Kramer DIP-20 Quick Start Manual

KRAMER
DIP-20 Automatic Video Switcher Quick Start Guide
This guide helps you install and use your product for the first time. For more detailed information, g
http://www.kramerav.com/manual/DIP-20
Step 1: Check what's in the box
DIP-20 Automatic Video Switcher
Power adapter (48V)
Step 2: Install the DIP-20
Mount the device in a rack (using the optional RK-T2B rack adapter available for purchase) or attach the rubber feet and place the
device on a shelf.
Step 3: Connect inputs and outputs
Always switch off the power to all devices before connecting it to your
For best results, we recommend that you always use Kramer high-performance cables to connect AV equipment to the DIP-20.
Blu-ray
Disk Player
Active
Speakers
DIP-20 Quick Start (P/N: 2900-300490QS REV 2)
to download the latest manual or scan the QR code on the left.
1 Quick start guide
4 Rubber feet
Laptop
To Remote
Step-In
Switch
To Remote To Remote
Input Toggle Volume
Switch Control Switch
1 ADC-DPM/HF
DisplayPort (M) to HDMI (F) Adapter Cable
DIP-20 .
Computer
Graphics Source
1 2 3 4
TP-588D/
TP-580RXR
o to
Front Panel
Rear Panel
P/N: 2 9 0 0 - 3 0 0 4 9 0 QS
Rev:
2
