2.7 Send your claim to:
Standard Communications Pty Ltd. Unit B, 22-24 College Street, Gladesville,
NSW 2111, Australia. Tel: (02) 9879 8888, Fax: (02) 9816 4722
Email: servadmin@gme.net.au
2.8 If we determine that your goods are defective, we will pay for the cost of returning
the repaired or replaced goods to you, and reimburse you for your reasonable
expenses of sending your warranty claim to us.
3. What this warranty does not cover
3.1 This warranty will not apply in relation to:
(a) goods modified or altered in any way;
(b) defects and damage caused by use with non Standard Communications
products;
(c) repairs performed other than by our authorised representative;
(d) defects or damage resulting from misuse, accident, impact or neglect;
(e) goods improperly installed or used in a manner contrary to the relevant
instruction manual; or
(f) goods where the serial number has been removed or made illegal.
4. Warranty period
4.1 We provide the following warranty on GME and Kingray products. No repair or
replacement during the warranty period will renew or extend the warranty period
past the period from original date of purchase.
Product Type
Kingray amplifiers, modulators, diplexers and filters,
Kingray plug pack power supplies, Kingray Professional
rack mount products.
Warranty Period
3 years
Part No: 310347 Drawing No: 42887-4
INSTALLATION MANUAL
Specialists in TV signal amplification
DW32
( 44–230/520–860 MHz )
DISTRIBUTION AMPLIFIER
Optimised for both digital and analogue TV signal amplification.
UHF Gain
Control
Separate or
Combined
Input Link
VHF Input
VHF/UHF
Input
Thank you for selecting an Australian designed and built
distribution amplifier.
The DW32 is a Free-to-Air distribution amplifier for use in MATV multiple
dwelling applications. It features single or combined VHF/UHF inputs,
separate VHF/UHF gain controls, inbuilt slope, -30 dB test point, local or
remote powering options.
INSTALLATION
The Kingray DW32 is primarily designed for internal applications. However,
in situations where the amplifier needs to be installed externally, it can be
mounted in a MHB001 weather proof housing and remotely powered.
Power LED
RF Output
2.5 mm
-30 dB
DC Plug
Test Point
VHF Gain
Control
