XA-500 FRAMING

User Manual

Please read the instruction carefully before use

Advertisement

Table of Contents
loading

Related Manuals for ACME XA-500

Summary of Contents for ACME XA-500

  • Page 1: User Manual

    XA-500 FRAMING User Manual Please read the instruction carefully before use...

  • Page 2: Table Of Contents

    CONTENTS 1. Safety Instructions ..........................2 2. Technical Specifications ........................3 3. How To Set The Unit ......................... 4 3.1 Control panel ..........................4 3.2 Main Function ..........................4 3.3 Home Position Adjustment ......................10 4. Control By Universal DMX Controller ..................... 12 4.1 DMX Connection ..........................

  • Page 3: Safety Instructions

    1. Safety Instructions Please read carefully the instruction, which includes important information about the installation, usage and WARNING  Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. ...

  • Page 4: Technical Specifications

    moisture.  DO NOT open the unit within five minutes after switching off.  The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged. Caution: There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself.

  • Page 5: How To Set The Unit

    3. How To Set The Unit 3.1 Control panel 1. Function Display: Used to show the various menus and the selected function; 2. Button: MENU To select the programming functions To go forward in the selected functions DOWN To go backward in the selected functions ENTER To confirm the selected functions 3.

  • Page 6: Fixture Settings

    DMX Functions 29 CH 31 CH Fixture Settings Near Square Law Inv SQ Law Liner S Curve No/Yes No/Yes Display Setting 1~10 ° ° Fixture Test Fixture Information Reset Functions Special Functions...
  • Page 7 DMX Settings To select DMX Settings press the ENTER button to confirm, use the UP/DOWN button to select DMX Address or Channel Mod. DMX Address —DMX512 address setting To select DMX Address, press the ENTER button to confirm. Use the UP/DOWN button to adjust the address from 001 to 512, press the ENTER button to store.
  • Page 8 to select Disable, Near, Medium or Far, press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode. BL.O. P/T Moving —Blackout while pan/tilt moving To select BL.O.
  • Page 9 The increase in light intensity appears to be linear as DMX value is increased. Square Law: Light intensity control is finer at low levels and coarser at high levels. Inverse Square Law: Light intensity control is coarser at low levels and finger at high levels. S-cure: Light intensity control is finger at low levels and high levels and coarser at medium levels.
  • Page 10 Fixture Test Enter menu mode, select Fixture Test, press the ENTER button to confirm, use the UP/DOWN button to select Auto Test or Manual Test Auto Test Select Auto Test, press the ENTER button to confirm, the unit will run built-in programs to automatically test pan, tilt, shutter, color, CMY, gobo, gobo rotation, prism, prism rotation, iris, frost, zoom, focus, dimmer and lamp on/off.

  • Page 11: Home Position Adjustment

    UP/DOWN button to select Pan/Tilt, Effect or All. Pan﹠Tilt —Reset Pan/Tilt Select Pan﹠Tilt, press the ENTER button to confirm, use the UP/DOWN button to select Yes (the unit will run built-in program to reset pan and tilt to their home positions) or No(normal), press the ENTER button to store.

  • Page 13: Control By Universal Dmx Controller

    4. Control By Universal DMX Controller 4.1 DMX Connection 1. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the input of the next fixture. The cable cannot be branched or split to a “Y” cable. Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system 2.

  • Page 14: Address Setting

    4.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button to enter menu mode, select the DMX Functions, press the ENTER button to confirm, use the UP and DOWN button to select the DMX Address, press the ENTER button to confirm, the present address will blink on the display, use the UP and DOWN button to adjust the address from 0 to 512, press the ENTER button to store.
  • Page 15 000-009 Open 010-018 Color1 019-027 Color2 028-036 Color3 037-045 Color4 046-054 Color5 055-063 Color6 064-127 Color Index 128-189 Rotation: Fast  Slow 190-193 Stop 194-255 Rotation: Slow  Fast Gobo 1 Open 000-009 Gobo1 010-018 Gobo2 019-027 Gobo3 028-036 Gobo4 037-045 Gobo5 046-054...
  • Page 16 072-079 Gobo2 Shaking 080-087 Gobo3 Shaking 088-095 Gobo4 Shaking 096-103 Gobo5 Shaking 104-111 Gobo6 Shaking 112-119 Gobo7 Shaking 120-127 Gobo8Shaking 128-189 Rotation: Fast  Slow 190-193 Stop 194-255 Rotation: Slow  Fast Iris 000-255 0%  100% Prism 000-007 No Effect 008-127 Prism 1 128-255...
  • Page 17 000-255 0%  100% FRAMING 2 000-255 0%  100% FRAMING 3 000-255 0%  100% FRAMING 4 000-255 0%  100% FRAMING 5 000-255 0%  100% FRAMING 6 000-255 0%  100% FRAMING 7 000-255 0%  100% FRAMING 8 000-255 0% ...
  • Page 18 Yellow 000-255 0%  100% 000-255 0%  100% Color 000-009 Open 010-018 Color1 019-027 Color2 028-036 Color3 037-045 Color4 046-054 Color5 055-063 Color6 064-127 Color Index 128-189 Rotation: Fast  Slow 190-193 Stop 194-255 Rotation: Slow  Fast Gobo 1 Open 000-009 Gobo1...
  • Page 19 029-035 Gobo4 036-042 Gobo5 043-049 Gobo6 050-056 Gobo7 057-063 Gobo8 064-071 Gobo1 Shaking 072-079 Gobo2 Shaking 080-087 Gobo3 Shaking 088-095 Gobo4 Shaking 096-103 Gobo5 Shaking 104-111 Gobo6 Shaking 112-119 Gobo7 Shaking 120-127 Gobo8Shaking 128-189 Rotation: Fast  Slow 190-193 Stop 194-255 Rotation: Slow ...

  • Page 20: Troubleshooting

    000-255 0%  100% Dimmer Fine 000-255 0%  100% FRAMING Rotation 000-255 0%  100% FRAMING 1 000-255 0%  100% FRAMING 2 000-255 0%  100% FRAMING 3 000-255 0%  100% FRAMING 4 000-255 0%  100% FRAMING 5 000-255 0% ...

  • Page 21: Fixture Cleaning

    B. Not responding to DMX controller 1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly. 2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity.

  • Page 23: Declaration Of Conformity

    Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009+A1:2012; EN55103-2: 2009; EN61000-3-2: 2014; EN61000-3-3: 2013. & Harmonized Standard EN 60598-1:2015;...
  • Page 24 Innovation, Quality, Performance...
