations as configuration via an application or a phone (maximum length, value ® range, two-digit limitation, etc.). If any of these rules is not met, 2N Lift8 shall not set the parameters and shall send an error SMS specifying the wrong parameter.
  • Page 178 Note The language localisation of the SMS reply is based on the voice menu recorded. Cs and en texts are available at present. Slovak uses cs, the other languages use en. 2N TELEKOMUNIKACE a.s., www.2n.cz 178/377...
  • Page 179 4.3 Function Description (for Advanced Users) 4.4 Call Confirmation Types 4.5 Lift Blocking Function 4.6 Four-Lift Version 4.7 Intercom Function 4.8 System Completeness Check 4.9 ALARM Button Test 4.10 Rescue Activation and End 4.11 Battery Replacement 2N TELEKOMUNIKACE a.s., www.2n.cz 179/377...
  • Page 180 TRIPHONY is active between the lifts. The yellow LED indicator is illuminated if connection is being made with the control centre. The green LED indicator is illuminated if connection has been made and confirmed by the control centre. 2N TELEKOMUNIKACE a.s., www.2n.cz 180/377...
  • Page 181 Press 7 to dial the cabin 2 roof Press 8 to dial the lift cabin 2 bottom Press # to return to the main menu Press 9 for administration Press 1 to enter the programming menu 2N TELEKOMUNIKACE a.s., www.2n.cz 181/377...
  • Page 182 Press 4 for IO module administration Press # to return to the main menu Press # t o end the call Note selection serves primarily for the configuration – refer to S. 3 – Configuration. 2N TELEKOMUNIKACE a.s., www.2n.cz 182/377...
  • Page 183 (DISA), offers you another function to get through to the required audio unit. Incoming calls are time limited as outgoing calls and are processed in the same way (extension, termination). 2N TELEKOMUNIKACE a.s., www.2n.cz 183/377...
  • Page 184 Press 8 to dial the lift cabin 2 bottom Press # to return to the main menu Press 9 for administration Press 1 to enter the programming menu Press 2 to terminate the rescue process 2N TELEKOMUNIKACE a.s., www.2n.cz 184/377...
  • Page 185 Alarm function. ® This function operates only if you are calling Lift8 via a PSTN, GSM, UMTS or VoIP network. Note ® selection serves primarily for Lift8 configuration – refer to S. 3 – Configuration. 2N TELEKOMUNIKACE a.s., www.2n.cz 185/377...
  • Page 186 DTMF signalling is mixed with the call and thus may be masked by certain speech tones or noise. This, however, is not a defect of the product. 2N TELEKOMUNIKACE a.s., www.2n.cz 186/377...
  • Page 187 Press the TRIPHONY button to enter the machine room voice menu get through to the other audio units of the same lift and set up triphony with the other shafts. 2N TELEKOMUNIKACE a.s., www.2n.cz 187/377...
  • Page 188 Press 8 to dial the lift cabin 2 bottom Press # to return to the main menu Press 9 for administration Press 1 to enter the programming menu Press 2 to terminate the rescue process Press 3 for communicator info 2N TELEKOMUNIKACE a.s., www.2n.cz 188/377...
  • Page 189 Incoming calls are time limited as outgoing calls and are processed in the same way (extension, termination). Press 0 in the voice menu for connection with the last-calling audio unit. 2N TELEKOMUNIKACE a.s., www.2n.cz 189/377...
  • Page 190 Incoming Call Voice Menu ® Welcome, this is a 2N Lift8 communicator Press 0 to dial the last-calling audio unit Enter the lift number X to dial another audio unit Press 1 to dial the lift cabin Press 2 to dial the cabin roof...
  • Page 191 = not applicable ns = not served (ns* for machine room configured as the control centre: the Fireman call is entered whenever the phone is answered) q = put in queue S = suspends ongoing activity 2N TELEKOMUNIKACE a.s., www.2n.cz 191/377...
  • Page 192 A control centre with a PC workplace with the Lift8 Server receives calls ® automatically as configured. Configure the server using the Lift8 Control Panel Overview of Announcements Announcement Meaning “Please wait for The announcement is played to the lift user when the call is being set connection”...
  • Page 193 The time limit has expired during programming. A higher-priority call request has arrived. 2N TELEKOMUNIKACE a.s., www.2n.cz 193/377...
  • Page 194 Ringing tone L8 waits for the defined time (parameter 913). Continuous tone L8 hangs up and dials the next number. (on PBX line, e.g.) L8 hangs up immediately and dials the next number. DTMF char 2N TELEKOMUNIKACE a.s., www.2n.cz 194/377...
  • Page 195 The only difference is that the confirmation-less mode detects the ringing tone and recognises that the called party is off-hook (i.e. answers the call) when the ringing tone terminates before the timeout end. The message speaker cannot be controlled using buttons 2N TELEKOMUNIKACE a.s., www.2n.cz 195/377...
  • Page 196 Used wherever the counterparty is equipped with the required SW. When the line is answered, a DTMF character is sent and the lift is identified. The call is either switched to voice communication (alarm call) or confirmed automatically and terminated (check call), as the case may be. 2N TELEKOMUNIKACE a.s., www.2n.cz 196/377...
  • Page 197 If such troubles occur, we recommend you to change the CPC Antenna /P100 (3/5) settings. 7, 8, 9. CPC (Antenna and KONE), P100 2N ext (for Alarm Calls only) The protocols work identically like for CPC (items 3 and 4) and P100 (item 5). The only difference is that they transmit shaft numbers and audio unit types too.
  • Page 198 – the lift gets blocked when the internal bus gets disconnected. ® Lift8 is off – the lift gets blocked immediately. Caution The PSTN line test is carried out every hour. If an error is detected, the line test is repeated every 2 minutes until the line is evaluated OK again.
  • Page 199 Caution This function may be mandatory if the applicable regulations valid for the country and time of installation require so. 2N TELEKOMUNIKACE a.s., www.2n.cz 199/377...
  • Page 200 Connect the machine room audio unit to the internal splitter if necessary. Display of 4-Cabin Connection in Service Tool Warning Make sure that each audio unit is assigned a different type (cabin roof, cabin, cabin bottom, shaft bottom). 2N TELEKOMUNIKACE a.s., www.2n.cz 200/377...
  • Page 201 If you set parameter 994 to 0, you can connect up to 8 lift shafts and up to 5 audio units to each shaft (machine room, cabin roof, cabin, cabin bottom, shaft bottom). 8-Lift Configuration Caution Up to 7 audio units can be connected to one shaft in versions 2.0.0 and higher (two-cabin lifts). 2N TELEKOMUNIKACE a.s., www.2n.cz 201/377...
  • Page 202 Connection two-cabin lift. 2N TELEKOMUNIKACE a.s., www.2n.cz 202/377...
  • Page 203 Press the ALARM button on any audio unit (except for the machine room ® audio unit set as the control centre) to start the process. Upon the press, 2N Lift8 calls the pre-set machine room – control centre audio unit.
  • Page 204 PSTN, GSM, UMTS and VoIP networks (depending on the module used). To set up a check call to a machine room audio unit, you can set the number as described in the Alarm – Intercom subsection above. 2N TELEKOMUNIKACE a.s., www.2n.cz 204/377...
  • Page 205 Use the RESET button again to make the system monitor all the audio units added later to the system. ® Such audio units are displayed in the Supervision - Added units menu in the 2N Service Tool ® Display of Audio Units to Be Checked in...
  • Page 206 An audio test is considered unsuccessful if it fails three times. The test is carried out three times in 1-hour intervals. Audio Error Event In version 2.3 and higher an event can inform of an unsuccessful audio test. Use the 2N ® Service Tool Events menu for audio error configuration.
  • Page 207 CU. It takes CU some time (several tens of seconds) to ® find out that all the units have been disconnected. Therefore, use the 2N Service Tool to check whether all the units have logged out. Then press and hold RESET until all the LEDs light up red.
  • Page 208 This function informs that the ALARM button got stuck in the lift cabin. Set the timeout in seconds after which the button shall be considered jammed in ® parameter 969 (ALARM button test). Then, the event defined via the 2N Service Tool Events menu (Jammed button) will be executed.
  • Page 209 Multiple events can be set up (output activation + operational call, e.g.). SMS can be sent only if the GSM/UMTS module is installed. If you set the operational call option and CPC/P100 2N ext confirmation, the audio unit type (cabin 1 or 2) and shaft number is displayed for the ®...
  • Page 210 2N TELEKOMUNIKACE a.s., www.2n.cz 210/377...

  • Page 211: Battery Replacement

    Operational call – this call is set up to the number defined in parameters 081–088 (Operational call) and uses CPC Antenna, CPC KONE or P100 for transmissions Caution SMS can be sent only if the GSM/UMTS module is installed. 2N TELEKOMUNIKACE a.s., www.2n.cz 211/377...
  • Page 212 5.1 Installation and Login 5.2 Introduction to Application 5.3 Use ® Refer to the Lift8 product pages at www.2n.cz , download section, for the latest FW version. You can use this link from the online manual. 2N TELEKOMUNIKACE a.s., www.2n.cz 212/377...
  • Page 213 Now the application will ask you to enable transmission of system data and software use surveys to help the 2N TELEKOMUNIKACE a.s. company improve the software quality, availability and performance. No confidential data shall be sent. You can participate in this effort voluntarily and cancel sending statistic data any time.
  • Page 214 PC. Finally, you will be asked whether you really want to delete the existing configuration files. If you click NO, your configuration will be preserved. 2N TELEKOMUNIKACE a.s., www.2n.cz 214/377...
  • Page 215 500 MB of free disk space at least. ® Now the Lift8 Service Tool is ready for use. Click the shortcut item on the desktop (see the figure below) or select the Start item to start the application. ® Lift8...
  • Page 216 ® Connect. The Lift8 Service Tool automatically finds the connected on the PC and starts downloading parameters and logs. Having completing the download, the 2N ® Lift8 Service Tool is ready for work. Warning ® Make sure that the USB port driver for the...
  • Page 217 If there is no Lift8 selection, go one step back. Here enter the path to the driver file on the local disk and get the driver installed. The typical path is C:\Program Files (x86)\2N ... \ServiceTool\inf 2N TELEKOMUNIKACE a.s., www.2n.cz 217/377...
  • Page 218 Equivalent Intel Quad Core i7 3,4 GHz 8 GB 500 GB 100 Mbps Ethernet ( Other Dedicated Sound card ( User sound record ) Dedicated Graphics card Caution Default values for connection: Password: 2n Port: 7007 Password: 2n 2N TELEKOMUNIKACE a.s., www.2n.cz 218/377...
  • Page 219 CU and quit the program. The Setting submenu includes a Statistics window: confirm the request to enable transmission of your system data and software use surveys to help the 2N TELEKOMUNIKACE a.s. company improve the software quality, availability and performance within the applicable law.
  • Page 220 APN server to the SIM card if UMTS / GSM data transmission is allowed and configured. If data flow is disallowed, incorrectly configured or not supported by the SIM, the address will be 0.0.0.0. Maximum Application Display with Real-Time Device State 2N TELEKOMUNIKACE a.s., www.2n.cz 220/377...
  • Page 221 DNS server. Finally, like with the GSM / UMTS module, you can see the current battery and charger states. If you use a PSTN module, the line state and battery charging state will only be displayed. Real-Time Device State for VoIP Module 2N TELEKOMUNIKACE a.s., www.2n.cz 221/377...
  • Page 222 Connect device switches the user into the 'Connect to device' menu. New group helps you create a new connection group in the Connect to device screen. New server helps you create a new connection in the Connect to device screen. 2N TELEKOMUNIKACE a.s., www.2n.cz 222/377...
  • Page 223 Find next helps you find another occurrence of the set string (word). Read from device downloads the current settins and logs from the Save to device helps you save new parameters into the memory. 2N TELEKOMUNIKACE a.s., www.2n.cz 223/377...
  • Page 224 Click Load script to load a script from the backup file and delete the original script. Click Open directory to load video files from a disk/SD card. 2N TELEKOMUNIKACE a.s., www.2n.cz 224/377...
  • Page 225 Print HW setup – diagram helps you print out the current Lift8 HW settings as an image. ® Print HW setup – text helps you print out the current Lift8 HW settings as a text. Upgrade starts FW uploading to the 2N TELEKOMUNIKACE a.s., www.2n.cz 225/377...
  • Page 226 CU too. Open from file and save to device opens a file viewer for you to select the licence file for your This file will be downloaded to the upon confirmation. 2N TELEKOMUNIKACE a.s., www.2n.cz 226/377...
  • Page 227 5.3 Use Upon the application launch, you get to the Configuration main menu and then the ® Parameters – Basic menu, where you can find almost all the 2N Lift8 Central Unit settings. You are in the offline configuration, which you can modify, save into a file and prepare for download into the any time later.
  • Page 228 Click the funnel symbol in the selected column to activate the filter. Activation is indicated by a colour change of the funnel symbol; see the figure below. Left – Inactive Filter, Right – Active Filter 2N TELEKOMUNIKACE a.s., www.2n.cz 228/377...
  • Page 229 A grey icon and greyish 'Not connected' description indicate an unconnected camera module. A yellow-highlighted icon plus a green 'Connected' text indicate that the camera module is connected to the CU and the camera is online. See the figure below. 2N TELEKOMUNIKACE a.s., www.2n.cz 229/377...
  • Page 230 IP-Cam username is IP camera access user name (login). IP-Cam password is IP camera access password. The DHCP server in the camera module ensures that the connected camera should always get the same 2N TELEKOMUNIKACE a.s., www.2n.cz 230/377...
  • Page 231 .mjpg file in hours in the Record limit/file parameter for memory card saving. The IP camera configuration section also includes DHCP settings and camera module IP configuration. Refer to Subs. 2.12. for more setting and function details. IP Camera Configuration RS232 Camera Configuration 2N TELEKOMUNIKACE a.s., www.2n.cz 231/377...
  • Page 232 The other two buttons help turn the image left or right to optimise the view if the camera scans under the angle of 90°, for example. Close the window to quit the preview. Camera Window 2N TELEKOMUNIKACE a.s., www.2n.cz 232/377...
  • Page 233 Surveillance menu. Activation action specifies the action to be executed whenever the input becomes active and Deactivation action defines the action after the input passes into the inactive state. See the Action menu below for 2N TELEKOMUNIKACE a.s., www.2n.cz 233/377...
  • Page 234 Send SMS, where you enter a phone number and SMS text of the maximum length of 160 or 70 characters depending on the encoding type. Use GSM 03.38 or UCS 2 for diacritics and non-standard character sets. One SMS is sent at a time. Long, multipart 2N TELEKOMUNIKACE a.s., www.2n.cz 234/377...
  • Page 235 This solution is useful for installations where identical parameters are defined and can be simply copied to multiple central units. The LUA open-source programming language is used for the script. Refer to www.lua.org for more details. 2N TELEKOMUNIKACE a.s., www.2n.cz 235/377...
  • Page 236 PC disk. Click Load script to load a file from the disk and add it to the script editing field. Click Load configuration on the Basic tab to save the completed script to the device. The functions below are available. 2N TELEKOMUNIKACE a.s., www.2n.cz 236/377...
  • Page 237 Rescue end – the event is executed when the rescue process has been completed. Refer to Subs. 4.10 for more details. Audio error – the event is activated when the audio test fails for three times. Refer to Subs. 4.8 for more details. 2N TELEKOMUNIKACE a.s., www.2n.cz 237/377...
  • Page 238 , the CU shall make a call to the number defined in the error call set: parameters 081–086. The error information is then transmitted via CPC or P100. Click Save to device to save the actions into the device. 2N TELEKOMUNIKACE a.s., www.2n.cz 238/377...
  • Page 239 Level and Source, which define the log type and source respectively. Message includes the information itself. The State parameter above the table specifies how many logs (rows) have been read and the log start/end time. Logs Menu 2N TELEKOMUNIKACE a.s., www.2n.cz 239/377...
  • Page 240 Custom Date and Time Format Strings rules (see here for details, e.g.). Auto refresh logs is the last option. Set the Refresh rate in minutes a tick off Autoscroll to display the latest log row all the time. Advanced Settings Menu 2N TELEKOMUNIKACE a.s., www.2n.cz 240/377...
  • Page 241 Unit name (CU = Central Unit, AU = audio unit, SPL = splitter, CAM = camera module, IO = I/O module) line Line type (6 = 6-wire, 2 = 2-wire) addr Unit address txpkt Count of packets sent txbytes Count of bytes sent 2N TELEKOMUNIKACE a.s., www.2n.cz 241/377...
  • Page 242 The simplest is to remove the SD card from the camera module respecting the SD card connection/disconnection rules described in Subs. 2.12., connect the SD card to your PC and copy the data to a local disk directory. 2N TELEKOMUNIKACE a.s., www.2n.cz 242/377...
  • Page 243 Use the scroll bar or set the playing rate to view the video more quickly (1 to 10 times). Find the count of images in the file and the currently displayed picture in the menu. 2N TELEKOMUNIKACE a.s., www.2n.cz 243/377...

  • Page 244: User Messages

    User Messages User Messages helps you replace the default system announcements with user ® messages. Load these messages from a file or, in the correct format, via the 2N Lift8 Service Tool. Use the microphone connected to your PC to record the messages.
  • Page 245 The output volume value in the application does not affect the master volume of the record to be saved into the . Thus, if the recorded volume is too low, record the message once again and louder. 2N TELEKOMUNIKACE a.s., www.2n.cz 245/377...
  • Page 246 Thus, optimise the message time to record all of your messages. Device ® Device menu provides information on the Lift8 Central Unit connected: basic parameters and text/graphic diagram of available Audio Units and splitters. In addition, you can upgrade the here too. 2N TELEKOMUNIKACE a.s., www.2n.cz 246/377...
  • Page 247 Enter the existing password into the Current password and the new password into the New password. Click Save password to device to confirm and save the new setting. Note ® Remember to change the password in the 2N Lift8 Service Tool configuration too for future connections. Upgrade...
  • Page 248 Select this option and click Upgrade to reset factory default values upon upgrade. This action will only be performed together with new FW, Bootloader or Voice menu loading. To reset the default values only, use the Configuration menu. 2N TELEKOMUNIKACE a.s., www.2n.cz 248/377...
  • Page 249 . Enter a greater portion of the IMSI code to specify the SIM cards to be ® used in one network. You can add up to 10 IMSI codes to the licence. Contact your 2N Lift8 supplier or the manufacturer's Technical Support department ( sales@2n.cz...
  • Page 250 The brief description to the left of the audio unit includes the Audio Unit serial number, type and current state. 2N TELEKOMUNIKACE a.s., www.2n.cz 250/377...
  • Page 251 LED colour change and text notification, which provides information on the module, input and signal value that initiated the event. This notification is displayed in a special pop-up window, which is not closed automatically but closing 2N TELEKOMUNIKACE a.s., www.2n.cz 251/377...
  • Page 252 /output. You can also select the active/inactive input/output state colour in the same menu to simplify the visual state identification. The logic state of the given object (input/output) is signalled with digits 0/1 in a colour ring. 2N TELEKOMUNIKACE a.s., www.2n.cz 252/377...
  • Page 253 6. Lift8 Server Here is what you can find in this section: 6.1 Installation and Licensing 6.2 Use ® Refer to the Lift8 product pages at www.2n.cz , download section, for the latest FW version. You can use this link from the online manual.
  • Page 254 6.1 Installation and Licensing ® ® Lift8 Server is an application necessary for a correct operation of the ® ® Lift8 Central Unit 2N Lift8 Control Panel Lift8 Communicator. Its purpose is to mediate communication between these devices and user interfaces. Caution ®...
  • Page 255 Then you will be asked whether the configuration files should be removed too. If you select no, the existing configuration ® will be retained and the application will only be updated. Now the 2N Lift8 Server ®...
  • Page 256 If a problem with non-compatible version of .NET occurs during installation, you should download new version of .NETFX4.0 from www. 2n.cz . From online manual you can use this link Minimum operating system requirements: Windows Vista Windows Windows 2N TELEKOMUNIKACE a.s., www.2n.cz 256/377...
  • Page 257 Licensing ® All the Lift8 Server functions are subject to licence. Upon your first PC installation of the application, you will get a trial licence for 800-hour operation and 50-user and 50-lift (CU) connection. Caution ® Every Lift8 Server restart increments the hour counter by 1.
  • Page 258 ® Having received the licence file, start the Lift8 Licence Tool and enter the path to this file into the Licence path parameter. Click Upload to add the licence to the server directory and restart the server to update the licence data. The licence status will change into OK.
  • Page 259 ® ® settings and/or process incoming alarm calls via the Lift8 Control Panel Lift8 Communicator ® Lift8 Server integrates a SIP station which can be assigned up to 8 independent accounts and process up to 32 parallel calls.
  • Page 260 The application is launched in the command row. The common path to the program in all WINDOWS XP, Vista and 7 versions is as follows: c:\Program Files\2N TELEKOMUNIKACE\2N Lift8\Server\l8-config.exe If l8-config.exe is launched without any parameter, the program will write out all available information on the server as follows: l8-config.exe...
  • Page 261 C:\Program Files\2N TELEKOMUNIKACE\ 2N Lift8\Server\l8-config.exe - cStopServer Then enter the –cImportDatabase parameter and the file path to import the database: C:\Program Files\2N TELEKOMUNIKACE\ 2N Lift8\Server\l8-config.exe - cImportDatabase "C:\ProgramData\2N TELEKOMUNIKACE\ 2N Lift8\Server\db- 20130221095921-export.xml" Now all the database tables start being exported sequentially. Every successful table import is confirmed.

  • Page 262: Setting Options

    Restart the server after every successful database import using the following command: C:\Program Files\2N TELEKOMUNIKACE\ 2N Lift8\Server\l8-config.exe - cStartServer Setting Options The l8-config program provides numerous server settings; see the long list below. parameters...
  • Page 263 --help or -h displays Help. --version or -V writes out the program version. -d <data directory> sets the server data directory. Parameter Get Commands -gListenPort writes out the server listening port. -gLicensesNumber Get number of installed license 2N TELEKOMUNIKACE a.s., www.2n.cz 263/377...
  • Page 264 The maximum count is based on the licence. -sMaxLift <max_lift_tcp_conn> sets the maximum count of lifts to be connected to the server at the same time. The maximum count is based on the licence. -sResetAdmin resets the Admin password to default '2n'. 2N TELEKOMUNIKACE a.s., www.2n.cz 264/377...
  • Page 265 -cRestartServer restarts the l8 server. -cExportDatabase exports the database to an XML file. -cImportDatabase <XML_file> imports the database from an XML file. Make sure that the server has been stopped to avoid operation failure. 2N TELEKOMUNIKACE a.s., www.2n.cz 265/377...

  • Page 266: Control Panel

    7. Control Panel ® Lift8 Control Panel is an application is used for easy intercom administration and, thanks to the administrator approach, user and user group administration. Users can be assigned access rights to new intercom settings and administration. The...
  • Page 267 Now the application will ask you to enable transmission of system data and software use surveys to help the 2N TELEKOMUNIKACE a.s. company improve the software quality, availability and performance. No confidential data shall be sent. You can participate in this effort voluntarily and cancel sending statistic data any time.
  • Page 268 PC. Finally, you will be asked whether you really want to delete the existing configuration files. If you click NO, your configuration will be preserved. 2N TELEKOMUNIKACE a.s., www.2n.cz 268/377...
  • Page 269 Note ® Lift8 Control Panel installation requires 650 MB of free disk space at least. ® Now the Lift8 Control Panel is ready for use. Click on the shortcut item on the desktop (see the figure below) or select the Start item to start the application.
  • Page 270 The application will execute login to the Lift8 Server Server login may take some time if you have an extensive database as the application has to download all the current tables. Be patient please and wait for completion. 2N TELEKOMUNIKACE a.s., www.2n.cz 270/377...
  • Page 271 If a problem with non-compatible version of .NET occurs during installation, you should download new version of .NETFX4.0 from www. 2n.cz . You can use this link from the online manual. Minimum operating system requirements: Windows Vista Windows Windows 2N TELEKOMUNIKACE a.s., www.2n.cz 271/377...
  • Page 272 The Setting submenu includes a Statistics window: confirm the request to enable transmission of your system data and software use surveys to help the 2N TELEKOMUNIKACE a.s. company improve the software quality, 2N TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 273 See the figure above. Find the Logout button in the right-hand bottom corner and various important control buttons in the lower part of the application. The table below describes all the buttons available in the application. 2N TELEKOMUNIKACE a.s., www.2n.cz 273/377...
  • Page 274 – changes cannot be saved as the validator disapproved some of the parameters (marked with a distinct red frame). Undo helps undo all changes made since the last saving. 2N TELEKOMUNIKACE a.s., www.2n.cz 274/377...
  • Page 275 Add plan helps you add a building plan to the selected storage. Remove plan helps you remove the selected plan. Change plan updates the plan stored by storing a new map under the same name. 2N TELEKOMUNIKACE a.s., www.2n.cz 275/377...
  • Page 276 Load calls from archive helps you display all the server database calls. Both the current records and records moved to the archive are displayed. Refresh intercoms is available in the Surveillance menu and helps update the list of intercoms and their states. 2N TELEKOMUNIKACE a.s., www.2n.cz 276/377...
  • Page 277 (or a sequence of characters) into the search row. The function requires no confirmation and starts searching the database the moment you enter the first character. Add more characters to refine the filter until you find the required intercom. 2N TELEKOMUNIKACE a.s., www.2n.cz 277/377...
  • Page 278 The list in the figure above includes some information on the intercom. The icon at each intercom indicates the lift cabin and can have several functions and meanings, which can be combined (see the table below). 2N TELEKOMUNIKACE a.s., www.2n.cz 278/377...
  • Page 279 ® This symbols a functional intercom: SingleTalk 2N LiftNet 2N Helios Unknown ® probably supplied by another manufacturer and able to communicate with the 2N Lift8 Server via CPC / P100. ® A functional Lift8 intercom. The red chain below the icon indicates the Disconnected ®...
  • Page 280 Remove to delete the intercom from the database if unintentional (telemarketing, error). Authorisation of Intercom Created by Check Call Complete more intercom card parameters for authorisation. See below for details (Intercoms). 2N TELEKOMUNIKACE a.s., www.2n.cz 280/377...
  • Page 281 Intercoms subsection below. As this intercom has not made a check call yet, it will be considered non-functional. Install it and make the first check call to make the intercom ready for use. 2N TELEKOMUNIKACE a.s., www.2n.cz 281/377...
  • Page 282 PBX/gateway behind which the intercom is located. Intercom group specifies the group to which the intercom is assigned. Select an item from the list to change the group. Press the cross symbol to remove an intercom from all the groups. 2N TELEKOMUNIKACE a.s., www.2n.cz 282/377...
  • Page 283 The default value of this parameter is 72 hours. The Alarm call response specifies the type of alarm call processing: Normal call Confirm with 1, CPC Antenna, CPC KONE P100. Similarly, the Check call response specifies the type of check call 2N TELEKOMUNIKACE a.s., www.2n.cz 283/377...
  • Page 284 . Complete the serial number of your intercom in the Serial number field. Together with Password, this parameter is relevant for a correct function of the data tunnel. The default password is 2n. Click Save to confirm the setting. If you select the ®...
  • Page 285 Lift8 Server from intercom addition until now. Click the filter button at each column to use filtration for call history search. Refer to the Calls subsection for details. The table 2N TELEKOMUNIKACE a.s., www.2n.cz 285/377...
  • Page 286 The change will appear in the General menu too. Click Check address to set a new address and press Save to add the address to the database. Intercoms – Map Menu Local Plan 2N TELEKOMUNIKACE a.s., www.2n.cz 286/377...
  • Page 287 Export. Having pressed this button, you have additional checkbox options: select the items to be exported and click Export in the form to confirm your selection. If you choose export of assigned users, a list of the 2N TELEKOMUNIKACE a.s., www.2n.cz 287/377...
  • Page 288 Add more characters to refine the filter until you find the required user. Click Create user card to add a user to the end of the table. Each user has an icon that identifies its role (function). 2N TELEKOMUNIKACE a.s., www.2n.cz 288/377...
  • Page 289 Superuser Superuser is only authorised to manage the intercoms and users in its group. Dispatcher ® Dispatcher processes the assigned intercom alarm calls via the 2N Lift8 Communicator application. Technician Technician is entitled to view the assigned lift settings. User defined User defined role.
  • Page 290 Assigned intercoms and move it to the Not assigned intercoms with the arrow key. To search an intercom, enter the text or number to be searched into the field above the list and see the filtration result in the associated list immediately. Click Save to save the new settings. 2N TELEKOMUNIKACE a.s., www.2n.cz 290/377...
  • Page 291 Communicator must be assigned a SIP line, ® i.e. an account registered with a SIP provider or the PBX used for login via the 2N Lift8 Communicator . When you log in to the application, your line will get registered ®...
  • Page 292 Users – Communicator Menu Caution Make sure that the SIP line is configured correctly to register your SIP ® line and log in to the Lift8 Communicator application. Contact your network administrator for the SIP line settings. 2N TELEKOMUNIKACE a.s., www.2n.cz 292/377...
  • Page 293 Set the Registration expiry and Time limit parameters as necessary. Activate the line you have just configured. Save the new settings. ® After such modification, you will be able to log in via the 2N Lift8 Communicator and process calls in a standard manner. Roles Roles menu specifies the user login types.
  • Page 294 You will be informed of this by a dialogue window with confirmation. Parameter name Meaning Authorisation   User is Technician The user is included as Technician in the database and its ® assignment to the intercom in the Lift8 Communicator displayed. 2N TELEKOMUNIKACE a.s., www.2n.cz 294/377...
  • Page 295 Parameter name Meaning Allowed to use ® The user has access to the SIP line settings and may join the 2N Communicator Lift8 Communicator application. Users   User administration Helps create, delete and edit all users. Role administration Helps create, delete and administer user roles.
  • Page 296 (in one building, e.g.) at one time. The other option helps you manage multiple companies on one server as separate groups. Administrator assigns intercoms and users to each group to be administered by the appropriate group Superusers. 2N TELEKOMUNIKACE a.s., www.2n.cz 296/377...
  • Page 297 Click Create group to create a new group and add it to the end of the list. Click Delete to remove a selected group. Click Save to confirm the settings. Groups Menu – General 2N TELEKOMUNIKACE a.s., www.2n.cz 297/377...
  • Page 298 The advanced parameter list is empty by default. If a parameter is identically set for all the intercoms, the parameter value will be displayed. If not, the field will remain empty. 2N TELEKOMUNIKACE a.s., www.2n.cz 298/377...
  • Page 299 Make sure that a correct email is defined for every user on the list in the Users - Basic menu to allow for proper report sending. 2N TELEKOMUNIKACE a.s., www.2n.cz 299/377...
  • Page 300 Email server – Report settings menu. Define the Sending interval for the reports: Next run will generate the time of your next report sending. Enable prompt notifications using the last checkbox to send information on a new situation immediately. 2N TELEKOMUNIKACE a.s., www.2n.cz 300/377...
  • Page 301 SIP lines for the check calls. Configure up to 8 independent telephone lines. The first line is also intended for active check calls and can be configured via extended settings. Enter the SIP line parameters correctly 2N TELEKOMUNIKACE a.s., www.2n.cz 301/377...
  • Page 302 Server for all the lines and Line . Server provides the current SIP server state information: Maximum simultaneous calls displays the maximum count of check calls to be processed by the server at the same 2N TELEKOMUNIKACE a.s., www.2n.cz 302/377...
  • Page 303 In practice, the database always stores three calls at least from each intercom phone number if accomplished. If the intercom never called more than once, there will be just one call in the database. 2N TELEKOMUNIKACE a.s., www.2n.cz 303/377...
  • Page 304 Registration result displays the SIP Proxy registration result. If unsuccessful. the registration packet will be resent. This parameter is updated automatically. When you click Save for 2N TELEKOMUNIKACE a.s., www.2n.cz 304/377...
  • Page 305 Set the Registration expiry and Time limit parameters as necessary. Activate the line you have just configured. Save the new settings. Go on like this with all the other lines. After such modification, the call server will start processing calls in a standard manner. 2N TELEKOMUNIKACE a.s., www.2n.cz 305/377...
  • Page 306 SIP Stack Settings Caution ® The SIP stack settings are common for all the server lines and all the 2N Lift8 Communicator users. If TLS is enabled for dispatcher lines too, the application downloads the current security certificate from the server.
  • Page 307 It is necessary to read the SSL libraries, which are not needed in common operations. ® Restart the server in the Services system menu or via the 2N Lift8 l8- config.exe application. Refer to Subs. 6.2. for function details.

  • Page 308: Email Server

    SMTP server and helps send reports on intercom states. The menu has two parts: SMTP Server Settings, which helps you set the report sending account, and Report Settings for detailed report settings. 2N TELEKOMUNIKACE a.s., www.2n.cz 308/377...
  • Page 309 (body). You can use a string to be replaced with the current intercom count or date. Refer to the list of supported strings below the report body. At present, the following strings are supported: 2N TELEKOMUNIKACE a.s., www.2n.cz 309/377...
  • Page 310 Enable prompt notifications and set the text of the report to be sent to distinguish prompt notifications from periodic reports. Prompt notifications are automatically sent to the email address completed for the given situation whenever a change occurs. Email Server – Report Settings Menu 2N TELEKOMUNIKACE a.s., www.2n.cz 310/377...
  • Page 311 Assign the plans to the selected intercom and mark the intercom position in ® the Intercoms menu. This information will then be displayed to the 2N Lift8 Communicator operators.
  • Page 312 Download plan to save the plan without the intercom positions onto a local disk. Plan changing is useful when you need to update a plan after reconstruction and interior changes while keeping the existing intercom structure in the building. 2N TELEKOMUNIKACE a.s., www.2n.cz 312/377...
  • Page 313 Click Show files to view the files and plans stored on the disc. Their names correspond with the server database key. You can also see the file size and delete any file in this window. 2N TELEKOMUNIKACE a.s., www.2n.cz 313/377...
  • Page 314 You can also delete the filters via the contact menu displayed by clicking the right mouse button anywhere in the table or using Alt + r . 2N TELEKOMUNIKACE a.s., www.2n.cz 314/377...
  • Page 315 Such a call is then considered a correctly processed alarm call. The last icon signals that the confirmed alarm call has been transferred to another Dispatcher or a Technician. Check Call State 2N TELEKOMUNIKACE a.s., www.2n.cz 315/377...
  • Page 316 This allows you to view the call list on one monitor and configure other intercom and user parameters on the other; see the figure below. Pin View 2N TELEKOMUNIKACE a.s., www.2n.cz 316/377...
  • Page 317 Lift8 Server from intercom addition until now. Click the filter button at each column to use filtration for call history search. See above for details. The table provides the following information: call state, Timestamp, Contact 2N TELEKOMUNIKACE a.s., www.2n.cz 317/377...

  • Page 318: Outgoing Calls

    Agent name. The last table column Note shows the note entered by Agent during the alarm call. Click Load calls from archive to load the secondary call database as described in the Calls Server subsection above. 2N TELEKOMUNIKACE a.s., www.2n.cz 318/377...
  • Page 319 OK now as the last check call was correct but the last but one check call was wrong and green reappears when a non-functional intercom makes a correct check call. 2N TELEKOMUNIKACE a.s., www.2n.cz 319/377...
  • Page 320 Add more characters to refine the filter until you find the required intercom. Click the Refresh intercoms button in the left-hand bottom corner to refresh all the intercoms on the map Surveillance Menu – Filtration 2N TELEKOMUNIKACE a.s., www.2n.cz 320/377...
  • Page 321 (see above). All calls are displayed by default. The search result is shown in the Surveillance menu – Global Map figure above. 2N TELEKOMUNIKACE a.s., www.2n.cz 321/377...
  • Page 322 8.1 Installation and Login 8.2 Introduction to Application 8.3 Use ® Refer to the Lift8 product pages at www.2n.cz , download section, for the latest FW version. You can use this link from the online manual. 2N TELEKOMUNIKACE a.s., www.2n.cz 322/377...
  • Page 323 Now the application will ask you to enable transmission of system data and software use surveys to help the 2N TELEKOMUNIKACE a.s. company improve the software quality, availability and performance. No confidential data shall be sent. You can participate in this effort voluntarily and cancel sending statistic data any time.
  • Page 324 PC. Finally, you will be asked whether you really want to delete the existing configuration files. If you click NO, your configuration will be preserved. 2N TELEKOMUNIKACE a.s., www.2n.cz 324/377...
  • Page 325 If you are the first user of the ® application, enter your login data as communicated to you by your 2N Lift8 administrator. It is easy to set the connection: enter the server IP address if you establish connection to a LAN or public network server.
  • Page 326 Now click Connect to selected server to log in to the Lift8 Server Server login may take some time if you have an extensive database as the application has to download all the current tables. Be patient please and wait for completion. 2N TELEKOMUNIKACE a.s., www.2n.cz 326/377...
  • Page 327 If a problem with non-compatible version of .NET occurs during installation, you should download new version of .NETFX4.0 from www. 2n.cz . You can use this link from the online manual. Minimum operating system requirements: Windows Vista Windows Windows 2N TELEKOMUNIKACE a.s., www.2n.cz 327/377...
  • Page 328 The horizontal Main menu helps you choose whether to view assigned intercoms or ® supervise the alarm call history. You can also display the database of the 2N Lift8 users including their phone numbers.
  • Page 329 Hang up helps you terminate an active call or reject an incoming call during ringing. Save helps you return from the Incoming/Outgoing call window after call hangup and termination and save modified notes. Pick up helps you answer an incoming call. 2N TELEKOMUNIKACE a.s., www.2n.cz 329/377...
  • Page 330 Get new image helps you download a preview from the camera connected to the selected camera module in the lift cabin. Rotation to left turns the image left by 90°. Rotation to right turns the image right by 90°. 2N TELEKOMUNIKACE a.s., www.2n.cz 330/377...
  • Page 331 Telephoning is the main function of the application. If the user SIP line cannot be registered, the user will not be able to log in. In that case, ask ® your system administrator to check the SIP line settings in the 2N Lift8 Control Panel...
  • Page 332 Contacts menu and call the technician immediately. Caution ® For the purpose hereof, Technician means the Lift8 user that is assigned the Technician user role. The other users (Admin, Operator or Own role) are not displayed in this table. 2N TELEKOMUNIKACE a.s., www.2n.cz 332/377...
  • Page 333 Call to set up a call to this user. This opens the Outgoing call window and the call will be made. See below for details on outgoing calls. If the call cannot be set up, you will get a voice message. Contacts Menu 2N TELEKOMUNIKACE a.s., www.2n.cz 333/377...
  • Page 334 The dispatcher is notified and calls the intercom (Audio Unit) that initiated the alarm call. Such a call is then considered a correctly processed alarm call. The next icon, Transferred call, is 2N TELEKOMUNIKACE a.s., www.2n.cz 334/377...
  • Page 335 Click the funnel symbol in the selected column to activate the filter. Activation is indicated by a colour change of the funnel symbol; see the figure below. Left – Inactive Filter, Right – Active Filter 2N TELEKOMUNIKACE a.s., www.2n.cz 335/377...
  • Page 336 If you did not delete the setting, the filtration settings would keep active even upon the logout and you would obtain filtration results instead of complete information in your next search. 2N TELEKOMUNIKACE a.s., www.2n.cz 336/377...
  • Page 337 Select an input or output device in your PC in a pop-up menu and set the required volume using a slider. 2N TELEKOMUNIKACE a.s., www.2n.cz 337/377...
  • Page 338 Every incoming call to a dispatcher/technician number is signalled with an automatic switch to the Incoming calls window and pop-up of an Incoming call window in the ® left-hand bottom corner of the screen. This is useful when the 2N Lift8 Communicator display is hidden under another application as the Incoming call window is always on the top.
  • Page 339 Intercom identification, Contact number and Address. Use the keypad below these items to control the Speaking call: confirm the call with DTMF or dial the required shaft number. A calling technician can use the keypad for the voice menu control. 2N TELEKOMUNIKACE a.s., www.2n.cz 339/377...
  • Page 340 Agent and Note added during the alarm call. The Checking calls table shows all check calls from the given intercom since intercom addition to the database according to the server archives deletion setting. Each record includes its date/time and result. 2N TELEKOMUNIKACE a.s., www.2n.cz 340/377...
  • Page 341 This type of transfer is called call transfer with hang-up, i.e. your call is terminated, the caller gets the ringing tone again and this call will alert the dispatcher's line selected by you. 2N TELEKOMUNIKACE a.s., www.2n.cz 341/377...
  • Page 342 Here is what you can find in this section: 9.1 Installation and Connection 9.2 Use Refer to the Lift8 Download section at the 2N TELEKOMUNIKACE official web sites for the latest application versions. Use the following link or Google Play mobile application to view the online manual.
  • Page 343 9.1 Installation and Connection The application is available at Google Play or 2N TELEKOMUNIKACE web sites, Download of Lift8 products. Use the following link to view the online manual. The application can be used for connection of Central Units with FW versions 1.10.0 and higher.
  • Page 344 The web interface allows you to view applications more comfortably. If you like any of the applications, proceed like with a phone: click Install, confirm authorisation, let the application get installed and start using it. 2N TELEKOMUNIKACE a.s., www.2n.cz 344/377...
  • Page 345 Package Installation Tool Now the installation proceeds like with Google Play. After installation, the Service Tool icon will be added to the menu. Click on the icon to open the application and display the login screen. 2N TELEKOMUNIKACE a.s., www.2n.cz 345/377...
  • Page 346 Service Tool will automatically start and display the login screen whenever the CU gets connected to the selected USB port. Unselect the option and click OK to prevent this automatic launch. If you choose Cancel, you will be asked after the next CU connection again. 2N TELEKOMUNIKACE a.s., www.2n.cz 346/377...
  • Page 347 The application warns you of any typing error and allows you to re-enter the password. Upon login, you get into the Main menu and its submenus. The ® Configuration menu is only available at present. Other menus known from the 2N Lift8 Service Tool PC application will be available in the future.
  • Page 348 To do this, use the two options in the pop-up menu in the right-hand upper corner: Read configuration and Save configuration. The control design may be different in different Android versions. Yet, the location and operation of the system control elements are almost the same. Read Configuration 2N TELEKOMUNIKACE a.s., www.2n.cz 348/377...
  • Page 349 When the configuration has been read, parameter blocks are displayed in the alphabetical order like in the PC application. Click on the selected block to open the list of related parameters. Every parameter includes a numeric code, name and current value. 2N TELEKOMUNIKACE a.s., www.2n.cz 349/377...
  • Page 350 Click Default to set the default value and OK to confirm the new setting. If you make a typing mistake (set a value beyond the limits or exceed the character limit), you will be warned by the validator. 2N TELEKOMUNIKACE a.s., www.2n.cz 350/377...
  • Page 351 Back to return to the preceding menu. If you click Back in the Main menu, you will log out. Click the system Home button to quit the application and press Last used programs to terminate the application. 2N TELEKOMUNIKACE a.s., www.2n.cz 351/377...
  • Page 352 By default, C:\Program Files (x86)\2N TELEKOMUNIKACE\2N Lift8\get-cam-image is ® used. Click Next to make the wizard install 2N Lift8 get-cam-image. Once installed, the application is ready for use. Alternatively, use the command line for installation: select the installer file and define the manner and location parameters.
  • Page 353 Make sure that the command line is started by admin. If it is started by a user, the editor authenticating window will pop up. Note ® Lift8 get-cam-image requires 250 MB of free disk space at least for installation. 2N TELEKOMUNIKACE a.s., www.2n.cz 353/377...
  • Page 354 Lift8 Server connection /WAN Warning If you see 'incompatible version .NET' upon the wizard launch, download the current redistribution .NETFX4.0 from the 2N TELEKOMUNIKACE web sites or click here The minimum OS requirements are Windows Vista Windows 7 Windows ®...
  • Page 355 Caution To download an image successfully, configure the selected intercom in ® Lift8 Control Panel application. Make sure that the data tunnel is enabled (refer to Subs. 7.3 for details). ® Also make sure that a user is created in the...
  • Page 356 2N TELEKOMUNIKACE a.s., www.2n.cz 356/377...
  • Page 357 ® Lift8 Server IP address ® Lift8 Server port ® User (must be created via the Lift8 Control Panel User password User listing (optional) Developer listing (optional) Example: Get-cam-image.exe -o test.jpg -s 89.24.1.180 7008 -u novak - 1234 603123456 The application downloads the image from the intercom camera...
  • Page 358 Authentication error Incompatible protocol version Server connection failed Connection terminated by server Loading file on disk failed No intercom selected Selected intercom is not in database Connection with intercom failed (tunnel) Timeout expired Intercom is busy 2N TELEKOMUNIKACE a.s., www.2n.cz 358/377...
  • Page 359 Error number Description Camera module not found Camera error Image cannot be downloaded now (rescue function enabled yet inactive) 2N TELEKOMUNIKACE a.s., www.2n.cz 359/377...
  • Page 360 11. Maintenance This section describes the product maintenance and FW upgrade. 11.1 Operation Interruption and Battery Replacement 11.2 Firmware Upgrade 2N TELEKOMUNIKACE a.s., www.2n.cz 360/377...
  • Page 361 Make sure that the earthing wire is connected with the cover before replacing the cover! By reset button proceed the Zero backup rechargeable battery life counter (see chapter: 2.1 ) 2N TELEKOMUNIKACE a.s., www.2n.cz 361/377...
  • Page 362 ® Never use 2N Lift8 without its protective cover to avoid electric ® accident, malfunction due to wrong interconnection and/or 2N Lift8 electronics damage or destruction as a result of electric short-circuit or ® adverse environmental conditions. It is because...
  • Page 363 Remember to replace the rechargeable batteries every 2 years to provide backup in the case of power outage. Always remember that the state of the batteries is essential for the system operation. 2N TELEKOMUNIKACE a.s., www.2n.cz 363/377...

  • Page 364: Firmware Upgrade

    Back up your configuration, execute upgrade and factory default reset and upload the configuration into the device (new ranges and default values will be used in the new FW version). Check the device time after upgrade. 2N TELEKOMUNIKACE a.s., www.2n.cz 364/377...
  • Page 365 Set the splitters to odd addresses (lift/shaft number) for 1.x.x to 2.x.x upgrade as even addresses cannot be upgraded. Example: First upgrade the odd address splitters. Then disconnect these spliters and change the even address splitters to odd ones. After upgrade, change the odd addresses back to even ones. 2N TELEKOMUNIKACE a.s., www.2n.cz 365/377...

  • Page 366: Technical Parameters

    Power supply : 24 V from central unit or local Capacity: 4 inputs + 4 outputs Inputs: galvanic isolation, 12–24 V AC or DC Outputs: relay, NO contacts, u7p to 250 V, 5 A Dimensions: 142 x 98 x 34 mm 2N TELEKOMUNIKACE a.s., www.2n.cz 366/377...
  • Page 367 Working relative humidity: 10–95 % (non-condensing) Storing temperature: -40 °C to 70 °C Dimensions: (217 x 109 x 83) mm, (242 x 136 x 83) mm incl. frame Weight: netto max. 2 kg, brutto max. 2,5 kg Covering level: IP65 2N TELEKOMUNIKACE a.s., www.2n.cz 367/377...
  • Page 368 All the product parameters comply with TBR-21 on condition that the product is to be operated as a single line terminal, i.e. no parallel connection with any other equipment is allowed. Line interference and noise picked up by the microphone are relevant factors. 2N TELEKOMUNIKACE a.s., www.2n.cz 368/377...
  • Page 369 The manufacturer reserves the right to modify the product in order to improve its qualities. The product contains no environmentally harmful components. When the product's service life is exhausted, dispose of it in accordance with the applicable legal regulations. 2N TELEKOMUNIKACE a.s., www.2n.cz 369/377...
  • Page 370 13. Supplementary Information ® This section provides supplementary information on the Lift8 product. Here is what you can find in this section: 13.1 Troubleshooting 13.2 List of Abbreviations 13.3 Regulations 13.4 General Instructions and Cautions 2N TELEKOMUNIKACE a.s., www.2n.cz 370/377...
  • Page 371 13.1 Troubleshooting For the most frequently asked questions refer to faq.2n.cz 2N TELEKOMUNIKACE a.s., www.2n.cz 371/377...

  • Page 372: List Of Abbreviations

    DISA Automatic voice menu for incoming call routing to the required audio unit or function activation, remote programming, e.g. Private branch exchange (equipped with PSTN connection and analogue local lines). 2N TELEKOMUNIKACE a.s., www.2n.cz 372/377...
  • Page 373 PC applications. Validator This code monitors the values entered in the applications, and in the event of an error such as excessive length, forbidden character, incorrect format etc., warns the user. 2N TELEKOMUNIKACE a.s., www.2n.cz 373/377...
  • Page 374 February 2014 on the harmonisation of the laws of the Member States relating to lifts and safety components for lifts European Parliament and Council Directive 95/16/EC of 29 June 1995 on the approximation of the laws of the Member States relating to lifts ČSN EN 81-28 ČSN EN 81-72 2N TELEKOMUNIKACE a.s., www.2n.cz 374/377...
  • Page 375 The consumer shall, at its own expense, obtain software protection of the product. The manufacturer shall not be held liable and responsible for any damage incurred as a result of the use of deficient or substandard security software. 2N TELEKOMUNIKACE a.s., www.2n.cz 375/377...
  • Page 376 Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either. 2N TELEKOMUNIKACE a.s., www.2n.cz 376/377...
  • Page 377 2N TELEKOMUNIKACE a.s. Modřanská 621, 143 01 Prague 4, Czech Republic Phone: +420 261 301 500, Fax: +420 261 301 599 E-mail: sales@2n.cz Web: www.2n.cz v2.3.1 2N TELEKOMUNIKACE a.s., www.2n.cz 377/377...

Table of Contents
