Micro800™ Non-isolated Thermocouple
Plug-in Module
Catalog Number 2080-TC2
http://literature.rockwellautomation.com
Cette publication est disponible en français sous forme électronique (fichier PDF).
FR
Pour la télécharger, rendez-vous sur la page Internet indiquée ci-dessus.
Questa pubblicazione è disponibile in Italiano in formato PDF. Per scaricarla
IT
collegarsi al sito Web indicato sopra.
Diese Publikation ist als PDF auf Deutsch verfügbar. Gehen Sie auf die oben
DE
genannte Web-Adresse, um nach der Publikation zu suchen und sie
herunterzuladen.
Esta publicación está disponible en español como PDF. Diríjase a la dirección web
ES
indicada arriba para buscar y descarga esta publicación.
Esta publicação está disponível em portugués como PDF. Vá ao endereço web que
PT
aparece acima para encontrar e fazer download da publicação.
ZH
ZC
KO
Wiring Diagrams
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Allen-Bradley Micro800
Summary of Contents for Rockwell Automation Allen-Bradley Micro800
- Page 1 Wiring Diagrams Micro800™ Non-isolated Thermocouple Plug-in Module Catalog Number 2080-TC2 http://literature.rockwellautomation.com Cette publication est disponible en français sous forme électronique (fichier PDF). Pour la télécharger, rendez-vous sur la page Internet indiquée ci-dessus. Questa pubblicazione è disponibile in Italiano in formato PDF. Per scaricarla collegarsi al sito Web indicato sopra.
-
Page 2: Environment And Enclosure
2 Micro800™ Non-isolated Thermocouple Plug-in Module Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial ATTENTION environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11. -
Page 3: North American Hazardous Location Approval
Micro800™ Non-isolated Thermocouple Plug-in Module 3 North American Hazardous Location Approval The following modules are North American Hazardous Location approved: 2080-TC2 The following information applies Informations sur l’utilisation de cet when operating this equipment in équipement en environnements dangereux: hazardous locations: Products marked "CL I, DIV 2, GP A, B, C, D"... - Page 4 4 Micro800™ Non-isolated Thermocouple Plug-in Module Parts List Your package contains one Micro800 Non-isolated Thermocouple plug-in module, two module fastening screws, one trimmed/formed bendable lead NTC thermistor and these pin out guide wiring instructions. 45010 You can choose to wire the plug-in before inserting it onto the controller, or wire it once the module is secured in place.
-
Page 5: Wire The Module
Micro800™ Non-isolated Thermocouple Plug-in Module 5 Insert Module into Controller Follow the instructions to insert and secure the plug-in module to the controller. 44012 This plug-in module is intended for use with Micro800 Family of ATTENTION Programmable Controllers. 1. Position the plug-in module with the terminal block facing the front of the controller as shown. - Page 6 6 Micro800™ Non-isolated Thermocouple Plug-in Module 12-Pin Female Terminal Block Back (View into terminal block) Pin A1 CH0+ Pin B1 CH1+ Pin A2 CH0- Pin B2 CH1- 40511 Pin A3 CJ+ Pin B3 CJ- Front Pin A4 No connection Pin B4 No connection B1 + B1 - Pin A5 No connection...
- Page 7 Micro800™ Non-isolated Thermocouple Plug-in Module 7 Thermocouple Color Codes ANSI ANSI MC 96.1 Alloy Combination IEC 584.3 (mV) Color Coding Color Code Code Code Grade Over Extension +Lead -Lead Temp Temp Intrinsi- Grade Grade Range Range Grade cally Safe +Yellow +Yellow Chromega Alomega...
- Page 8 8 Micro800™ Non-isolated Thermocouple Plug-in Module Wire the CJC Thermistor 2080-TC2 CJC Thermistor Wiring and Mounting Guide 2.41 max 1. Connect the thermocouples to channel 0 and 1, respectively. Then, connect and screw the 6.5 max thermistor to terminals A3 and B3. 5 mm 0.25 50 ±...
-
Page 9: General And Environmental Specifications
Micro800™ Non-isolated Thermocouple Plug-in Module 9 Direct sensor wiring Shielded/sheathed thermocouple sensor 2080-TC2 Blue Red Blue 1 2 3 4 5 6 Process 1 2 3 4 5 6 temperature measurement 45790 Direct wiring is the preferred method of wiring for thermocouples. ATTENTION Specifications General and Environmental Specifications... - Page 10 10 Micro800™ Non-isolated Thermocouple Plug-in Module General and Environmental Specifications Attribute Value Accuracy ±1.0 °C for TC @ 25 °C (77 °F) For more information, see the Micro830 Programmable Controllers User Manual, publication 2080-UM002. Channels 2, non-isolated Thermocouple types supported J,K,N,T,E,R,S,B Open-circuit detection time 8…1515 ms...
- Page 11 Micro800™ Non-isolated Thermocouple Plug-in Module 11 Notes: Publication 2080-WD006A-EN-P - September 2011...
-
