AKC 25H1
The following messages can be connected to a "DI input" at your option. This is done with the
"configuration of inputs" setting.
For each individual DI input you may furthermore define the importance of the alarm:
DI( ) Dest [ 1, 2, 0 ]
Air flow switch
Compr. no( ) current cut out
Compr. no( ) disch temp cut out
Comp. no( ) disch press. cut out
Compr. no( ) motor prot. cut out
Compr. no( ) not in auto
Comp. no( ) safety cut out
Comp. no( ) oil press. cut out
Cond. no( ) safety cut out
Condensate pump fault
Current fault
Flow pump fault
High condensate level
Liquid flow switch
Low liquid level
Phase fault
Refrigerant leak
This is how the various messages are transmitted:
Information is in principle sent twice.
1) An alarm message when the error is discovered.
2) A message about cancellation of the alarm situation, when the error disappears again.
(In connection with a sensor alarm, there may be 10 minutes between the two messages).
This procedure has a different influence on the below-mentioned systems:
Single systems (systems with control panel type AKA 21)
Information can be shown on the screen, when an "E" (error) is observed.
The error message cannot be removed from AKA 21, as long as the cause of the error
has not been removed. When the cause of the error message has been removed, the
error message will remain visible in AKA 21 until it is acknowledged by pushing
"Enter".
Function description RC.1J.Z4.02 © Danfoss 09/1999
Error report from the air flow switch.
Check the flow switch.
Alarm from AKC 22H.
Check the alarm input on AKC 22H.
Alarm from AKC 22H.
Check the alarm input on AKC 22H.
Alarm from AKC 22H.
Check alarm input on AKC 22H.
Alarm from AKC 22H.
Check alarm input on AKC 22H.
Wrong setting of switch on alarm module
AKC 22H. Put switch in pos. "AUT".
Signal on input DI( ) interrupted.
Check the compressor's safety circuit.
Alarm from AKC 22H.
Check alarm input on AKC 22H.
Signal on input DI( ) interrupted.
Check the condenser's safety circuit.
Drip tray pump defective.
Check the pump.
Faulty supply voltage.
Check the earth-leakage circuit breaker.
Fault in the refrigerant circulation.
Check the refrigerant pump.
Drip tray level too high.
Check the drip tray.
Error report from the liquid flow switch.
Check the flow switch.
Low refrigerant level.
Check the amount of refrigerant.
Faulty supply voltage.
Check the supply voltage.
Refrigerant is leaking.
Check the unit that monitors leakage of
refrigerant.
