EX260-TFN20
Setting (Continued)
Terminator
A bus termination is required at both ends of the PROFIBUS DP bus
segment.
<EX260-SPR1/-SPR2/-SPR3/-SPR4>
The bus termination switch is built-in to EX260-SPR1/-SPR2
/-SPR3/-SPR4.
Switch it ON if the SI unit is at the end of the fieldbus segment.
Note: Factory default setting is OFF.
ON
<EX260-SPR5/-SPR6/-SPR7/-SPR8>
EX260-SPR5/-SPR6/-SPR7/-SPR8 do not have a
built-in termination resistor.
Termination is required on the outside of the SI unit. A termination
switch built-in to the PROFIBUS DP D-sub connector may be used.
Configuration
In order to configure the SI unit in the PROFIBUS DP network, the
appropriate device master file (GSD file) for the SI unit will be required.
The current GSD file can be found on the SMC website
(URL http://www.smcworld.com)
GSD file
Part number GSD file
1 EX260-SPR1/-SPR2 Smc_1430.gsd
2 EX260-SPR3/-SPR4 Smc_1431.gsd
3 EX260-SPR5/-SPR6 Smc_1432.gsd
4 EX260-SPR7/-SPR8 Smc_1433.gsd
Output number assignment
The output number refers to the solenoid position on the manifold and
starts at zero.
Bit: 7 0
Byte
0 Offset
16 outputs
0: Solenoid valve: OFF
Bit: 7 0
Byte type
1: Solenoid valve: ON
1 Offset
Bit: 7 0
Byte
2 Offset
Bit: 7 0
Byte
3 Offset
Bit No. 0 2 4 6 0 0 4 6
Output No. 0 2 4 6 8 16 28 30 Solenoid on side A
Side D
(SI unit side)
Output No. 1 3 5 7 9 17 29 31 Solenoid on side B
Bit No.
1 3 5 7 1 1 5 7
Valve manifold
Diagnostic information
The EX260 SI unit can support 8 bytes of diagnostic information,
6 bytes standard diagnostic information and 2 bytes SI unit-related
diagnostic information.
Diagnostic information can be requested by the DP master from the SI
unit, and such system fault states can be indicated by the SF LED.
Technical documentation giving detailed diagnostic information can be
found on the SMC website (URL http://www.smcworld.com)
LED indication
SF BF PWR PWR(V)
LED Description
SF System fault
BF BUS fault
OFF
PWR Turns ON in green when SI unit operating voltage is supplied
Turns ON in green when load voltage for the valve is supplied
PWR(V) Turns OFF when load voltage for the valve is not supplied or
outside tolerance range (19 V or less)
<Indication of communication status>
SF status BF status Description
No fault. Communication connection to the
OFF OFF
master is established
SI unit can not detect a transmission rate and
OFF Red ON
the connection to the DP master has failed
SI unit has detected the transmission rate,
OFF Red flashing
but is not addressed by the DP master
SI unit-related diasgnostic error is detected
Red ON OFF (load power for the valve is not supplied or
outside tolerance range)
Red ON Red ON SI unit PROFIBUS DP address outside range
The configuration data sent from the DP
Red ON Red flashing master to the SI unit does not agree with the
SI unit configuration
Troubleshooting
Technical documentation giving detailed troubleshooting information can be
found on the SMC website (URL http://www.smcworld.com)
Specifications
32 outputs
type Connected load: 24 VDC Solenoid valve with light and surge voltage
suppressor of 1.5 W or less (manufactured by SMC)
Current consumption of power supply for SI unit operation: 0.1 A max.
Ambient temperature for operation: -10 to 50 ℃
Ambient temperature for storage: -20 to 60 ℃
Pollution degree 2: (UL508)
Technical documentation giving detailed specifications can be found on the
SMC website (URL http://www.smcworld.com)
Outline Dimensions
Technical documentation giving detailed outline dimensions can be found
on the SMC website (URL http://www.smcworld.com)
Accessories
Technical documentation giving detailed accessories information can be
found on the SMC website (URL http://www.smcworld.com)
