Wiring Diagrams Micro800™ Non-isolated Unipolar Analog Output Plug-in Module Catalog Number 2080-OF2 http://literature.rockwellautomation.com Cette publication est disponible en français sous forme électronique (fichier PDF). Pour la télécharger, rendez-vous sur la page Internet indiquée ci-dessus. Questa pubblicazione è disponibile in Italiano in formato PDF. Per scaricarla collegarsi al sito Web indicato sopra.
2 Micro800™ Non-isolated Unipolar Analog Output Plug-in Module Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial ATTENTION environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11.
Micro800™ Non-isolated Unipolar Analog Output Plug-in Module 3 North American Hazardous Location Approval The following modules are North American Hazardous Location approved: 2080-OF2 The following information applies Informations sur l’utilisation de cet when operating this equipment in équipement en environnements dangereux: hazardous locations: Products marked "CL I, DIV 2, GP A, B, C, D"...
Page 4
4 Micro800™ Non-isolated Unipolar Analog Output Plug-in Module Parts List Your package contains one Micro800 Non-isolated Unipolar Analog Output Plug-in Module and these pinout guide wiring instructions. 45013 You can choose to wire the plug-in before inserting it onto the controller, or wire it once the module is secured in place.
Page 5
Micro800™ Non-isolated Unipolar Analog Output Plug-in Module 5 Wire the Module Follow the pinout diagram to wire your plug-in module. 8-Pin Female Terminal Block Back (View into terminal block) Pin A1 COM Pin B1 VO-0 Pin A2 COM Pin B2 CO-0 Pin A3 COM Pin B3 VO-1 Pin A4 COM...
6 Micro800™ Non-isolated Unipolar Analog Output Plug-in Module Specifications General and Environmental Specifications Attribute Value Mounting torque 0.2 Nm (1.48 lb-in) Terminal screw torque 0.22…0.25 Nm (1.95…2.21 lb-in) (using a 2.5 mm (0.10 in.) flat-blade screwdriver) Wire size 0.14…1.5 mm (26…16 AWG) solid copper wire or 0.14…1.0 mm (26…17 AWG) stranded copper wire...
Page 7
Micro800™ Non-isolated Unipolar Analog Output Plug-in Module 7 Certifications Certification (when Value product is marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E322657. UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S.
New Product Satisfaction Return Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
