Technical Specifications
Power
AC 120V 60Hz
Fuse
20mm Glass T6.3A Fast Blow 20mm Glass T5A Fast Blow
Lamps
1 x 24V 250W Part No. ELC 24V 250W
Dimension
500mm x 200mm x 155mm / 19.69in x 7.87in x 6.1in
Weight
=================================================================
For further requirements, contact the nearest authorized technical assistance office
=================================================================
AC 230-250V 50/60Hz
10 kg / 22 lbs
Professional Lighting Technology
User Guide
Please read these instructions carefully before use
Advertisement
Related Manuals for ACME MH-640S-ELC
Summary of Contents for ACME MH-640S-ELC
- Page 1 Technical Specifications Power AC 120V 60Hz AC 230-250V 50/60Hz Fuse 20mm Glass T6.3A Fast Blow 20mm Glass T5A Fast Blow Professional Lighting Technology Lamps 1 x 24V 250W Part No. ELC 24V 250W Dimension 500mm x 200mm x 155mm / 19.69in x 7.87in x 6.1in Weight 10 kg / 22 lbs User Guide...
-
Page 2: Fixture Cleaning
E. FIXTURE CLEANING The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics. ... - Page 3 ( 2 ) Preprogram functions The unit can be linked together as master/slave in daisy chain in linkage as many units as required and run by built in preprogrammed chase sequences automatically or by sound activation. When linking the Barrel and the Scanner in stand alone mode, the Barrel must be used as the master head.
-
Page 4: General Instructions
A. GENERAL INSTRUCTIONS DMX512 CONFIGURATION CHANNEL 1 CHANNEL 2 CHANNEL 3 CHANNEL 4 CHANNEL 5 SHUTTER GOBO COLOR TILT FLAT BARREL FLAT BARREL Please read the enclosed instructions carefully as they include important points about Fast Fast Stopped safety for the installation, usage and maintenance of the unit. •... -
Page 5: Main Features
B. MAIN FEATURES D. HOW TO CONTROL THE UNIT • Voltage：AC 120V 60Hz or 230-250V 50/60Hz ( 1 ) By universal DMX controller • Bulb： ELC 24V 250W The DMX512 is widely used in intelligent lighting control, with a maximum of 512 •...
