Kramer DIP-31 Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
DIP-31 Automatic Video Switcher
1 Power supply (12V DC)
Step 2: Get to know your DIP-31
# Feature
1 SELECT Button
HDMI™ IN
1
2 HDMI 1 Connector
3 SELECT Button
HDMI IN 2
4 HDMI 2 Connector
5 SELECT Button
PC IN
6 PC Graphics 15-pin
HD Connector
7 AUDIO IN 3.5mm Mini Jack
8 Step-In Button
9 ON LED
DIP-31 Quick Start
DIP-31 Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/DIP-31
upgrades are available.
Function
Press to select the HDMI In 1 input. When HDMI In 1 is selected, the button:
Lights red when external audio is selected
Lights green when HDMI In 1 is selected
Connect to the first HDMI source
Press to select the HDMI In 2 input. When HDMI In 2 is selected, the button:
Lights red when external audio is selected
Lights green when HDMI In 2 is selected
Connect to the second HDMI source
Press to select the PC graphics input. When PC graphics is selected, the button:
Lights red when external audio is selected
Lights green when the PC input selected
Connect to the PC graphics source, (for example, a laptop)
Connect to the unbalanced, stereo audio source, (for example, the audio output of
the laptop)
Press to take control of the input that this device is connected to on a compatible
switcher
Lights green when the device is powered on
DIP-31 for the first time.
to download the latest user manual and check if firmware
1 Set of rack ears
4 Rubber feet
P/N: 2 9 0 0 - 3 0 1 0 7 4 QS
1 Quick start guide
Rev: 4
