Micro810 12 Point Programmable Controllers
Catalog Numbers 2080-LC10-12AWA, 2080-LC10-12QWB,
2080-LC10-12QBB, 2080-LC10-12DWD
http://literature.rockwellautomation.com/idc/groups/literature/documents/in/2080-in006_-mu-p.pdf
Cette publication est disponible en français
sous forme électronique (fichier PDF). Pour la
FR
télécharger, rendez-vous sur la page Internet
indiquée ci-dessus.
Questa pubblicazione è disponibile in Italiano
IT
in formato PDF. Per scaricarla collegarsi al sito
Web indicato sopra.
Diese Publikation ist als PDF auf Deutsch
verfügbar. Gehen Sie auf die oben genannte
DE
Web-Adresse, um nach der Publikation zu
suchen und sie herunterzuladen.
Esta publicación está disponible en español
ES
como PDF. Diríjase a la dirección web indicada
arriba para buscar y descarga esta publicación.
Table of Contents
Topic
Important User Information
Additional Resources
Overview
Controller Description
Mount the Module
Status Indicator
Wire the Controller
Specifications
Installation Instructions
Esta publicação está disponível em portugués
como PDF. Vá ao endereço web que aparece
PT
acima para encontrar e fazer download da
publicação.
ZH
ZC
KO
Page
2
6
7
7
8
7
10
11
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Micro810 Series
Summary of Contents for Rockwell Automation Micro810 Series
- Page 1 Installation Instructions Micro810 12 Point Programmable Controllers Catalog Numbers 2080-LC10-12AWA, 2080-LC10-12QWB, 2080-LC10-12QBB, 2080-LC10-12DWD http://literature.rockwellautomation.com/idc/groups/literature/documents/in/2080-in006_-mu-p.pdf Cette publication est disponible en français Esta publicação está disponível em portugués sous forme électronique (fichier PDF). Pour la como PDF. Vá ao endereço web que aparece télécharger, rendez-vous sur la page Internet acima para encontrar e fazer download da indiquée ci-dessus.
-
Page 2: Important User Information
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. - Page 3 Micro810 12 Point Programmable Controllers Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial ATTENTION environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11.
- Page 4 Micro810 12 Point Programmable Controllers North American Hazardous Location Approval The following modules are North American Hazardous Location approved: 2080-LC10-12AWA, 2080-LC10-12QWB, 2080-LC10-12QBB, 2080-LC10-12DWD The following information applies when Informations sur l’utilisation de cet operating this equipment in hazardous équipement en environnements locations: dangereux: Products marked "CL I, DIV 2, GP A, B, C, D"...
- Page 5 Micro810 12 Point Programmable Controllers • If you insert or remove the module while power is on, an electrical arc can WARNING occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding. •...
-
Page 6: Additional Resources
Grounding Guidelines, publication 1770-4.1 If you would like a manual, you can: • download a free electronic version from the Internet: http://literature.rockwellautomation.com • purchase a printed manual by contacting your local Allen-Bradley distributor or Rockwell Automation representative Publication 2080-IN006A-EN-P - September 2010... -
Page 7: Overview
Micro810 12 Point Programmable Controllers Overview The Micro810 12 Point controller is an economical brick-style controller with embedded inputs and outputs. It can accomodate a USB adapter, and an LCD module. It can also accomodate any 24V DC output power supply that meets minimum specifications such as the optional Micro800 power supply. -
Page 8: Mount The Module
Micro810 12 Point Programmable Controllers Mount the Module Most applications require installation in an industrial enclosure to reduce the effects of electrical interference and environmental exposure. Locate your controller as far as possible from power lines, load lines, and other sources of electrical noise such as hard-contact switches, relays, and AC motor drives. - Page 9 Micro810 12 Point Programmable Controllers To remove your controller from the DIN rail, pry the DIN rail latch downwards until it is in the unlatched position. For environments with greater vibration and shock concerns, use the panel mounting method, instead of DIN rail mounting. Panel Mounting The preferred mounting method is to use four M4 (#8) screws per module.
-
Page 10: Wire The Controller
Micro810 12 Point Programmable Controllers Wire the Controller 2080-LC10-12AWA Input Terminal Block L1 VAC L2/N VAC I-00 I-02 I-04 I-06 L2/N VAC I-01 I-03 I-05 I-07 45055 Output Terminal Block O-00 O-01 O-02 O-03 45059 2080-LC10-12QWB Input Terminal Block +DC24 COM0 I-01 I-03... -
Page 11: Specifications
Micro810 12 Point Programmable Controllers Specifications General (2080-LC10-12AWA, 2080-LC10-12QWB, 2080-LC10-12QBB, 2080-LC10-12DWD ) Attribute 2080-LC10-12AWA 2080-LC10-12QWB 2080-LC1012DWD 2080-LC10-12QBB Number of I/O 8 Input (4 digital, 4 analog/digital, configurable) 4 Output Dimensions 91 x 75 x 59 mm HxWxD (3.58 x 2.95 x 2.32 in.) Supply voltage range 85V…263V 20.4…26.4V DC 10.8V…13.2V DC... - Page 12 Micro810 12 Point Programmable Controllers General (2080-LC10-12AWA, 2080-LC10-12QWB, 2080-LC10-12QBB, 2080-LC10-12DWD ) Attribute 2080-LC10-12AWA 2080-LC10-12QWB 2080-LC1012DWD 2080-LC10-12QBB Isolation voltage 250V (continuous), 250V (continuous), Reinforced Insulation 50V (continuous), Reinforced Type, I/O to Aux and Network, Inputs to Reinforced Insulation Type, I/O Outputs Insulation Type, I/O to Aux and Type tested for 60 s at 720V DC, Inputs to...
- Page 13 Micro810 12 Point Programmable Controllers DC Inputs (2080-LC10-12QWB, -12QBB, -12DWD) (Inputs 0 through 3) Attribute Non-isolated, shared with analog inputs Isolated Nominal impedance 14.1 kΩ 3.74 kΩ (isolated) IEC input compatibility Type 1 Type 3 Analog Inputs (2080-LC10-12QWB, -12QBB, -12DWD) (Inputs 4 through 7) Attribute Value Input type...
- Page 14 Micro810 12 Point Programmable Controllers Relay Outputs (2080-LC10-12AWA, -12QWB, -12DWD) Attribute Value Output rating Relay 00 & 01: 8 A @ 240V AC, 5A @ 24V DC, B300 Relay 02 & 03: 4 A @ 240V AC, 2A @ 24V DC, C300, R150 For more specifications, refer to the Micro810 Programmable Controllers User Manual, publication 2080-UM001.
- Page 15 Micro810 12 Point Programmable Controllers Environmental Specifications Attribute Value Surge transient IEC 61000-4-5: immunity ±1 kV line-line(DM) and ±2 kV line-earth(CM) on power ports ±1 kV line-line(DM) and ±2 kV line-earth(CM) on signal ports ±2 kV line-earth(CM) on shielded ports Conducted RF immunity IEC 61000-4-6: 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz...
- Page 16 New Product Satisfaction Return Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
