Micro800™ Programmable Controller External
AC Power Supply
Catalog Number(s) 2080-PS120-240VAC
http://literature.rockwellautomation.com/idc/groups/literature/documents/in/2080-
in001_-mu-p.pdf
Cette publication est disponible en
FR
français sous forme électronique (fichier
PDF). Pour la télécharger, rendez-vous sur
la page Internet indiquée ci-dessus.
Questa pubblicazione è disponibile in
Italiano in formato PDF. Per scaricarla
IT
collegarsi al sito Web indicato sopra.
Diese Publikation ist als PDF auf Deutsch
verfügbar. Gehen Sie auf die oben
DE
genannte Web-Adresse, um nach der
Publikation zu suchen und sie
herunterzuladen.
Esta publicación está disponible en
español como PDF. Diríjase a la dirección
ES
web indicada arriba para buscar y
descarga esta publicación.
Table of Contents
Topic
Important User Information
Overview
Connect the Power Supply
Wire the Module
Specifications
Installation Instructions
Esta publicação está disponível em portugués
PT
como PDF. Vá ao endereço web que aparece
acima para encontrar e fazer download da
publicação.
ZH
ZC
KO
Page
2
7
8
10
10
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Micro800
Summary of Contents for Rockwell Automation Micro800
- Page 1 Installation Instructions Micro800™ Programmable Controller External AC Power Supply Catalog Number(s) 2080-PS120-240VAC http://literature.rockwellautomation.com/idc/groups/literature/documents/in/2080- in001_-mu-p.pdf Cette publication est disponible en Esta publicação está disponível em portugués français sous forme électronique (fichier como PDF. Vá ao endereço web que aparece PDF). Pour la télécharger, rendez-vous sur acima para encontrar e fazer download da la page Internet indiquée ci-dessus.
-
Page 2: Important User Information
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 3: Environment And Enclosure
Micro800™ Programmable Controller External AC Power Supply 3 Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial ATTENTION environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. -
Page 4: Preventing Electrostatic Discharge
4 Micro800™ Programmable Controller External AC Power Supply Preventing Electrostatic Discharge This equipment is sensitive to electrostatic discharge, which can cause ATTENTION internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. -
Page 5: North American Hazardous Location Approval
Micro800™ Programmable Controller External AC Power Supply 5 North American Hazardous Location Approval The following modules are North American Hazardous Location approved: 2080-PS120-240VAC The following information applies when operating Informations sur l’utilisation de cet équipement en this equipment in hazardous locations: environnements dangereux: Products marked "CL I, DIV 2, GP A, B, C, D"... - Page 6 6 Micro800™ Programmable Controller External AC Power Supply • When used in a Class I, Division 2, hazardous location, this equipment WARNING must be mounted in a suitable enclosure with proper wiring method that complies with the governing electrical codes.
-
Page 7: Additional Resources
Micro800™ Programmable Controller External AC Power Supply 7 Additional Resources Resource Description Micro810™ LC10 Programmable Controllers A more detailed description of how to install and use User Manual, publication 2080-UM001 your Micro810 LC10 programmable controller and expansion I/O system. Micro830™ LC30 Programmable Controllers... - Page 8 8 Micro800™ Programmable Controller External AC Power Supply Connect the Power Supply 45063 General Considerations Most applications require installation in an industrial enclosure to reduce the effects of electrical interference and environmental exposure. Locate your module as far as possible from power lines, load lines, and other sources of electrical noise such as hard-contact switches, relays, and AC motor drives.
- Page 9 Micro800™ Programmable Controller External AC Power Supply 9 DIN Rail Mounting Use a flat-blade screwdriver to mount the power supply on EN50022-35x7.5 DIN rails. Panel Mounting The preferred mounting method is to use four M4 (#8) screws per module. Hole spacing tolerance: ±0.4 mm (0.016 in.).
-
Page 10: Specifications
10 Micro800™ Programmable Controller External AC Power Supply Wire the Module PAC-1 PAC-2 PAC-3 45062 DC-1 DC-2 DC-3 DC-4 45061 AC Input Connectors DC Output Connectors (DC 24V/ 1.6 A) PAC-1 AC hot 100…240V AC DC-1 PAC-2 AC neutral 100…240V AC... - Page 11 Micro800™ Programmable Controller External AC Power Supply 11 General Attribute Value Power consumption 38.4W @ 100V AC, 38.4W @ 240V AC (Output power) Power dissipation 45.1W @ 100V AC, 44.0W @ 240V AC (Input power) Isolation voltage 250V (continuous), Primary to Secondary: Reinforced Insulation Type Type tested for 60s at 2300V AC primary to secondary and 1480V AC primary to earth ground.
- Page 12 12 Micro800™ Programmable Controller External AC Power Supply Environmental Attribute Value Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal Shock): -20…65 °C (-4…149 °F) Temperature, 65 °C (149 °F)
- Page 13 Micro800™ Programmable Controller External AC Power Supply 13 Certifications Certification Value (when product is marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E322657. UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S.
- Page 14 14 Micro800™ Programmable Controller External AC Power Supply Notes: Publication 2080-IN001A-EN-P - September 2010...
- Page 15 Micro800™ Programmable Controller External AC Power Supply 15 Notes: Publication 2080-IN001A-EN-P - September 2010...
-
Page 16: Installation Assistance
New Product Satisfaction Return Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
