Installation MANUAL
MODEL MHU24GE
Masthead Amplifier
Thank you for selecting an Australian designed and built masthead amplifier.
LED
For maximum
UHF gain
turn control
clockwise
• A masthead amplifier is designed to amplify low signal levels for both analogue
and digital applications.
• The amplifier gain should be selected to suit each individual environment.
WARRANTY
Standard Communications
PTY. LTD
warrants this Kingray product to be free
from defects in material and workmanship
for a period of 3 years from the date of
Optimised for both Digital and
Analogue TV Signal Amplification
Mount with polypropylene
securing strap on to mast
or mount to a wall with
the four pre-drilled holes
Best mounting location for
masthead unit is on mast
300 mm to 1 metre below
antenna
Ensure weatherproof strips
remain in place
installation and reserves the right to void
warranty if unit was misused, improperly
installed or damaged by claimant.
